PROTRONIX NLB-CO2+RH+T-5-MRF User Manual

NLB-CO2+RH+T-5-MRF |
The NLB-CO2+RH+T-5-MRF is a wireless room
sensor and is intended for continuous
monitoring of indoor air quality and for
effective control of ventilation (HVAC)
systems according to the current air quality.
The sensor monitors the concentration of
carbon dioxide (CO ), relative humidity (RH)
2
and air temperature (T). It is used in
households, offices, schoolrooms, shopping
centers, restaurants, fitness centers,
commercial buildings, etc. for efficient control
of ventilation systems.

Monitors CO , RH and T
2

Wireless communication with a receiver

Battery powered

Easy installation

Maintenance during operation is not
required

Long battery lifetime
Description
The measuring of CO is based on an optical principle
2
(NDIR) using advanced optical chamber. Built-in auto-
calibration function ensures excellent long term
stability and accuracy.
Measurement of the relative humidity is based on the
principle of capacitive polymer sensor.
Individual quantities (CO
2
receiver either via RS485 serial interface with Modbus
communication or via two analog outputs (CO
RH).
The sensor efficiently controls ventilation systems,
based on current room air quality.
Low battery power is indicated by a built in LED
indicator.
Explanation of abbreviations and technical terms can
be found on our website in the
Protronix s.r.o., Pardubická 177, Chrudim 537 01, Czech Republic
um-nlb-co2+rh+t-5-mrf-en-v10-221214
Combined battery powered CO
, RH, T) are available on the
and
2
Glossary section.
.docx
Technical data
Parameter
Power supply - 2xAA
Battery life
CO measuring range
2
CO accuracy
2
RH measuring range
RH accuracy 0 – 90 %
RH accuracy 90 – 100 %
T measuring range
T accuracy
Working humidity
non condensing
Working temperature
Storage temperature
Expected lifetime
Ingress protection
Dimensions
Adjustable broadcasting
period
1)
Applies to a minimum broadcasting period of 5 minutes with
original batteries.
2)
Range up to 5000 ppm CO
2
www.protronix.cz www.careforair.eu
User manual
/RH/T MRF sensor
2
Value Unit
1,5 V
1)
24 months
2)
400 – 2000/5000 ppm
± 35 ppm ±5 % of reading
0 – 100 % RH
± 5 % RH
± 6 % RH
0 – 50 °C
± 0,45 °C
0 – 95 % RH
0 to +50 °C
-20 to +60 °C
min. 10 years
IP20
90x80x31 mm
1 to 35 minutes
is available only via serial interface.
1/3
