FA02118-EN
ETI MINI SER
CONFIGURATION MANUAL
EN
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETI MINI SER and is the answer not in the manual?

Questions and answers

Related Manuals for CAME ETI MINI SER

Summary of Contents for CAME ETI MINI SER

  • Page 1 FA02118-EN ETI MINI SER CONFIGURATION MANUAL English...

  • Page 2: Table Of Contents

    CONTENTS DESCRIPTION AND SYSTEM REQUIREMENTS Description Minimum PC requirements CONFIGURING THE ETI MINI SER SERVER Accessing the first configuration page MENU Device data Network Switch mode connection Dual network mode connection Static routes DHCP server Services CAMEConnect Date and time...

  • Page 3: Description And System Requirements

    Accessing the first configuration page Once your PC has been configured and connected to the ETI MINI SER device, enter the address http://192.168.0.3 in your browser (when connecting to port Port0) or http://192.168.1.3 (when connecting to port Port1) to access the server configuration page.
  • Page 4 Diagnosis Network parameters Interface name IP address Subnet Mask Copyright © 2024 CAME S.p.A - All rights reserved - VAT ID No. 03481280265 English Before starting configuration, select the Language icon for your preferred language. User General information General information...

  • Page 5: Menu

    MENU Device data In the [Device data] section, view general information about the device. ETI MINI SER device ID data. ETI MINI SER device firmware version. User Device data General information Model Device data Name Network Serial number Date and time...

  • Page 6: Switch Mode Connection

    Network Switch mode connection Go to [Network] and then the [Connections] tab; enter the chosen IP address for this device and the netmask. Enter the default gateway for the chosen subnet in the field below. The two RJ45 ports are interconnected in switch mode via the Ethernet and respond to the same IP address as the device – this address corresponds to the same single ETH0 logical interface and the same MAC address.

  • Page 7: Dual Network Mode Connection

    Dual network mode connection The two ports are NOT logically interconnected; each corresponds to a different Ethernet interface: ETH0 and ETH1, respectively, and therefore to a different subnet. From the [Network] window under the [Connections] tab, the IP address, netmask and gateway must be entered for the two interfaces. An IP video-entry terminal connected to the subnetwork of Port 0 (ETH0) can make/receive video calls to/from an IP device connected to the subnetwork of Port 1 (e.g IP terminals in an apartment, ETI/SER with porters and ETI/XIP in an apartment block network).

  • Page 8: Dhcp Server

    DHCP server Through the DHCP Server service, ETI MINI SER assigns IP addresses of a certain set and the associated netmask and gateway, to client devices that request them (via the standard DHCP protocol). The service is disabled by default.

  • Page 9: Cameconnect

    CAMEConnect Under [CAMEConnect], enter the URL to enable remote management of CAME systems. Unless stated otherwise, leave xip01.cameconnect.net as the default. Connection status with the CAMEConnect cloud. Field for enabling connection to CAMEConnect. Once you have finished, press [Save]. User...

  • Page 10: Voip Settings

    VoIP settings General settings Under [VoIP settings] in the [General settings] tab, set the ring time after which the called user will be considered absent and the call will be terminated automatically. Set the ring time after which the called user will be considered absent and call diversion will be activated. The ring time must be longer than the ring time with diversion.

  • Page 11: Access Control

    Access control Standard programming Under [Access Control] in the [Routine Programming] tab, program access to one or more passages for a group of users. The [User management] icon allows you to: - search for a user; - create a new user; - show a list of all created users.
  • Page 12 From [Add user], select the users to associate with the group. User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name Group name VoIP settings Users Weekly programming Passages Access control Add user Add time slot Add passage...
  • Page 13 From [Add time slot], set a weekly time interval. User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name VoIP settings CLEANING COMPANY Passages Users Weekly programming Access control Cleaning operator 1 Add time slot Add passage Video entry system...
  • Page 14 Under [Non-standard programming], add non-standard programming (e.g. public holidays or company closures). User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name VoIP settings CLEANING COMPANY Passages Users Weekly programming Access control From: Add passage Cleaning operator 1...

  • Page 15: Predefined Programming

    Select one or more passages to give the user group access to. Once you have finished, press [Save]. User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name VoIP settings CLEANING COMPANY Users Weekly programming Passages...
  • Page 16 To change a user’s credentials, press the arrow corresponding to the group they belong to. User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name Users Weekly programming ALFATECH VoIP settings EURORAC managers Access control ALFATECH managers...

  • Page 17: Example Of Access-Control Application

    Example of access-control application Installation description You need to program access control for the complex shown in the figure below, consisting of two office buildings and an enclosed car park divided by pedestrian entrances. The access-control devices positioned at each passage are shown in red. ENTRANCE EAST ENTRANCE...

