SpeedBox Tracker 1.0 for Bosch
STEP 1: Installing the SpeedBox Tracker mobile app
and activating the device
A.
Install the SpeedBox Tracker app on your mobile phone. Then, create a new user account or
log in if you already have an account.
B.
Click on „Add Device" and scan the QR code, or enter the IMEI and PIN, which can be found
on the included activation card.
A.
B.
1.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tracker 1.0 and is the answer not in the manual?

Questions and answers

Related Manuals for speedbox Tracker 1.0

Summary of Contents for speedbox Tracker 1.0

  • Page 1 STEP 1: Installing the SpeedBox Tracker mobile app and activating the device Install the SpeedBox Tracker app on your mobile phone. Then, create a new user account or log in if you already have an account. Click on „Add Device“ and scan the QR code, or enter the IMEI and PIN, which can be found...

  • Page 2: Step 2: Preparation For Installation

    STEP 2: Preparation for installation Turn off your e-bike before installing the SpeedBox Tracker device. If possible, disconnect and remove the battery from the e-bike. Following the manufacturer‘s instructions, disassemble all components of the e-bike so you have access to the motor connectors or the control unit within the e-bike frame.
  • Page 3 Select adapter A or B with connectors according to your motor type and connect it to the Tracker device. Disconnect the display connector from the motor. Connect the disconnected connector and motor using the SpeedBox Tracker device adapter. Make sure that the locks on the connectors are seated properly.
  • Page 4 SpeedBox Tuning device Disconnect the display connector of the SpeedBox Tuning device from the motor. Connect the motor and SpeedBox using adapter A or B (depending on the motor type). Ensure that the connector locks are correctly aligned. Now connect the SpeedBox Tracker device to the selected adapter.

  • Page 5: Step 5: Completing The Installation

    Turn off the e-bike. Only now reassemble the e-bike back to its original state. By turning on the e-bike, the SpeedBox Tracker device will also begin to charge. The SpeedBox Tracker should connect to the server within a few minutes and send information about the battery status to your mobile app.
  • Page 6 STEP 6: Notice If you installed the SpeedBox Tracker device in the e-bike before adding it to the app, turn off the e-bike, wait a few seconds, and then turn it back on. If the data does not synchronize even after several minutes, make sure you are in an open area with signal coverage.
  • Page 7 STEP 7: SpeedBox Tracker App The transport mode is designed to disable route recording when transporting the e-bike, for example, by car or by air. Once activated, the transport mode will turn on during the next synchronization of the Tracker with the server. When the e-bike is turned on (powering the Tracker), the transport mode will be deactivated.
  • Page 8 Ebike Electronic s.r.o. Rybna 716/24 | 110 00 Praha 1 | Czech Republic | ID: 05553555 | VAT: CZ05553555...
