FA-F350/F355
WARNING
1.1 Specifications ..........................................................................................
1.2 Features ..................................................................................................
1.3 Exterior Parts ..........................................................................................
1.4 Structual Drawing ...................................................................................
1.5 Component Location ...............................................................................
2.1 Outline ....................................................................................................
2.2 Mechanism .............................................................................................
3.1 Maintenance chart ..................................................................................
3.2 Disassembly and Assembly ....................................................................
4.1 Electrical parts Operation .......................................................................
4.2 Signal information ...................................................................................
4.3 Adjustment ..............................................................................................
5.1 Self-diagnosis/Detection of malfunction .................................................
5.2 Service mode ..........................................................................................
5.3 Self-checking ..........................................................................................
5.4 Error Code ..............................................................................................
6.1 Installation requirements .........................................................................
6.2 Installation procedure .............................................................................
Back to Model List
FA-F350/F355
Contents /Index
1-1
1-3
1-4
1-4
1-5
2-1
2-6
3-1
3-2
4-1
4-6
4-11
5-1
5-6
5-7
5-10
6-1
6-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA-F350 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic FA-F350

Summary of Contents for Panasonic FA-F350

  • Page 1: Table Of Contents

    FA-F350/F355 Back to Model List FA-F350/F355 Contents /Index WARNING I. Introduction 1.1 Specifications ..................1.2 Features ....................1.3 Exterior Parts ..................1.4 Structual Drawing ................... 1.5 Component Location ................II. Operation 2.1 Outline ....................2.2 Mechanism ..................... III. Maintenance 3.1 Maintenance chart ..................
  • Page 2 This manual was developed and is supplied to authorized servicing dealers by Panasonic Co. for the sole purpose of providing information necessary for the equipment's proper support. It is intended that this information be confidential and may not be reproduced without prior written consent from Panasonic Co.

  • Page 3: Section I Introduction

    Offset stacking (Top sheet of paper for each set is shifted by 30mm) Paper Detecting 1-3 bins Operation Part None Display None Size (W) (D) (H) 26.3”x22.9”x41.2” / 669x582x1,039mm (FA-F350) 26.3”x23.7”x41.2” / 669x603x1,039mm (FA-F355) Weight 76lbs./34.5kg(FA-F350), 79lbs/36kg(FA-F355) Power Source 24VDC supplied from copier Power Approx. 70W...
  • Page 4 Item Stapled copy size Diagonal stapling Front A3, B4, A4, A4R, B5, LDR, LGL, LTR, LTRR, Rear A3, B4, A4, B5, LDR, LGL, LTR One-point stapling Rear A4R, LTRR Two- point stapling A3, B4, A4, B5, LDR, LGL, LTR, LTRR Refer to illustration below (Tolerance : ±2mm) Stapling Position Stapled Number of copies...

  • Page 5: Features

    1.2 Features (1) Large Capacity A maximum of 1,500 copies can be stacked in normal 3 bins (20Ibs/80g/m small size paper, not stapled). (2) Improved Paper Transport Performance Copy paper 12-32Ibs/50-128g/m can be used. (3) Job Offset The first or the last copy of each job can be discharged to the foreground position, so that copies in a tray can be sorted.

  • Page 6: Exterior Parts

    1.3 Exterior Parts Interrupt tray Front lower cover Tray Rear cover Rear lower cover P.C.B. cover Fig. 1-02 1.4 Structural Drawing (1) Finisher Interruption tray Range sensor Rolling flapper Transport roller Buffer roller Swing guide Interruption flapper Paper exit roller Buffer inlet flapper Transport roller 1 Tray1/2/3...

