- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 109351(B1&B2) Dining Table REVISION 0 : 08/26/2024 COASTERFURNITURE.COM PAGE 1 OF 4...
- Page 2 B1 (BOX 1) MOUNTING PLATE 4PCS (ATTACHED TO TOP) B2 (BOX 2) 4PCS HARDWARE IDENTIFICATION Z-B1(BOX 1) - HARDWARE PACK IS LOCATED IN 109351(B1) ALLEN WRENCH (M4 x 100mm - BLK) BOLT 16PCS (M6 x 25mm - BLK) LOCK WASHER...
- Page 3 109351(B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Attention! Please remove part B and all hardware from TOP (A), using ALLEN WRENCH (1) and keep for STEP 3. BOLT (M6 x 25mm) OPEN LOCK WASHER (M6) FLAT WASHER (M6) STEP 2 PAGE 3 OF 4...
- Page 4 109351(B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 3 Attention! Use hardware from STEP 1 for this STEP. BOLT (M6 x 25mm) LOCK WASHER (M6) FLAT WASHER (M6) STEP 4 STEP 5 COMPLETE PAGE 4 OF 4 COASTERFURNITURE.COM...
- Page 5 109351(B1&B2) ITEM: 70.75" 39.25" 30.50" 29.00" 30.00" 61.75" 70.75" 39.25" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
