BulletCam is an IP camera with a smart infrared (IR) backlight and an object
recognition function. The user can view archived and live videos in the Ajax apps.
To store the captured data, install a microSD card or connect the camera to
with an installed hard disk.
The camera is connected to the network via Ethernet, using the appropriate
connector.
The camera is available in several versions:
BulletCam (5 Mp/2.8 mm);
BulletCam (5 Mp/4 mm);
BulletCam (8 Mp/2.8 mm);
BulletCam (8 Mp/4 mm).
BulletCam user manual
Updated October 31, 2024
NVR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BulletCam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX Systems BulletCam

Summary of Contents for AJAX Systems BulletCam

  • Page 1 BulletCam user manual Updated October 31, 2024 BulletCam is an IP camera with a smart infrared (IR) backlight and an object recognition function. The user can view archived and live videos in the Ajax apps. To store the captured data, install a microSD card or connect the camera to with an installed hard disk.

  • Page 2: Functional Elements

    Buy BulletCam Camera versions with other enclosures are also available. All Ajax cameras are available here Functional elements 1. Swivel mounting bracket. 2. Protective cover. 3. Screw for fixing camera position. 4. Slot for microSD card. 5. Reset button. . Microphone.

  • Page 3: Operating Principle

    10. Cable channel for routing the cable connector from the camera. 11. Cable connector. 12. QR code with the device ID. Used to add BulletCam to an Ajax system. 13. Holes for attaching the camera to the surface. Operating principle BulletCam is an IP camera that uses artificial intelligence (AI) for object...

  • Page 4: Video Wall

    Create video scenarios that send a short video from the selected camera to the Ajax app when the security detector is triggered. How to export video in PRO Desktop How to configure temporary camera video access Video scenarios The Ajax system offers the capability to use IP cameras for alarm verification. Video scenarios enable the substantiation of alarm triggers with corresponding video from cameras installed at the facility.

  • Page 5: Privacy Zones

    . Change the order in which the camera video is displayed. Create templates for displaying videos in a slideshow What keyboard shortcuts are available in PRO Desktop Privacy zones The system allows hiding parts of the frame. For instance, if a safe is in view, activity around it can be recorded without revealing its contents by setting up the right zone.

  • Page 6: Selecting The Installation Site

    The user can create up to four private zones. Selecting the installation site When choosing the optimal location to install BulletCam, consider the camera’s viewing angle and any potential obstacles that might obstruct its view. How to install an Ajax camera for better AI recognition Consider the placement recommendations when designing the security system project for your object.
  • Page 7 2. Using the mounting template, mark the locations for the drill holes on the surface where you plan to mount the camera. Secure the template to the chosen installation location with tape, and drill four holes as indicated on the template.

  • Page 8: Adding To The System

    . Ensure that the camera lens faces the protected area. Secure it by tightening the screw in the swivel mounting bracket. 7. Connect the Ethernet cable to the camera. If it is powered by PoE, no external power supply is needed; otherwise, connect both the external power supply and the Ethernet cable.
  • Page 9 The icons in the app display some device states. To access them: 1. Select a space in the Ajax app. 2. Go to the Devices tab. 3. Find BulletCam in the list. Icon Value Live view is available. Live view is not available.
  • Page 10 1. Select a space in the Ajax app. 2. Go to the Devices tab. 3. Select BulletCam from the list of devices. If BulletCam is connected to the video recorder, select NVR and then click Cameras. Parameter Value Firmware update...
  • Page 11 Downloading… — the firmware downloading is in progress. Shown in percentages. Installing… — the firmware installation is in progress. The camera connection status to the internet via Ethernet: Online — the camera is connected to the network. Normal state. Connection Offline —...
  • Page 12 Clicking the icon displays the recording mode and storage settings. The memory card connection status to the camera: OK — the memory card is communicating with the camera. Normal state. Error — there is an error in the memory card operation.
  • Page 13 To change camera settings, in an Ajax app: 1. Go to the Devices tab. 2. Select BulletCam from the list. If BulletCam is connected to the video recorder, select NVR and click Cameras. 3. Go to Settings by clicking on the gear icon...
  • Page 14 5. Click Back to save the new settings. Settings Value Camera name. Displayed in the list of devices, SMS text, and notifications in the events feed. To change the camera name, click on the text Name field. The name can contain up to 12 Cyrillic characters or up to 24 Latin characters.
  • Page 15 received. Available options: Human; Pet; Vehicle; Any motion. You can also configure Interval in reporting similar events and select the armed mode that triggers the notifications. Available options: When camera armed; Always. The Notifications from camera detectors feature is available if the Video alerts option is enabled in space settings Camera settings When the Motion detector toggle is enabled, the...
  • Page 16 Allows the user to customize the display of additional information on the camera image: Camera name; On-screen display (OSD) progress) Timestamp; Parameters of the displayed text. Settings for audio capture and playback. Audio capture and playback — turn on to watch and record videos with audio.
  • Page 17 Allows the user to describe a problem and send a Report a problem report. User guide Opens the camera user manual. Unpairs BulletCam from the space and all NVR Delete device where it’s added. Indication The green LED indicator is placed on the cable connector.

  • Page 18: Maintenance

    Lights up green. connected to the internet. Malfunction When a BulletCam malfunction is detected, the Ajax app displays a malfunction counter on the device icon. All malfunctions are indicated in the camera States Fields with malfunctions will be highlighted in red.

  • Page 19: Warranty

    Technical specifications for BulletCam (8 Mp/4 mm) Compliance with standards Warranty Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the date of purchase. If you encounter any issues with the device’s functionality, we recommend contacting Ajax Technical Support first.