  • Page 7: Component Location

    1.5 Component Location 1. Sensor Height sensor Buffer path entrance (PS1) paper sensor (PI17) Buffer path paper Swing guide open sensor (PI14) sensor (PI18) Tray 1 paper Entrance sensor (PI1) sensor (PI11) Tamper guide Staple tray sensor home position (PI4) sensor (PI6) Door open Joint sensor (PI15)
  • Page 8 3. Motor Paper exit motor (M2) Transport motor 2 Tamper motor (FA-F355 only) (M3) (M8) Transport motor 1 (M1) Tray shift motor (M5) Stapler shift motor (M4) Staple motor (M6) Fig. 1-06 4. Solenoid Interruption solenoid (SL4) Paddle solenoid (SL5) Buffer entrance Buffer exit solenoid (SL2)
  • Page 9 5. PCB Finisher controller Relay PCB 4 Sensor PCB Relay PCB 3 Fig. 1-08...

  • Page 10: Section Ii Operation

    Section II Operation 2.1 Outline This finisher receives commands from the copier and discharges into the tray the papers sent from the copier in normal mode, shift mode or staple mode. If the command to discharge into interruption copy bin is sent from the copier, it will operate accordingly.
  • Page 11 (2) Job Offset Mode The first or the last paper of each sort, is discharged into the staple tray face- up, shifted by 30mm. Whether the first paper should be shifted or the last one should be shifted depends on the command from the copier. The second paper or the first paper of the next sort, is not discharged into the staple tray but to the tray.
  • Page 12 (3) Staple mode The paper is loading in the staple tray. Next the first item into the tray. tray Paper Staple Swing guide Staple Stopper tray Fig. 2-06 Paper exit roller Transport roller 1 Width of paper Front diagonal stapling 2-point stapling Rear diagonal stapling Rear 1-point stapling...
  • Page 13 2.1.3 Exit route There are three normal exit routes. The route that is used depends on the paper size and discharge mode. (1) Route for small size When small size paper is loaded normally, the paper passes under the buffer roller.
  • Page 14 (3) Buffer route Paper takes this route when small size paper is used in the job offset or staple mode. Offset paper or the first and the second sheet of paper which follows the final paper to be stapled takes this route. a) The first sheet of paper is transported toward the buffer roller.

