Summary of Contents for Orion OLC2
- Page 1 OLC2 2 channel line output convertor with bass processor...
- Page 2 - Run the remote bass wire to the f ront of your vehicle for easy access and control. Adjusting Input Gain: - Use the Main and Bass Output Level knobs on the OLC2 to adjust the input gain according to your preferences and system requirements.
- Page 3 CONVERTER WITH BASS PROCESSOR Power: While it's fantastic that the OLC2 offers three different ways to be turned on, it is crucial to remember that the OLC2 must be connected to a constant +12V power source and a ground. Perhaps in the future, science will discover a method to power devices using the electrifying energy of a Jimi Hendrix guitar solo, but until then, we rely on good old +12V power and ground connections.
- Page 4 Settings Level: Main Output - The OLC2 provides a f ixed full range output, which is perfect for connecting to multi-channel amplif iers intended for door speakers. You can adjust the output level using the Main Output Level knob to achieve the desired audio performance for your system.
- Page 5 TruBASS Level knob to your liking for continuous bass enhancement. Remote Output - Utilize the Remote Output (Rmt Out) on the OLC2 to trigger your aftermarket amplif ier. The Remote Output will be active whenever the OLC2 is turned on, regardless of the method used to activate it.
-
Page 6: Specifications
2 CHANNEL LINE OUTPUT CONVERTER WITH BASS PROCESSOR 2 CHANNEL LINE-OUTPUT CONVERTER WITH BUILT-IN BASS PROCESSOR 1 Speaker Level Inputs (40V / 400W INPUT MAXIMUM AT 20 K ) 2 Remote control input 3 Power Connector REQUIRES CONSTANT +12V POWER 4 Power Status LED SPECIFICATIONS 5 Load Select Switch... - Page 7 (1) year f rom the date of original purchase provided it was purchased f rom an Authorized Orion Dealer. The conditions of this warranty and the extent of the responsibility of Orion, under this warranty are as follows: 1.
- Page 8 3130 WEST 15TH AVENUE HIALEAH, FLORIDA 33012 TEL: 786.464.0247 EMAIL: SUPPORT@ORIONCARAUDIO.COM ORIONCARAUDIO.COM PROUD SPONSOR OF Copyright ORION All rights reserved. Any unauthorized reproduction or use of any Orion logos, images or design elements is strictly prohibited by law. Specifications subject to change without notice. REV. 23.10...
