Summary of Contents for Outsunny GH301
- Page 1 IN230500408V01_UK 842-189V01BK GAS FIREPIT IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY INSTRUCTION MANUAL...
- Page 2 Dear customer, Thank you for purchasing this product. So that your appliance serves you well, please read all the instructions in this user's manual. If you have any questions, please contact our customer care center. Our contact details are below: Country Phone Email...
- Page 3 842-189V01BK (GH301) 9.0kW Butane/Propane/LPG Gas Mixtures 1.46mm 1.27mm 0063DL7313 0063-23 For outdoors and well ventilated areas use. The use of this appliance in enclosed areas can be dangerous and is PROHIBITED. A well ventilated area must have a minimum of 25% of the surface area open.
- Page 4 WARNING PLEASE READ CAREFULLY THE FOLLOWING SAFETY GUIDELINES BEFORE OPERATION. FOR INSTALLATION AND USE, PLEASE READ THIS MANUAL CAREFULLY. REPAIRS SHOULD BE DONE BY A QUALIFIED SERVICE PERSON ONLY. KEEP THE MANUAL FOR FUTURE USE. The user assumes all risk in the assembly and operation of the gas heater. Failure to follow the warnings and instructions in this manual can result in severe personal injury, death or property damage.
- Page 5 Control compartment, burner and circulation air passageways of the heater must be kept clean.Frequent cleaning may be required as necessary. The LP tank should be turned off when the heater is not in use. Check the heater immediately if any of the following occurs: - The heater does not reach temperature.
- Page 6 ATTENTION Never use the heater while it is raining, the glass tube would break when it suddenly met water. Always turn off the heater while there is a rain. Never splash any liquid to the glass tube when the heater is working. The glass will be extremely hot when it is working.
- Page 8 Cover Plate Glass Clip Glass Glass Bracket Lava Stone Firebowl Assem Left Panel Door Rear Panel Magnet Right Panel Bottom Panel Lock Caster Caster Regulator Kit Screw (M5X18) Screw (M6X10) Screw (M5X15) Screw (M4X10) M4 Nut...
- Page 9 M6x10 M4x10 M4 Nut M6x10...
- Page 10 M6X10 M6X10...
- Page 11 M5X15 M5X15...
- Page 12 Install glass piece by piece. Ask for assistant to hold the glass during installing to avoid falling down. M5x18 M5X18...
- Page 13 M6x10...
- Page 15 Insert the hose into firepit connector Fix the hose clip Warning !!! Identify any leaks after assemble & before use ! ( Refer to Leak Test Instruction, Page 15 ) Below connection are the parts which must test the leakage.
-
Page 16: Gas Requirements
HEATERS STAND AND LOCATION The heater is primarily for outdoor use only. Always ensure that adequate fresh air ventilation is provided. Always maintain proper clearance to combustible materials, i.e. top 45cm (18'') and sides 70cm (28”) minimum Heater must be placed on level firm ground. Never operate heater in an explosive atmosphere like areas where gasoline or other flammable liquids or vapors are stored. -
Page 17: Gas Cylinder
CYLINDER, REGULATOR&HOSE This appliance is only suitable for use with low-pressure butane or propane gas and fitted with the appropriate low-pressure regulator via a flexible hose. The hose should be secured to the regulator and the appliance with hose clips or nut. This barbecue is set to operate a 28 mbar regulator with butane gas and a 37mbar regulator with propane gas and a regulator with butane/propane mixture at 37mbar and a regulator with butane/propane mixture at 50mbar and a regulator with butane/propane mixture at 30mbar. -
Page 18: Cleaning And Maintenance
FUEL GAS ODOR LP gas and natural gas have manmade odorants added specifically for detection of fuel gas leaks. If a gas leak occurs you should be able to smell the fuel gas. Since Propane (LP) is heavier than air you should smell for the gas odor low to the floor. ANY GAS ODOR IS YOUR SIGNAL TO GO INTO IMMEDIATE ACTION! Do not take any action that cloud ignite the fuel gas. - Page 19 Air flow must be unobstructed. Keep controls. Burner and circulating air passageways clean. Signs of possible blockage include: --Heater does NOT reach the desired temperature. --Heater glow is excessively uneven. --Heater makes popping noises. Spider and insects can nest in burner orifices. The dangerous condition can damage heater and render it unsafe for use.
- Page 20 CLAUSE SHOOTING Problem Problem cause Solution Pilot will not light Gas valve may be OFF Turn the gas valve ON Tank fuel empty Refill LPG tank Opening blocked Clean or replace opening Air in supply system Purge air from lines Loose connection Check all fittings Pilot will not stay on...