  • Page 15: Mechanism

    2.2 Mechanism 2.2.1 Job offset The job offset operation, the first or last copy of each job is shifted forward, and the other copies of that job are exited in the normal position. Papers are moved by the tamper. Tamper home position detecting sensor (PI6) checks whether or not the tamper is on the home position.
  • Page 16 Fig. 2-14 Tamper Guide plate Tamper guide Position sensor (PI6) Paper Tamper motor (M3) Shunting Fig. 2-15 solenoid (SL6) Job offset sequence Paper exit motor (M2) Transport motor 1,2 (M1/M8) Tamper motor (M3) Tamper home position sensor (PI6) Swing guide open detecting sensor (PI18) Staple tray paper sensor (PI4) Swing guide open/close...
  • Page 17 2.2.2 Stapling (1) Outline Copies can be stapled by the stapler unit when staple mode is selected. The stapling position is decided by the selected staple mode and paper size. The stapler shifting/home-position sensor (PI7) detects whether or not the stapler unit is in the home position.
  • Page 18 (2) The first paper When the rear end of the first paper rolls out of transport roller 2, the finisher controller P.C.B. stops the paper exit motor (M2). Then the rotation of the paper exit motor is reversed, and the gear is shifted to the swing guide drive.
  • Page 19 (3) The second and the proceeding papers When the tail edge of the second and the proceeding paper roll out of transport roller 2, the finisher controller P.C.B. turns the paddle solenoid (SL5) on. Then the transport motor's (M1) drive rotates the paddle. Papers pushed by the paddle are transported to staple tray.
  • Page 20 (4) The last paper After the last sheet of paper is finished being tapped, the finisher controller P.C.B. shifts the tamper to the tapping position (holding paper with tamper), then stops the tamper motor (M3). Then the finisher controller P.C.B. reverses the rotation of the paper exit motor (M2) again, and lowers the swing guide.
  • Page 21 Stapler modes and home position: a) Front diagonal stapling Home position is the stapling point in this mode. Stopper Staple tray direction Stopper Guide Fig. 2-24 Stapler b) Rear one-point stapling The stapler moves back and forth between the center position and the stapling point.
  • Page 22 c) Rear diagonal stapling When LTR or B5 is used, home position is in the back of the stapling point Stapler moves back and forth between home position and stapling point. Stapler Home position Stapling point Stopper Staple tray direction Stopper Guide Fig.
  • Page 23 Rear one-point stapling of 2 papers Starting signal Mode detection Loaded paper Staple Paper exit 1st paper 2nd paper Paper exit motor (M2) Transport motor 1 (M1) Transport motor 2 (M8) Tamper motor (M3) Tamper home position sensor (PI6) Swing guide open detecting sensor (PI18) Staple tray paper sensor (PI4)
  • Page 24 (6) Stapler unit Stapling is carried out by the staple motor (M6). One staple is made every time the cam is rotated by the motor. The cam home position is detected when the staple movement home position detecting sensor (PI2) is turned ON. Normal rotation and reversed rotation of the staple motor is controlled by micro computer (Q1) on finisher controller P.C.B..
  • Page 25 2.2.3 Tray Operation (1) Outline There are three paper exit trays used for normal feed. Vertical movement of trays is carried out by the drive of the vertical shift motor (M5). Clock pulses from the tray vertical movement motor clock sensors 1 and 2 (PI19/PI9) detect the tray position after the home position detecting sensor (PI8) is activated.
  • Page 26 Tray guide Tray 1 Tray upper limit detecting switch (MS5) Tray 2 Encoder Tray 3 Tray shift motor clock detecting sensor 1 (PI9) Tray shift motor thermo- Tray shift motor clock switch (TP1) detecting sensor 2 (PI19) Safety area switch (MS3) Tray home position sensor Tray shift motor (M5) (PI8)
  • Page 27 (2) Shutter Operation Before changing, by tray shift motor (M5) operation, the trays for receiving papers, the finisher controller P.C.B. closes the shutter on paper exit. This prevents jamming of papers loaded on tray at paper exit. The shutter moves upward (closes) when the transport motor 1 or 2 rotates in reverse, and stays in that position when the motor stops.
  • Page 28 b) Tray shift motor rotates and shifts the new tray to the lowest loading point. Tray shifting distance is detected by the tray shift motor clock sensor 1,2 (PI19,9). Tray shift motor Fig. 2-34 c) Transport motor 1 or 2 rotates in reverse and shutter moves downward. Fig.

  • Page 29: Tray Shift Motor Fig

    d) Tray shift motor rotates and adjusts the tray to the height of loaded papers. Appropriate height is detected by height sensor (PS1). Height sensor (PS1) Tray shift motor Fig. 2-36 Transport motor Claw Shutter Claw Shutter open switch (MS4) Shutter close sensor (PI5) Fig.
  • Page 30 (3) Detection of tray-loaded paper amount The amount of copies made in the sort mode (stapling or offset number) and discharged into tray, are memorized by the finisher controller P.C.B.. The height of the paper stack is detected by the height sensor (PS1). The maximum loading amount in each tray is shown in table 2-01.

  • Page 31: Fig

    2.2.4 Buffer route/operation When the finisher stops receiving paper from the copier while stapling or job offset operation, the copier has to stop operation. This finisher receives paper even while stapling or job offset operation. By transporting paper though the buffer route during stapling and offset operation, it enables the continuous operation of the copier.
  • Page 32 (3) When the lead edge of paper passes through paper sensor (PI17) at buffer entrance, the buffer exit solenoid (SL3) is turned ON, and the paper is rolled around buffer roller. Buffer entrance paper sensor (PI17) Fig. 2-42 (4) Buffer roller stops and waits for the second sheet of paper the moment the lead edge end of paper moves approximately 50mm from buffer path paper sensor (PI14).

