- Page 1 Senior GmbH Assembly instructions for shower temple (11v24eng) Attention: This shower should be installed by two people!
- Page 2 Foreword Thank you for choosing our shower temple. Before unpacking the shower cubicle, check the packaging for any damage! Subsequent complaints will not be accepted. Before assem- bly, all parts must also be checked for damage and to ensure they are complete. If you have any problems, contact the seller or us as soon as possible! Please read these instructions carefully before starting the assembly.
-
Page 3: Electrical Parameters
Electrical parameters Rated voltage Frequency Total consumption Lighting 230V 50/60Hz 3031W Radio Frequency range radio Steam 88-108MHz 3000W Tips for the electrical connection The electrical work in the bathroom must be carried out by a qualified electrician! They must also ensure that there is adequate earthing to prevent accidents and malfunctions. •... -
Page 4: Technical Data
Tips for connecting the water • The water pressure should be 0.2-0.4MPa (2-4 bar); if the pressure is higher, a pres- sure-reducing valve should be installed. • The water temperature must not exceed 65 degrees Celsius. • The water supply for the shower should be separate, e.g. with ball valves that can be turned off. - Page 5 Product items Cover: with integrated fan, ozone generator, loudspeaker, rain shower and LED overhead lighting Left and right side panels: consisting of 2 fixed side panels with aluminium pro- files Rear wall: equipped with back massage, tap, control display, mirror and aroma- therapy fragrance dispenser The shower panel is only pre-assembled at the fac- tory to make installation easier for you.
- Page 6 4x10mm Aluminium Self-tapping corner profiles screw 4x10 mm 4x20mm Self-tapping Screws Foot massage Bracket Shelf Water hose screw short 4x10mm Hand shower Hand shower Long water Screws holder hose 4x16mm Centre aluminium Lateral aluminium Upper and lower Self-tapping U-seal Front profiles aluminium profile windows...
- Page 7 Connections for water, waste water, electricity, telephone 150 cm 90 cm Hot water 1/2 inch ATTENTION: leave an area of 15 cm diameter free in the connection area Cold water 1/2 inch of the white siphon (dark grey area) on Connections can also be located the underside of the shower base on the opposite side...
- Page 8 Positioning and alignment of the shower tray Place the shower tray where you want it to stand later. Level the shower tray using a spirit level. You can adjust the height of the individual feet. It is very important that the shower tray is level, does not tilt and that all feet are on the floor.
- Page 9 Mount front panel 4x16mm Upper and lower Self-tapping Lateral aluminium aluminium profile screw profiles In this step, you connect the side aluminium profiles E1 to the upper and lower aluminium profiles E2 using the self-tapping screws E3.
- Page 10 Centre aluminium U-seal Front profiles Front windows windows Now attach the U-shaped seals E4 to the right and left outer sides of the fixed glass panes E of the front. Press them firmly into the side profiles as far as they will go. The panes must be firmly seated in the side aluminium profiles.
-
Page 11: Install Doors
Install doors Door rollers F-seal Next, screw the door rollers F1 into the existing holes in the two sliding doors. Do not tighten the screws on the rollers completely yet, so that you still have some leeway when inserting the doors. Do not put on the inner cover yet either. The two F seals F2 are attached to the outer sides of the sliding doors. - Page 12 Door handles Magnetic perform Once the door rollers are mounted, hook the doors into the upper and lower runners at the front. The drill holes for the handles should be in the centre of the front. Once the doors are in the correct position, you can tighten the rollers and put on the cover cap.
- Page 13 Connecting side panels and front 4x10mm Aluminium Self-tapping corner profiles screw Place the two corner profiles B1 on the right and left of the already assembled front panel and slide the corner profiles over the side profiles. Connect the profiles to the existing holes using the self-tapping self-tap- ping screws B2.
- Page 14 Fitting the foot massage, glass shelf and hand shower Foot massage Bracket Shelf Hand shower holder Fit all attachments (foot massage, shelf holder, hand shower holder, etc.) to the rear panels BEFORE you place the rear panel on the shower tray and screw it in place. This saves a lot of time during the final assembly of the cubicle.
- Page 15 Connect rear panel with side panels 4x10 mm Self-tapping screw Now place the rear panel between the side panels on the shower base. Screw the rear pan- el C to the aluminium profiles of the side panels B at the existing holes using the self-tap- ping self-tapping screws C1.
- Page 16 Put on the lid 4x20mm 4x10mm Screw Screw Now you can put on the lid A. Once it is correctly positioned, drill two small holes from above through the lid into the profile of the side walls (see illustration). The distance to the front edge should be about 7 cm.
-
Page 17: The Temperature Sensor
Connecting cable connections Wiring the shower is quite simple. All the connections that are linked together are marked with small stickers. For example, “Speaker” is connected to “Speaker”. The control unit is connected to the control unit (box at the back, top of the panel) using the 9-pin data cable “B”. -
Page 18: Hose Connections
Hose connections The sketch shows an overview of the water connections, which are located behind the shower panel. View of the connections from behind Now connect the hoses for the individual functions to the five-way distributor at the top of the fitting. - Page 19 Installing drain pipes The drain is located in the floor, but the waste pipe can also be attached to a drain in the wall, but not higher than 6 cm so that the drain is still guaranteed. The HT 40 flexible pipe used for this is included in the scope of delivery.
- Page 20 a screw connection is not properly sealed, check whether the seal in the screw connection is correctly seated and whether it is screwed tight enough. After the leak test, the electrical functions can now be checked. If the plug is plugged in, you can test the light, radio, steam function, etc.
- Page 21 Aromatherapy Aromatherapy is only available for showers with a steam generator. Take a small, heat-re- sistant cloth (e.g. made of linen or cotton) measuring approx. 5 x 5 cm and drip 2-4 drops of our highly concentrated aroma oil onto it. Now push the steam head upwards and insert the cloth (the steam head is the small white box at the bottom of the aluminium panel, approx.
-
Page 22: Using The Control Panel
Using the control panel ON/OFF (press for 3 seconds) Display Temperature Display Time preset Ozone cleaning °C Display of the active audio functions 96.5 Fan display, Steam Steam on/off Interior lighting Radio ON/OFF Telephone Ozone cleaning Channel search Volume, Temperature,Time, Volume, Transmission Temperature, Time,... - Page 23 Display key lock Please note that when switching on, the button must be pressed until the signal tone sounds. Only then can you operate the other buttons. After a relatively short time, if you do not operate the display, the key lock is automatically activated.
- Page 24 Small scratches can be polished out with toothpaste and a soft cloth, for example. Make sure that the drains, which are located in the middle of the shower tray under- neath the rear walls, are always open. If these become blocked, the water will no longer run back into the inside of the tray.
-
Page 25: Warranty And Service
Spare parts can be ordered from our customer service department. Please describe the spare part in detail - it is best to add the abbreviation used in this booklet (letter/number) and the exact type of cabin (e.g. D27). We are always open to your comments and sugges- tions. - Page 28 Senior GmbH...
