T200
USER MANUAL
Thank you for purchasing GRECELL portable power station.
For the best performance and safety purposes, please read this manual carefully before
use. Please keep this manual for further reference.
CHARGE FIRST!
Before using your new Power Station T200 or after storing it for more than 3 months,
plug it into a suitable power outlet until it is fully charged. Then you can start your exciting
journey with it. Highly recommend to charge T200 when battery indicate less than 20%.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GRECELL T200
Summary of Contents for GRECELL T200
- Page 1 Please keep this manual for further reference. CHARGE FIRST! Before using your new Power Station T200 or after storing it for more than 3 months, plug it into a suitable power outlet until it is fully charged. Then you can start your exciting...
-
Page 2: Product Function Description
LCD Screen Display USB-A Output USB-C Output / Input Silicone Handle DC 7909 Input LED Light USB-C Output Phone Tablet Stand DC 5525 Output ACCESSORY LIST USB-C 12V Car User Manual Charging Cable Charger Cable T200 Power Station - 1 -... -
Page 3: Button Feature
BUTTON FEATURE A: Power ON/OFF B: LED Light Button A: Power ON/OFF ● Press A to turn on the power. At the same time, the LCD will light up, and the USB and DC 5525 output will turn on. Press the A button again to turn off the power. Button B: LED Light ●... -
Page 4: General Specifications
The light is on, and the bulb icon is lit. LED Light (In ECO mode, it will enter sleep mode after 8 hours of illumination.) After the power button A is turned on, the DC Output USB OUT icon and DC OUT icon light up and display the total DC power output. -
Page 5: Product Features
Input DC/PV Input DC 7909, 12V-26V 8A, 100W Max USB-C1 Input 5V/9V/12V/15V/20V 3A, 20V 5A, 100W Max Output DC Output DC5525, 12.8V 8A USB-A Output×2 5V 3A, 9V 2A, 12V 1.5A, 18W Max USB-C1 Output×1 5V/9V/12V/15V/20V 3A, 20V 5A, 100W Max USB-C2 Output×1 5V/9V 3A, 12V 2.5A, 30W Max LED Light... -
Page 6: How To Charge
P U L L Phone stand function HOW TO CHARGE Do not connect device via ac output port while charge the T200. Recommend to disconnect the T200 when fully charged. 12V Car Charging 96W, adout 1.8-3 hours From Solar Panel PV Charging 100W, 1.7-4.4 hours... - Page 7 SOLAR PV CHARGING Supports 60W/100W solar panel charging at DC12-26V. Charging time depends on sunlight intensity, so please place as many solar panels in direct sunlight as possible. (Not Included) CHARGE USING THE USB-C PORT Charge your device using the provided charging cable.about 1.8-2.8 hours. AC Outlet AC Adapter - 6 -...
-
Page 8: Car Charging
12V CAR CHARGING Charge with car charging cable. It takes 1.8-2.9 hours to fully charge. Cigarette Lighter Plug Car Charger Note: Do not use the USB-C1 port and DC7909 port to charge the portable power station at the same time, or charge with solar PV input and car port at the same time! WHAT IT POWERS Mini Fridge... -
Page 9: Troubleshooting
When no output is activated, the LCD screen will turn off automatically. Overload protection and short circuit protection： ● If the output port is overloaded or shorted, the T200 will automatically shut down the output. But the LCD screen is still on. ●... - Page 10 ● Do not disassemble the device privately. ● Do not cover the equipment with towels, clothes or other items. Regularly observe the side vents for dust and foreign matter, and clean them according to the cleaning procedures specified in the manual. Equipment cleaning：...
-
Page 11: Important Safety Instructions
(4) The warranty of T200 Series does not apply to 1) any product that is modified, misused, abused, damaged by accident, or used for anything other than normal consumer use as authorized in current product literature or 2) any product purchased through an online auction house. - Page 12 incorporate a fuse or other protective device having a current rating not greater than 15A. INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. IMPORTANT SAFETY INSTRUCTIONS 1. WARNING – When using this product, basic precautions should always be followed, including the following: a) Read all the instructions before using the product.
-
Page 13: Fcc Note
5) Be extra cautious to reduce the risk of dropping a metal tool onto the battery. It might spark or short-circuit battery or other electrical parts that may cause an explosion. l) When charging the internal battery, work in a well-ventilated area and do not restrict ventilation in any way. - Page 14 See www.epa.gov for additional information. Warranty All GRECELL products come with a full 2-year limited warranty from the date of purchase (accessories excluded). It will be out of guarantee if damaged due to incorrect use or force majeure.
- Page 15 If you have any questions, please feel free to contact us: E-mail: support@grecell.com...