  • Page 33: M8 Transport Motor 1 Or

    (6) The first and the second sheet of paper are transported through upper side of the buffer roller at the same time. Buffer entrance paper sensor (PI17) Fig. 2-45 (7) When the trail edge of the paper passes through the buffer entrance paper sensor (PI17), the buffer entrance flapper is turned OFF (stays on if the following sheet of paper takes large size route).
  • Page 34 2.2.5 Discharge to the interruption tray When discharge to the interruption tray is ordered by the copier, the paper is discharged into interruption tray. The process is shown below: (1) When the first sheet of paper is transported, the buffer entrance solenoid (SL2) and interruption tray solenoid (SL4) are turned ON, switching the transport route to interruption tray route.

  • Page 35: Transport Motor 2 : Fa-F355 Only

    (3) A prescribed number of paper sheets transported from the copier are discharged though the same route. Fig. 2-50 (4) When the last sheet of paper passes though the buffer path entrance sensor, the buffer pass entrance solenoid and interruption tray solenoid are turned OFF (buffer pass entrance solenoid stays ON if the following paper sheets take the large size route.

  • Page 36: Section Iii Maintenance

    Section III Maintenance 3.1 Maintenance chart 3.1.1 Periodical replacement parts No periodic parts replacement. 3.1.2 Consumption parts standard durability The list below shows the parts which will need to be replaced at least once during the guarantee period of the product because of deterioration or damage. However, these parts should be replaced only when they perform poorly.

  • Page 37: Disassembly And Assembly

    3.2 Disassembly and Assembly 3.2.1 (1) Removal of the front door unit 1) Open the front door unit 1 . 2) Remove the screw 2 and hinge 3 , then hinge remove the front door unit. Screw Front door unit Fig.3-01 (2) Removal of the rear cover.
  • Page 38 (4) Removal of the front cover. 1) Remove the screw 1 , then remove the front cover 2 . Fig. 3-04 (5) Removal of the tray unit 1) Remove the rear cover. 2) Remove the ground wire. 3) Remove the connectors. 4) Remove the slide guide (x3) 3 .
  • Page 39 (6) Removal of the grid upper guide 1) Remove the slide guide unit 1 . 2) Remove the five screws (4M) 2 . 3) Remove the screw (3M) 3 , and then remove the grid upper guide 4 . Fig. 3-07 (7) Removal of the grid lower guide 1) Remove the tray unit.
  • Page 40 3.2.2 Transport unit (1) Removal of the oscillate unit 1) Remove the tray unit. (Refer to I-5.) 2) Remove the grid upper guide. 3) Remove the grid lower guide. 4) Disconnect the two connectors 1 of the oscillate guide in the harness guide unit . Fig.
  • Page 41 (2) Removal of the buffer roller unit. 1) Remove the rear cover. 2) Disconnect the buffer roller unit cable in the harness guide from the connector Fig. 3-14 3) Unhook both end notches 2 from the holes, pressing both side plates of the buffer roller unit, and then remove the buffer roller unit 3 .
  • Page 42 (3) Removal of the stapler 1) Open the front cover, and then pull the stapler unit to your side. 2) Turn the green knob counterclockwise and pull out the stapler unit, then hold it up while rotating it upper direction. Fig.
  • Page 43 3.2.3 P.C.B. unit (1) Removal of the finisher controller P.C.B. 1) Remove the rear cover. 2) Disconnect the 14 connectors 1 . 3) Remove the four screws 2 , and then remove the finisher controller P.C.B. 3 . Fig. 3-20...

