NLB-RH+T-MRF |
NLB-RH+T-MRF is a wireless room sensor and
is intended for continuous monitoring of
indoor air quality and for effective control of
ventilation (HVAC) systems according to the
current air quality. The sensor monitors
relative humidity (RH) and air temperature
(T). It is used in households, offices,
schoolrooms, shopping centers, restaurants,
fitness centers, commercial buildings, etc.

Monitors RH a T

Wireless communication with a receiver

Battery powered

Easy installation

Maintenance during operation is not
required

Long battery lifetime
Description
Measurement of the relative humidity is based on the
principle of capacitive polymer sensor.
Measurement of relative humidity and temperature
are available on the receiver either via RS485 serial
interface with Modbus communication or via two
analog outputs.
The sensor efficiently controls ventilation systems,
based on current room air quality.
Low battery power is indicated by a built in LED
indicator.
Explanation of abbreviations and technical terms can
be found on our website in the
Protronix s.r.o., Pardubická 177, Chrudim 537 01, Czech Republic
.docx
um-nlb-rh+t-mrf-en-v1-241122
Combined battery powered RH/T MRF sensor
Glossary section.
Technical data
Parameter
Power supply - 2xAA
Battery life
RH measuring range
RH accuracy 0 – 90 %
RH accuracy 90 – 100 %
T measuring range
T accuracy
Working humidity
non condensing
Working temperature
Storage temperature
Expected lifetime
Ingress protection
Dimensions
Adjustable broadcasting
period
1)
Applies to a minimum broadcasting period of 5 minutes with
original batteries.
www.protronix.cz www.careforair.eu
User manual
Value Unit
1,5 V
1)
36 months
0 – 100 % RH
± 5 % RH
± 6 % RH
0 – 50 °C
± 0,45 °C
0 – 95 % RH
0 to +50 °C
-20 to +60 °C
min. 10 years
IP20
90x80x31 mm
1 to 35 minutes
