INSTRUCTION MANUAL CAUTION: Before starting any exercise program, consult with your physician or health professional. IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for the future reference.
IMPORTANT SAFETY PRECAUTIONS 1. Plug the power cord into a surge protector (not included) then plug the surge protector into a grounded circuit. No other appliances should be on the same circuit. 2. Position the treadmill on a clear level surface. Do not place the treadmill on thick carpet as it may interfere with proper ventilation.
PARTS INCLUDED Parts# Description Remarks Qty. The machine assembly 1 SET Emergency key Color red 1 PC Hexagon socket pan head screw M8*15 4 PCS Hexagon socket pan head screw M8*35 2 PCS Silicone oil 20 ml 1 PC Wrench with screw driver S13/S14/S15 1 PC Allen wrench...
PARTS LIST DESCRIPTION DESCRIPTION Base frame assembly Cylindrical head bolt, M8*35 Bolt, M8*40 Flat washer, D8 Upright tubes, left & right Curve washer, D8 Console frame Cylindrical head bolt, M6*15 Running board holder Nylon nut, M6 Front roller Tapping screw, ST4.2*15 Rear roller Tapping screw, T4.2*45 Hexagon socket pan head screw...
Page 6
ASSEMBLY INSTRUCTIONS STEP 1 Open the packing boxes, set the treadmill in a clear area, and remove all packaging materials. Refer to the page of parts included to identify the parts used in assembly. Do not dispose the packaging materials until assembly is completed.
Page 7
INCLINE LEVEL ADJUSTMENT. Pull out the ball pin (34) and insert it according to the number of tap positions 1, 2, and 3 shown on the left. Same operation on the left side as well to ensure the same number of tap positions to keep balance of the treadmill.
Page 8
DIRECTION FOR MOVING THE TREADMILL Press the base tube of the treadmill with one of your foot as shown in the below picture. Hold the rear side of the main frame and push it down. Push the treadmill and move it with the rollers shown in the below picture.
GROUNDING METHODS This product must be grounded. If it malfunctions or breaks down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
Page 10
WARM UP STAGE Before exercise, it is better to warm up. Warm muscles stretch more easily, so spend the first 5 ~ 10 minutes to warm up. Then, follow the methods below to do stretching exercises - do five times for each leg, each time holding for 10 seconds or more.
EXERCISE INSTRUCTIONS Warm up stage: If you are over 35 years old, not very healthy, or it’s your first time exercise, please consult with your doctor or professional person. Before you use the treadmill, please learn how to control the machine, know well how to start, stop, adjust the speed and so on;...
MAINTENANCE INSTRUCTIONS WARNING: Always unplug the treadmill before cleaning or maintenance. General cleaning will greatly prolong the treadmill’s life. Keep the treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails. Keep your running shoes clean to avoid foreign material underneath the walking belt.
BELT ADJUSTMENT We suggest that you should cut off the power for 10 minutes after running for 1.5 hours to maintain the treadmill. The belt will slip if it is too loose while in use; if the belt is too tight, it will affect the performance of the motor and increase the abrasion of the roller and belt.
Page 14
OPERATION GUIDE CONSOLE DISPLAYS, FEATURES AND FUNCTIONS. Window SPEED: Displays the current speed. Speed Range: 0.8~12.0KM/H. When countdown mode starts, it displays "3", "2", "1". Window PULSE: Displays the current heart rate. Pulse Range: 50~199 bpm. As soon as the heart rate signal is detected, “♥”...
Page 15
SAFETY KEY FEATURE AND FUNCTIONS: The safety key is designed to function as an emergency stop mechanism. For this reason it is extremely important that the safety key CORD is attached to your clothing at all times while using the treadmill. As soon as the safety key is pulled out from the sensor on the treadmill, the treadmill will stop immediately with the beep signaling and the windows display “---”.
Page 16
WORKING PROGRAM: Press PROG to change among P01 to P12. It will display any of P01~P12 in the LCD window. You only need to preset the time. There are 10 intervals when running and the speed will change automatically. Refer to the left and right charts on the panel. PRESET PROGRAMS TIME INTERVAL(KILOMETERS)
IMPORTANT: Many of the check and correction points are intended to be performed by a certified technician. TROUBLESHOOTING GUIDE CODE# PROBLEM SOLUTION 1. Check whether the connection of the 1. The cables are damaged or poorly upper and lower communication lines is connected.