  • Page 44: Section Iv Electrical

    Section IV Electrical 4.1 Electrical parts Operation 4.1.1 Outline The finisher discharges the paper transported from the copier. There are two paper exit modes-job offset and staple. These operations are controlled by the finisher driver P.C.B.. These controls are carried out by responding to commands from the copier. Swing guide drive Tamper drive Stapler drive...
  • Page 45 5V generation Signal flow between finisher and option controller are as illustrated below: Motor Finisher driver P.C.B. Solenoid Switch Q2/Q7 EP-ROM Copier Sensor Q3/Q8 Communication IC Q9/Q14 Regulator Fig. 4-02 *Q2, Q3, Q9 : FA-F350 *Q7, Q8, Q14 : FA-F355...
  • Page 46 Finisher controller P.C.B. PI10 Fig. 4-03...
  • Page 47 4.1.3 Paper feed sensor The paper is detected by five sensors along the paper transport route. -Entrance sensor (PI1) -Paper exit sensor (PI3) -Staple tray sensor (PI4) -Buffer path tray sensor (PI14) -Buffer path entrance paper sensor (PI17) Each paper exit tray has a sensor detecting existence of paper. -Tray 1 paper sensor (PI11) -Tray 2 paper sensor (PI12) -Tray 3 paper sensor (PI13)
  • Page 48 4.1.4 Electrical circuit (1) Outline When the copier is turned ON, 24 VDC is supplied to the finisher controller P.C.B. though one route. This is for the motor solenoid and generate to 5VDC by regulator IC(Q9) on the finisher controller P.C.B. and then used for driving sensors. 24VDC for motor drive is interrupted when the door switch (MS1) is open.

  • Page 49: Signal Information

    4.2 Signal information (1) Finisher controller P.C.B. input Finisher drive circuit P.C.B. J106–3 –6 –1 J6–5 Entrance sensor "H" when paper is –1 –4 –3 –7 PENT –2 –5 –2 –6 detected by sensor J134–1 –9 –4 J9–12 Paper exit sensor "L"...
  • Page 50 J600–6 J15–10 Tray shift motor Repeats "H/L" when tray –4 –12 SFTCLK1 clock sensor 1 –5 –11 shift motor is rotating J600–6 J15–10 Tray shift motor –4 –12 Repeats "H/L" when tray SFTCLK1 clock sensor 2 –5 –11 shift motor is rotating Sensor circuit P.C.B.
  • Page 51 Stapler unit Staple home PI21 position switch J8–8 "L" when stapler is on home position STPHP Staple switch J8–10 "H" when staple is in cartridge HOOKEMP J8–11 J8–12 J8–7 "L" when stapler is connected J2–7 Copier –5 –4 –3 –2 –1 +24V J1–1...
  • Page 52 (2) Finisher controller P.C.B. output Buffer entrance solenoid +24V –1 –3 J4–3 ENTSL* –2 –1 –4 Solenoid ON when "L" Buffer exit solenoid +24V –1 –2 –4 –2 J4–5 EXITSL* –2 –1 –5 –1 –6 Solenoid ON when "L" Interruption solenoid +24V –1 –3...
  • Page 53 +24V Transport motor 1 J10–1 –2 –3 "H/L" depending on direction –4 and speed of motor rotation –5 –6 Paper exit motor J119–2 –2 J208–6 –6 J11–6 +/– depending on direction of motor rotation –1 –1 –7 –5 J11–7 +24V Tamper motor J124 J208...

