- Page 1 Home Decorators Collection BF-22419 OXFORD COLLECTION TWO DRAWER END TABLE ASSEMBLY INSTRUCTIONS Made In China...
-
Page 2: Important Note
Thank you purchasing this quality produst.Be sure to check all packing material carefully for small parts,which may have came loose inside the carton during shipment. Count all parts and material hardware,Compare with parts list to be sure all part are present.If any parts are missing or damaged,phone,fax,or mail to our Customer Service Department.For efficient and speedy service please indicate the model number and code letter of part(s)need... - Page 3 CAM-BOLTS-12PCS SCREWS-14PCS DOWELS-8PCS SCREWS-1PC CAM-TOOL-1PC SCREWS-3PCS KNOB-3PCS SCREWS-26PCS REAR PANEL GUIDE-1PC...
- Page 4 NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES TO REMOVE DUST AND DIRT THAT MAY HAVE SETTLED ONTO FINISH DURING SHIPMENT.IN ORDER TO PREVENT DAMAGE DURING ASSEMBLY,PLEASE ASSEMBLE THIS ITEM WITH AT LEAST TWO PEOPLE. NOTE: TURN THE CAM-BOLT SCREWS UNTIL THEY ARE TIGHT, THE SHOULDER SHOULD BE AGAINST THE SURFACE OF THE PART.
- Page 5 ASSEMBLE DRAWER ATTACH DRAWER SIDE PANEL(K/L)TO FRONT DRAWER PANEL(H)USING SCREWS(T). ATTACH KNOB(S)TO FRONT DRAWER PANEL(H) USING SCREWS(T). INSERT THE BASE PANEL(J)INTO SLOT IN SIDE DRAWER PANEL. ATTACH DRAWER BACK PANEL(I)TO SIDE PANEL(K/L)USING SCREWS(T).
- Page 6 ASSEMBLE SIDE PANEL(B/C). ATTACH THE LOW PANEL(G)TO BOTTOM PANEL(D)USING SCREWS(R). INSERT THE 8 DOWELS(P)INTO HOLES IN ACROSS PANEL(F)AND LOW PANEL(G). ROTATE THE CAM-BOLTS(N)INTO HOLES IN SIDE PANEL(B/C). PLACE CAM-BOLTS(N)INTO HOLES IN PANEL(F/D)AND ATTACH USING CAM-LOCKS(M).
- Page 7 ASSEMBLE THE TOP PANEL(A). ROTATE THE 4 CAM-BOLTS(N)INTO HOLES IN TOP PANEL(A). PLACE CAM-BOLTS(N)INTO HOLES IN SIDE PANEL(B/C)AND ATTACH USING 4 CAM-LOCKS(M).
- Page 8 ASSEMBLE THE DRAWERS. PUSH THE 3 DRAWER IN TO SLIDE-OUTS.
- Page 9 ASSEMBLE THE BACK PANEL(E). INSERT THE BACK PANEL(E)INTO SLOTS IN REAR PANEL GUIDE(V). ATTACH THE BACK PANEL(E)AND REAR PANEL GUIDE(V)USING SCREWS(O/T).
