- Page 1 Please Read The Manual Carefully Before Riding Electric Scooter ELECTRIC SCOOTER USER MANUAL Model: C1...
-
Page 2: Table Of Contents
CONTENTS General Guidelines Safety Guidelines Product Specifications Product Components Safety Guidelines Before Riding Unboxing Handlebar Unfolding Handlebar Folding Charging & Range Handlebar Controls Control Panel Parameter Settings Maintenance & FAQ Support... - Page 3 FOR USERS IMPORTANT Thank you for your purchase of the C1 Folding Electric Scooter by CAROMA! To ensure your safety and the safety of others, please read and follow the guidelines in this user manual carefully and thoroughly before and during riding.
-
Page 4: General Guidelines
Warning! REQUIRED CHECK BEFORE RIDING Please check this manual carefully before using the product. 1. Check if the control panel turns on. 2. Ensure that the brakes are working properly. 3. Check that the brake pads are not damaged or need replacing. 4. -
Page 5: Safety Precautions
Safety Precautions 1. Always wear a helmet and knee and elbow pads when riding. 2. When initially riding the scooter, maintain a low speed and gradually increase speed as riding skills improve. 3. Do not ride the scooter in the rain, in the snow, or on roads that are wet, muddy, icy, or that are slippery for any reason. -
Page 6: Product Specifications
Product Specifications Model Scooter Size(cm) 120*57*114 Fold Size(cm) 120*57*54 Battery Spec 48V 10.4A Battery Cell 18650 Max Speed(mph) Charging time Brake System Disc Suspension System null Gear Foldable Weight 21KG Climbing performance Material Magnesium Aluminum Alloy Tyre Spec 10Inch Jelly Rubber Wheel Water and Dust Resistance IP64 Battery protection... -
Page 7: Product Components
Product Components 01-Head light 07-Rear fender 13-Rear braking 02-Folding handle 08-Front motor 14-Handle bar 03-Folding hook (down) 09-Kickstand 15-Display 04-Folding hook (up) 10-Quick release lever 16-Turn signal switch 05-Charging port 11-Throttle 17-Brake calliper 06-Taillight 12-Bell 18-Brake disc... -
Page 8: Safety Guidelines Before Riding
3. Ensure all nuts and screws are tight. 4. Ensure the brakes are operating appropriately. Packing List 2*M6 The fender 4*M4 Quick release lever Please Read The Manual Carefully Before Riding Electric Scooter ELECTRIC SCOOTER USER MANUAL Model: C1 Rear wheel 2*M6... - Page 9 Installation Of Handlebar 1.Pull the handlebar in the direction 2.Insert the handlebar in the direction indicated by the arrow. indicated by the arrow. 2*M6 PACKING LIST 3..Tighten the two screws at the 4.Handlebar installation completed. arrow position.
- Page 10 Installation Of Rear Wheel 1.Install the rear wheel into 2.Install the spring to the 3.The quick release lever the rear fork. fast release rod. passes through the rear axle. Make sure the brake disc is placed between the brake pads. 4.Install the spring and the 5.Tighten the quick release 6.Press the snap lever...
-
Page 11: Handlebar Unfolding
SCOOTER UNFOLDING Handlebar Unfolding 1.Pull the handlebar in the direction 2.Close the folding handle in the indicated by the arrow. direction indicated by the arrow. 3.The safety latch closes automatically. 4.Unfolding complete. -
Page 12: Handlebar Folding
SCOOTER FOLDING Handlebar Folding 1.Slide the safety latch in the 2.Open the Folding part in the direction indicated by the arrow. direction indicated by the arrow. 4.Gently move the handlebar 3.Push the handlebar in the direction to the left, then fasten the hook. indicated by the arrow. -
Page 13: Charging & Range
CHARGING & RANGE When charging, connect the charging cable in this order: 1. FIRST to scooter’s charging port 2. THEN to the power outlet NOTE: When connected to the charger, the red light indicates that the scooter is charging. The light will turn green when fully charged. Be sure to close the charging port cap when driving or storing. -
Page 14: Adjustment Of Brake
Adjustment of Brake Before aligning the mechanical disc brake, make sure that the brake cable is properly inserted into the lock lever. If the disc rotor is bent or damaged, replace the rotor first. If the brake is not flexible, loosen the fixing bolt of the brake cable, shorten the braking distance of the brake cable, and then... -
Page 15: Handlebar Controls
Handlebar Controls Rear Brake Bell Grip mile Turning signal switch Control panel Power Headlight Rear braking and Bell Turning signal switch Throttle... -
Page 16: Control Panel
Control Panel Turning light Headlight Cruise Brake Malfunction Overheat Battery Indicator Single trip odometer Power variable bar Velocity mile variable bar Speed Gear position Total odometer • Power: Long press will start or turn off the scooter • Headlight: Headlight switch •... -
Page 17: Common Issues And Solutions
COMMON ISSUES AND SOLUTIONS Issue 1: Both headlights are not working. This situation occurs when the headlights are faulty. Replacing the headlights can solve the problem. Issue 2: The scooter cannot be charged. The problem may come from the charging port. If the charging interface is burnt out, it needs to be replaced. -
Page 18: App Introduction
APP Introduction 1.How to download the APP IOS users: Please search for "E-Scooter Home" Android users: Please download “Tencent in the Apple Store or scan the QR code to Browser” first, and then scan the QR code download it. below with Tencent browser to download it. After the app is successfully downloaded, the APP icon will be displayed. -
Page 19: Maintenance & Faq
Maintenance & FAQ The screws should be regularly maintained, inspected and tightened. Especially the screws on the folding mechanism, brake system and motors (axle nuts). • 1. Tighten the folding mechanism screws, handlebar, and front & rear wheel axle nuts. •... -
Page 20: Support
Customer Support We provide 12-month or 6-month warranty for different parts, please refer to the warranty or contact our service team by mail. Parts Warranty Period Category Battery 12 months Dynamical system Motor 12 months Controller 12 months Display 6 months Charger 6 months Electnical system...