  • Page 54: Adjustment

    1) Set DIP SW on the finisher controller P.C.B. as shown below. 2) Place one sheet of paper onto each bin. Fig. 4-12 (FA-F350) (FA-F355) 3) Press SW2 on the finisher controller P.C.B., then the finisher makes adjustment automatically. Automatic adjustment is made by moving the tray unit moving from the tray 1, tray 2 and tray 3 in order.
  • Page 55 This adjustment is made when the finisher controller P.C.B. is replaced. All paper sizes and staple positions can be adjusted at once by this adjustment. 1) Remove the rear cover of the finisher unit. 2) Set DIP SW on the finisher controller P.C.B. as shown below. Fig. 4-15 (FA-F350) (FA-F355) 4-12...
  • Page 56 3) Press SW2 on the finisher controller P.C.B. when making adjustment, using A4 size paper. Press SW3 on the finisher controller P.C.B. when making adjustment, using LTR paper. • By pressing SW2/3, the oscillate guide opens and the transport belt starts rotating.
  • Page 57 Tamper board Stapler A4/LTR Stopper Stopper Guide plate Staple shift direction by SW3 Staple shift direction by SW2 (Paper size -6mm) ± 2mm Fig. 4-17 7) Press SW2 and SW3 together. • Then, the oscillate guide opens and the transport belt starts rotating. When a piece of A4/LTR paper is set again, the finisher performs the staple operation.
  • Page 58 4.3.2 Variable Resistor (VR), LED, and check pin list (1) Finisher controller P.C.B. LED1 LED2 BAT1 Fig. 4-18 Switch Function Adjusting the height sensor, adjusting the tamper board, adjusting the staple position Adjusting the height sensor, adjusting the tamper board, adjusting the staple position, raising the tray Adjusting the tamper board, adjusting the staple position, lowering the tray...

  • Page 59: Section V Troubleshooting

    Section V Troubleshooting 5.1 Self-diagnosis/Detection of malfunction (1) Paper Jam The following sensors detect papers and whether they are transported appropriately: -Entrance sensor (PI1) -Paper exit sensor (PI3) -Staple tray sensor (PI4) -Buffer path paper sensor (PI14) -Buffer path entrance sensor (PI17) A paper jam is judged from whether or not paper is detected by the sensor during check timing, which is memorized in the micro computer on the finisher controller P.C.B..
  • Page 60 a) Delay of detection by the entrance sensor When the entrance sensor does not detect paper by the time the paper is transported 400mm after the paper exit signal was sent from the copier. Paper exit signal from the copier Paper exit signal from the copier 400mm 400mm...
  • Page 61 d) Paper remaining at buffer entrance sensor When the paper remains under buffer entrance sensor after the sensor is turned ON and the paper is transported twice the length of paper. Paper size x2 Paper size x2 Jam check Jam check Normal Buffer sensor (PI3) Buffer sensor (PI3)
  • Page 62 Paper exit sensor Normal (PI3) (PI3) Transport motor 1 (M1) Transport motor 1 (M1) Transport motor 2 (M8) Transport motor 2 (M8) Paper exit motor (M2) Paper exit motor (M2) *FA-F350 : Transport motor 1 *FA-F355 : Transport motor 2...
  • Page 63 i) Paper remaining at staple tray paper sensor (a) Staple mode When paper remains under staple tray paper sensor one second after the paper exit motor (M2) is turned ON. 1 second 1 second Jam check Jam check Staple tray sensor Staple tray sensor Normal (PI4)

  • Page 64: Service Mode

    5.2 Service mode F4 Mode Output check Activate the door switch before executing output check. Press the start key to start and press the Stop key to reset. Code Item Function C109 Finisher bin movement for up direction The #1 bin position moves forward the top bin position.

  • Page 65: Self-Checking

    5.3 Self-checking The CPU (Q1) on the finisher controller P.C.B. has the self-checking functions to detect the machine conditions promptly. When a problem is detected, it sends ‘Code’ and ‘Detail Code’, which represent the contents of the problem, to the copier. The copier indicates the Code on the operation panel.
  • Page 66 Detail Code Error condition Detecting timing Code • Paper exit motor (M2) • When the target clock number from E7-21 the paper exit motor clock sensor can • Paper exit motor clock not be gotten when the action starts. sensor (PI10) •...
  • Page 67 Detail Code Error condition Detecting timing Code • Backup RAM • When the checksum is faulty when E7-26 turning the power ON. • Tray up/down motor (M5) • When the up/down operation is not E7-27 completed within fifteen seconds after •...

