Avanti AVIM333S-IS Quick Start Manual

Bullet Ice Maker Quick Start Guide
Getting Started:
1. Make certain that the Drain Plug underneath the
unit is closed.
2. Plug the ice maker into the wall outlet.
3. Open the lid and remove the ice basket.
4. Fill the water reservoir to the max water level mark.
5. Reinsert ice basket and close the lid.
6. Press the POWER button.
7. Press the SELECT button, to change between either
the small or large ice size.
8. Fresh ice cubes will automatically dispense into
the basket.
Button Reference Button Reference
Power Full Ice Power Full Ice
Quick Info:
Ice Full LED Light: will light up when the
ice basket is full and the ice maker will
automatically stop the ice making cycle.
• When ice is removed from the ice
basket, the ice maker will restart its ice
making function automatically.
Add Water LED Light: will light up when the
water reservoir is empty, the ice making
cycle will stop automatically.
Add Add Small Small Large Large
Water Water Ice Ice Ice Ice
Do not tilt the ice maker more than 45° during
transport or use. Avoid turning it upside down,
as this could damage the compressor or
refrigeration system. Allow the fluids in the
compressor to settle for 2 hours after moving
or transporting the ice maker before using it.
To Refill:
Open the lid and remove the ice basket.
1. Fill the water reservoir to the max water
level mark.
2. Press the POWER button.
3. Press the SELECT button, to change
between either the small or large ice size.
Cleaning Select Cleaning Select
Drain Plug
092624
AVIM333S-IS
