Model# BRD051KDFR3084 BRD051KDFR3684
BRD051KDFR4284
Sku# 1011923914 1011923913 1011923912
USE AND CARE GUIDE
3/6 - Lite Panel
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m.- 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this barn door kit. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection BRD051KDFR3084
Summary of Contents for Home Decorators Collection BRD051KDFR3084
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this barn door kit. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........Pre-Installation . -
Page 3: Warranty
This warranty does not cover any labor costs incurred in removing, relocating, or replacing defective products or parts of these products. In the event of a defect, malfunction, or other failure of the product covered by the warranty, Home Decorators Collection will replace, or repair the defect for free within ninety (90) days of receipt of the product, or refund the purchase price to his sole discretion. -
Page 4: Pre-Installation
Pre-Installation Assembly Diagram Hardware List NOTE: Hardware not shown to actual size. x16 pcs... -
Page 5: Installation
Installation HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance. - Page 6 Installation (continued)
- Page 7 Installation (continued) HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 8 Installation (continued)
- Page 9 Installation (continued) HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 10 Installation (continued)
- Page 11 Pre-Installation Cut Out Acorn Nut Protectors For Step 1 Cut here Cut here CUT OUT TEMPLATE & PLACE OVER ACORN NUT TO PROTECT METAL SURFACE OF BARN DOOR For back of door For front of door HARDWARE Cut Out Handle Installation Template For Step 4 Cut here 4 ½"...
- Page 12 Pre-Installation TOOLS REQUIRED (NOT PROVIDED)
- Page 13 Installation Install The Hanger Straps □ Securing the Hanger Strap hardware to the door Determine the front side From the back of the Repeat above Steps A of the door by the door, insert Strap Bolts and B for the second texture of the glass and Washers.
- Page 14 Installation(continued) Installing the Anti-Jump Blocks on the door Outward 1/2" Door Front Rotate the blocks Screws should be Affix an Anti-Jump tightened just enough outward (towards the Block and screw into to hold the anti-jump front of door) to allow the pre drilled holes from spinning freely, but the door to be mounted...
- Page 15 Installation(continued) Pick Your Door Opening Location □ Determine what direction your door will be opening A) Door opens to the right B ) Door opens to the left These instructions will focus on right opening doors For this application work from the left jamb Open Open Door...
- Page 16 Installation(continued) Install The Handle Determine which direction your □ Template available below door will be opening. If your door opens to the right, your handle will be installed on the left side. If your door opens to the left, your handle will be Installing the Handle on the Barn Door installed on the right side as per the image.
- Page 17 Installation(continued) Check For Level Floor □ Use a Level to check if your floor is uneven before making measurements □ Select the highest point on the floor and measure up 85-3/4" from that point □ Make a light pencil X mark on the wall Height of door plus 1 "...
- Page 18 Installation(continued) Measure And Center The Track Location Onto The Wall □ Mark track location Once you determine which side of the opening your door will open to, measure 1 / " (4.45 cm) to the right and mark your center point Track 40 "...
- Page 19 Installation(continued) Locate And Mark The Studs And Header Use a stud finder to Stud Locations locate and mark the center and edges of each stud and mark with an Stud Stud Stud Stud Stud Stud edges "X", as well as the top of edges edges edges...
- Page 20 Installation(continued) Affixing Track Center Note: The Stanchion should be oriented as shown between With Lag Screw □ the track and the wall with the flange of the Stanchion Track Center Stud Hole against the wall. Track Center Stanchion into the stud center hole with a Lag Screw, Washer and Stanchion supplied, but do not fully tighten at this time.
- Page 21 Installation(continued) Place Door On Track Lift, Tilt, Rest With Lag Screw □ Lock Rotate the Anti-Jump Blocks to the open position Open (Towards the door front). Hang the door onto the track and lock Anti-Jump Blocks. Finish Affixing The Track To The Wall Finish affixing the trackt o the wall with the appropriate remaining Anchor Hole...
- Page 22 Installation(continued) IInstalling the Door Guide Note : These 2 rollers can be separately install/take out from the foor guide. You can freely choose the setups you like to fit your doors.These rollers are UNNECESSARY to always be installed together.
- Page 23 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m.- 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
