Indesit BTW S50400 EU/N Quick Start Manual

Quick guide
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
CONTROL PANEL
1
Programme selector
2
"Start/Pause" button
3
"Reset/Drain" button
4
Programme sequence indication
5
"Start delay" button
6
"Spin speed" button
7
Time indication
PROGRAMME CHART
Power consumption in off-mode 0,11 W / in left-on mode 0,11 W
Programme
Turn & Go
Sintetici
Cotone
Eco 40-60
Eco 40-60
20 °C
20°C
Wool 20°
20°
Delicates 30°
30°
Mix 45' 40°
40°
Cotton 30°
30°
Synthetics 30°
30°
Spin + Drain
Rinse + Spin
 Dosing required  Dosing optional
Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most efficient
programme in terms of energy and water consumption for washing normally soiled cotton
laundry. Display only: Spin speed values shown on the display can slightly differs from the
values stated in the table.
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
This data may differ in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options. The values given for programmes other than the eco 40-60
programme are indicative only.
PRODUCT DESCRIPTION
1. Lid handle
2. Lid
3. Control panel
4. Detergent dispenser
5. Drum
6. Water filter - behind the cover
7. Mobility lever (depending on model)
8. Adjustable feet (x2)
7
5 6
Max load 5,0 Kg
Temperatures
Max, spin
speed (rpm)
Setting Range
30°C 30°C 1000
40°C 40°C 1000
60°C 40°-90°C 1000
951
40°C 40°C 951
951
20°C 20°C 1000
20°C 20°C 1000
30°C 30°C 1000
40°C 40°C 1000
30°C 30°C 1000
30°C 30°C 1000
– – 1000
– – 1000
3.
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bracket is removed.
For more detailed instructions on how to remove it, see the Installation Guide.
4
1
Detergents and additives
Pre- Main
Max Dura-
wash wash
load tion
(kg) (h : m)
3,5 ** –

3,0 2:15
 
5,0 2:40
 
5,0 3:05 –

2,5 2:30 –

1,5 2:30 –

5,0 3:05 –

1,0 ** –

1,5 ** –

5,0 ** –

3,0 0:30 –

3,0 ** –

5,0 – –
5,0 – –
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the programme is shown on the display.
The sensor technology adapts water, energy and programme duration to your wash load.
DETERGENT DISPENSER
1.
Main wash compartment
Detergent for the main wash, stain remover or
2.
water softener.
4.
Prewash compartment
Detergent for the prewash.
5.
Softener compartment
Fabric softener. Liquid starch. Bleach.
Pour in softener, starch or bleach solution
only up to the "max" mark.
Release button
Press to remove tray for cleaning.
6.
7.
8.
INDICATORS
Door locked
Failure: Service
3
Failure: Clean filter
Failure: Water tap closed
In the event of any failure, refer to the
"TROUBLESHOOTING" section
2
Recommended
detergent
Softener
Pow-
Liquid
der
–
 
  
  
  
  
  
–
 
–
 
–
 
  
–
 
–
 
– – – –
– – –


EN
– – – –
47 0,630 40 40
64 0,950 46 55
60 0,611 45 34
62 0,411 36 31
66 0,455 36 32
62 0,250 46 20
– – – –
– – – –
– – – –
66 0,250 42 26
– – – –
– – – –
– – – –