  • Page 18: Programming

    Programming After creating and programming the system using PCS/XIP software, inserting entry panels with RFID readers and internal receives as shown in the image, the next step is to program access control. For this example, start by creating all users who will be able to access the buildings. To assign a badge to a user, position the cursor in the [Badge code] field ;...
  • Page 19 Next, create groups containing different categories of users. User Access control General information Standard programming Predefined programming Device data Network User management Date and time Group name Users Weekly programming No group found VoIP settings Access control Add group Reload Video entry system The client’s first request is to allow pedestrian access to the buildings for all employees, but only to the company they work for;...
  • Page 20 The client’s second request is to allow access from any passage to managers only on any day of the year; to fulfil this request, the following permissions must be created: ALFATECH managers and EURORAC managers. ALFATECH managers User Access control General information Standard programming Predefined programming...
  • Page 21 The client’s third request is to allow service personnel access only after office hours without passing through the EAST and WEST entrances; to fulfil this request, the following permissions must be created: CLEANING COMPANY. Cleaning company User Access control General information Standard programming Predefined programming Device data...

  • Page 22: Video-Entry System

    Video-entry system In a system with one ETI MINI SER and several ETI-XIP gateways, the ETI MINI SER must be the master and will be the first to be programmed. Device mode Under [Video entry system] in the [Device mode] tab, choose a communication port through which slaves will communicate with the ETI MINI SER Master (permitted range: 20050-20166).
  • Page 23 Credentials Call management Once all slaves in the system have been added, one of them (the one with the [Backup] box flagged) can be set to back up the ETI MINI SER master continuously. Assign a port (20050 to 20166).

  • Page 24: Multiserver

    Multiserver Multiserver is an XIP system with two or more interconnected servers belonging to a single LAN. The system is divided into several subsystems, each managed by a single server. Where there are XTS 7 IP Master or PLX V IP Wi-Fi Master or ETI/Miniser devices, it is considered a Multiserver system. The Registered field indicates that the server described in the corresponding row is correctly registered on the server shown.

  • Page 25: Credentials

    Credentials Receivers Under [Receivers], assign a password to CAME internal devices. Press the pencil corresponding to the relevant device to open the [Edit credentials] window. User Credentials General information Receivers Mobile app Generic SIP receivers SIP ATA interfaces SIP gateway interfaces...

  • Page 26: Mobile App

    Mobile app Under [Mobile app], assign a password to CAME mobile apps. Press the pencil corresponding to the relevant device to open the [Edit credentials] window. User Credentials General information Receivers Mobile app Generic SIP receivers SIP ATA interfaces SIP gateway interfaces...

  • Page 27: Sip Ata Interfaces

    SIP ATA interfaces An SIP ATA (Analog Terminal Adapter) receiver is a device through which an analogue telephone can interoperate with an XIP video-entry system. It supports the SIP protocol and can register with the ETI/SER. Under [SIP ATA interfaces], assign a password to SIP ATA receivers. Press the pencil corresponding to the relevant device to open the [Edit credentials] window.

  • Page 28: Call Management

    Call management Diversions From the [Call management] window under the [Diversions] tab, you can change the destination of a call. Press [Add diversion] to create a diversion. User Call management General information Diversions Active rules Device data Network Order Destination Forward Weekly programming Date and time...
  • Page 29 From the list of system components [Forward], enter or select the recipient of the diverted call. User Call management General information Diversions Active rules Device data Destination Forward Network Select element Select element Date and time Weekly programming VoIP settings Access control Save Cancel...

  • Page 30: Active Rules

    Active rules Under [Active rules], view the [Forwards] and [Diversions] schedule with the reasons for the diversion. User Call management General information Diversions Active rules Device data Active rules on date: Friday, 130/09/2024 Network From 17:00 To 17:15 Date and time Diversions VoIP settings Destination...

  • Page 31: Multi-Family

    Multi-family Internet Internet Router Router ADSL ADSL Home LAN Home LAN ETI/DOMO XIP ETI/DOMO XIP Appartamento 1 Appartamento 2 Smartphone Switch Terminali IP Ethernet 10/100/1G Common LAN - Backbone VA/08 ETI/XIP ETI/SER Installation description LAN backbone (common) separate and distinct from the home LANs. ETI/DOMO XIP in dual network configuration.

  • Page 32: Licences

    Diagnosis Manage licences Under [Manage licences], request additional licences from CAME S.p.A. by pressing [Request]; a file will be generated which can be saved on your PC and sent via email. Once you have received the necessary file, press [Select file]; find the received file on your PC and unlock the licence.

  • Page 33: Maintenance

    Maintenance Firmware Under [Maintenance] in the [Firmware] tab, view and update the installed firmware version. Firmware version installed Press [Select file] to select the firmware update file saved on your PC and proceed with the update. User Maintenance General information Firmware Restore device System configuration...

  • Page 34: System Configuration

    System configuration Under [Maintenance] in the [System configuration] tab, import and export the system configuration backup file. User Maintenance General information Firmware Restore device System configuration Device data Network Export system configuration Import system configuration Date and time VoIP settings Access control Video entry system Credentials...

  • Page 35: Events

    Events The system records log files that collect useful diagnostic information. Obtain one or more detailed system event reports under [Events]. Search by event type and system block and for a specific time interval. User Diagnosis General information Logs Events Device data Network From...
  • Page 36 CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941 info@came.com - www.came.com...
