Flex FXA5121 Operator's Manual

24v inspection light
Hide thumbs

Advertisement

Table of Contents

OPERATOR'S MANUAL
Model:
FXA5121
24V INSPECTION LIGHT
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
Please contact FLEX customer service in Australia 1300 000 346 or
New Zealand 0508 000 346 any time you have questions or warranty claims.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FXA5121 and is the answer not in the manual?

Questions and answers

Related Manuals for Flex FXA5121

Summary of Contents for Flex FXA5121

  • Page 1 WARNING: To reduce the risk of injury, the user must read and understand the Owner’s Manual before using this product. Save these instructions for future reference. Please contact FLEX customer service in Australia 1300 000 346 or New Zealand 0508 000 346 any time you have questions or warranty claims.

  • Page 2: Safety Symbols

    SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 3: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS Read all safety warnings, instructions, illustrations and specifications WARNING provided with this appliance. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Prevent unintentional starting. Ensure Do not use a battery pack or appliance that the switch is in the off-position before is damaged or modified.
  • Page 4 SYMBOLS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. Symbol Name Designation/Explanation Volts Voltage Amperes Current Hertz...
  • Page 5 Symbol Name Designation/Explanation Keep away from persons with Alerts user of potential harm to a pacemaker pacemakers Class III tool This product complies with applicable Regulatory compliance mark Australian standards.
  • Page 6 Grip On/Off Button Lens (Transparent Magnet Cover) Removable Belt Clip Model No. FXA5121 Rated Voltage 24 V d.c. Rated Power 10 W Luminous Flux (brightness) 1,000/500/200 Lumens Articulating Head Range 180° Pivot / 270° Swivel Recommended Operating Temperature -20 – 40℃ suitable for use indoors Recommended Storage Temperature <...
  • Page 7 ASSEMBLY Detach the battery pack WARNING Fig. 2 from the tool before performing any assembly or adjustments, or changing accessories. Such preventive safety Attach measures reduce the risk of starting the tool accidentally. TO ATTACH/DETACH BATTERY PACK (FIG. 2) To attach the battery pack: Align the raised rib on the battery pack with the grooves in the tool, and then slide the battery pack onto the tool.
  • Page 8 ADJUSTMENTS Fig. 4a HANGING LOOP (FIG. 4a & 4b) Your light is equipped with a hanging loop. It Hanging Loop can be pulled out and pivoted 360 degrees to hang the light on a hook or a hook-like object. To prevent the risk of injury or product damage，make sure that the hook is sturdy enough to support the weight of the light with attached battery pack.
  • Page 9 MAGNET BAR (FIG. 5) Fig. 5 Keep the inspection light WARNING away from cardiac pacemakers. The magnets generate a field that can impair the function of cardiac pacemakers. NOTICE: Keep the inspection light away from magnetic data medium and magnetically sensitive equipment.
  • Page 10 This inspection light must be used only with the FLEX 24V series battery packs and chargers. NOTICE: Please refer to the battery pack and charger manuals for detailed operating information.

  • Page 11: Maintenance

    We recommend that all tool service be foreign matter. Do not attempt to clean by performed by a FLEX Factory Service Centre or inserting pointed objects through openings. Authorized FLEX Service Station.

  • Page 12: Warranty Statement

    If the Customer registers its purchase of the Product online at www.flex-tools.com.au or by calling • 1300 000 346 in Australia or www.flex-tools.co.nz or by calling 0508 000 346 in New Zealand within 30 days of the date of its purchase (Registration), the Warranty Period for the following Products is as follows: FLEX 24V Tools: 5 years;...

  • Page 13: Warranty Claims

    The Warranty does not apply if: a) the Product is not supplied in its final shape and form by Chervon or an authorised FLEX Dealer, which can be confirmed on the website store locator (for avoidance of doubt, third party online stores such as eBay, Gumtree, Amazon, etc.
  • Page 14 *Original purchaser must register the product(s) within 30 days of purchase and retain their receipt as proof of purchase. This warranty applies only to the original purchaser from an authorised FLEX dealer and may not be transferred. If original purchaser does not register their product within 30 days, the warranty will apply for the duration set out in table above in column ‘LIMITED...
