Instruction manual
Folding scaffold type:
VS 4S
Aluminium folding scaffolds in accordance with European standard
EN 1004-1:2020 + EN 1004-2:2021
Solide NV drew up this user manual as carefully as possible.
The user is responsible for ensuring that this manual is available at the user's location.
The employer, supervisor, and user must ensure that the people responsible for the assembly work
read and understand this instruction manual so that they can safely assemble the scaffold.
SOLIDE NV
Senatorlaan 12
B 3201 Langdorp
www.solide.com
Tel: +32 13 772 313
Email:
info@solidegroup.com
Advertisement
Related Manuals for Solide VS 4S
Summary of Contents for Solide VS 4S
- Page 1 Aluminium folding scaffolds in accordance with European standard EN 1004-1:2020 + EN 1004-2:2021 Solide NV drew up this user manual as carefully as possible. The user is responsible for ensuring that this manual is available at the user’s location. The employer, supervisor, and user must ensure that the people responsible for the assembly work read and understand this instruction manual so that they can safely assemble the scaffold.
- Page 2 User training courses cannot replace the manual; these training courses are only a supplement to the manual. Adjustments deviating from this manual may not be made. Solide cannot be held liable for damage resulting from failure to assemble and use the scaffolding in accordance with these instructions.
-
Page 3: Safety Instructions
2) Damaged or defective components must not be used. These must always be replaced. 3) Only original Solide components may be used in accordance with the manufacturer’s instructions. 4) The location where the folding scaffold is constructed must be level and able to support the weight of the assembly. -
Page 4: Inspection And Maintenance
Joints and clamps must be in good working order. Rubber feet are not damaged. If in doubt about the good condition of the various components and for information about replacement components, consult your distributor or contact Solide nv. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM... -
Page 5: Product Information
Product information Description The Solide VS 4S scaffold is a lightweight, professional, aluminium folding scaffold. This folding scaffold is specifically used for carrying out inspection work, and light maintenance, installation, and construction work that does not require materials stored on the platform except the materials that will be immediately used, e.g. paint, plaster, cleaning products, etc. - Page 6 Always take care to wear the following PPE: safety gloves, hard hat, and safety work shoes. Before starting the assembly work, check that all components are in good working order. Damaged or defective components must be replaced, solely with original SOLIDE components. Model: VS30 4S 1.
- Page 7 (1 rung higher than the lower clamp of the front railing 4S). 9. Move the horizontal shore RS 185 H to the lowest rung on the open side. 10. Place a barge board set RS 001 K. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
- Page 8 Connect the stabiliser cross piece as horizontally as possible with the folding unit. Make sure that stabilisers rest on suitably solid ground. If necessary, use 30 cm by 30 cm reinforcing plates. 90° 70° MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
- Page 9 7 rung of the opposite frame, counting up from the bottom. After assembly, always check that the clamps are properly closed. 11. Place a barge board set RS 001 K. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
- Page 10 After assembly, always check that the clamps are properly closed. Repeat steps 10, 11, and 12 until you reach the desired platform height. 15. Place a barge board set RS 001 K. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
- Page 11 (1 rung higher than the lower clamp of the front railing 4S) 10. Move the horizontal shore RS 185 H to the lowest rung on the open side. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
- Page 12 Verify that platform hatches are securely closed before dismantling. NEVER allow the components fall to the ground to ensure the safety of people in the vicinity and to prevent damage to the materials. MANUAL - Folding scaffold VS 4S - 11/2023 WWW.SOLIDE.COM...