  • Page 68: Error Code

    5.4 Error Code (1) Finisher unit 1. E5-22 Communication to the copier error Cause/Error position Procedure Check item Result Action Finisher controller Is it corrected by turning the Completed. P.C.B./ Copier DC power switch of the copier controller circuit OFF/ON. P.C.B.
  • Page 69 3. E7-20 Transport motor error (Details 02) Cause/Error position Procedure Check item Result Action Transport motor (M1) Is the transport motor Replace the rotating in reverse at the transport motor or predetermined time? finisher controller P.C.B. Shutter mechanism Are the shutter and shutter Connect them up/down bar connected correctly.
  • Page 70 5. E7-21 Paper exit motor error Cause/Error position Procedure Check item Result Action Paper exit motor Rotate the paper exit roller Correct the by hands. Does it rotate mechanism. smoothly? Paper exit motor clock Check the paper exit clock Replace the sensor. sensor (PI10) sensor.
  • Page 71 8. E7-21 Paper exit motor error (Details 03) Cause/Error position Procedure Check item Result Action Safety area switch Check the safety area switch. Replace the switch. (MS3) Is the switch normal? Is the safety area detect Correct the switch pressed correctly? mechanism.
  • Page 72 11. E7-24 Stapler shift motor error Cause/Error position Procedure Check item Result Action Stapler shift home Check the stapler shift home Replace the sensor. position sensor (PI7) position sensor. Is the sensor normal? Wiring Is the wiring between the Correct it. finisher controller P.C.B.
  • Page 73 14. E7-25 Height sensor error (Details 04) Cause/Error position Procedure Check item Result Action Adjustment Perform the adjustment with Completed. the dip switch again. Is the condition improved? Wiring Is the wiring between the Correct the wiring. finisher controller P.C.B. and sensor normal? Power source Measure the voltage...
  • Page 74 17. E7-27 Tray up/down motor error (Details 02) Cause/Error position Procedure Check item Result Action Tray position Does the tray get to the tray Lower the tray upper limit switch position? position. Tray upper limit switch Check the tray upper limit Replace the switch.

  • Page 75: Section Vi Unpacking/Installation

    Section VI Unpacking/Installation 6.1 Installation requirements • The same as the copier, FA-F350/F355 is a precision machine. The performance of the sorter can be affected by the surrounding conditions. The sorter should not be installed under the following conditions: (1) Extremely high temperature/humidity.

  • Page 76: Installation Procedure

    6.2 Installation Procedure (1) Unpacking Check the contents and condition of the box for completeness and any shipping damage before installation. (visual check) * Check the contents of the box. 3 bin finisher (x 1) Rail guide (with rail) Floor plate (x 1) (x 1) Finisher mounting bracket...
  • Page 77 Harness cover (small) Latch receiving bracket Latch receiving bracket (x 2) mounting screw mounting screw (for FA-FK35) (for FA-RU350) (M4 x 12) (x 2) (M4 x 18) (x 2) Floor plate Finisher bin Rail guide Finisher mounting mounting screw mounting screw mounting screw bracket screw (M4 x 18) (x 2)
  • Page 78 Location Shipping material/Procedure Check (1) Install the rail mounting bracket onto the 3 bin finisher. (2 screws) (1) Install the latch. (2 screws) (2) Move the finisher onto the floor plate. Note: Adjust the height between the top of latch and top of the latch Guide guide so that it becomes 10...
  • Page 79 Location Shipping material/Procedure Check (1) Install the escape tray. (1) Remove the blind plate from the rear cover of the copier. (2 screws) (2) Connect the IPC communication PCB to CN21 of the main CPU PCB. Note: Components side of the IPC PCB should be facing towards the finisher.
  • Page 80 Location Shipping material/Procedure Check (1) Adjust the rail and rail guide height so that they become par- allel by adjusting the position of the rail mounting bracket. (1) Connect the 3 bin finisher lattice connector to the digital copier.
