Vornado AC350 Owner's Manual

Vornado AC350 Owner's Manual

Whole room air purifier
Hide thumbs Also See for AC350:
Table of Contents

Advertisement

Quick Links

Download this manual
model AC350
WHOLE ROOM AIR PURIFIER
OWNER'S GUIDE
vornado.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vornado AC350

Summary of Contents for Vornado AC350

  • Page 1 AC350 WHOLE ROOM AIR PURIFIER OWNER’S GUIDE vornado.com...
  • Page 2 We expect this If it is not, we product to be will make it perfect. right. vornado.com 800-234-0604 help@vornado.com 2 English...

  • Page 3: Table Of Contents

    CONTENTS Important Safety Instructions ..........4 Storage ................... 14 Product Information ..............7 Cleaning and Maintenance ............ 15 Control Panel ................8 Troubleshooting ..............16 User Tips ................10 Warranty ................. 17 True HEPA Filtration ............... 11 Automatic Filter Refill Program ..........11 Filter Replacement ..............

  • Page 4: Important Safety Instructions

    See www.vornado.com to view, download and print - Do not use this product outdoors or expose it to weather the most current version of this owner’s guide.
  • Page 5 Do not use gasoline, thinners, solvents, ammonias and parts replacement, visit vornado.com/support or contact or other chemicals for cleaning. Refer to the CLEANING Vornado Consumer Service by phone (1-800-234-0604) or email instructions provided. WARNING: To Reduce The Risk Of Fire, Electric Shock Or Injury (consumerservice@vornado.com).
  • Page 6 - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Contact Vornado Consumer Service or the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate...

  • Page 7: Product Information

    PRODUCT INFORMATION FRONT PANEL PLASTIC SUPPORT FILTER FRAME The frame secures both Carbon and HEPA filters in place. CARBON FILTER Captures larger initial particles and odors passing through the unit. HEPA FILTER Captures 99.97% of particles 0.3 microns or larger pass- ing through the unit, allowing only filtered air back into the environment.

  • Page 8: Control Panel

    CONTROL PANEL POWER CARBON FILTER HEPA FILTER REPLACEMENT REPLACEMENT FAN SPEED 8 English...
  • Page 9 CONTROL PANEL Power, Function ON and OFF by pressing the Power button. Note: User environments will differ. The filter replacement time is based on average use situations, if you are using Fan Speed, 3 fan speed settings to meet any need. Select the air cleaner in a more demanding environment, you Low, Medium, or High by pressing the Power button until may need to change your filter more frequently.

  • Page 10: User Tips

    USER TIPS 1. Keep retail carton to store unit when not in use. 2. Use the hand holds on either side of the unit for easy carrying. 3. For best results, position the front of the unit (side with logo) towards the center of the room, leaving at least a 6 inch distance away from walls or furniture on every side.

  • Page 11: True Hepa Filtration

    A convenient and hassle-free way to recieve regular shipments Filter will not achieve their full filtration potential. Gaps, poorly of Vornado Filters, direct to your door. Eliminate the hassle sealed filter housings, and excessive air velocity all reduce the of remembering to reorder. Maintain the high efficiency effectiveness of the product.

  • Page 12: Filter Replacement

    HEPA filters are used. Others may claim to be compatible with magnets. Vornado units, but the Vornado Air Purifier is calibrated to achieve a 99.97% capture rate of particles 0.3 microns or larger, only when used 3. Remove the Plastic Support Filter Frame by pulling on the center with Vornado Filters.
  • Page 13 HEPA Filter, take hold of the tab (Figure 1) and pull to release. Frame to secure the top 2 tabs into the top slots (A). Replace with genuine Vornado Filters. Place the Filters in the unit and gently press around the perimeter of the Filter to ensure se- cure placement (Figure 2).

  • Page 14: Storage

    Front Panel in place. seconds. The light will turn off confirming the indicator is reset. ± Press for 3 seconds Note: Do not operate the Air Purifier without Vornado Carbon and Vornado HEPA Filters in place. ± STORAGE Follow the steps listed below when you are ready to store your unit.

  • Page 15: Cleaning And Maintenance

    CLEANING AND MAINTENANCE HOW TO CLEAN Because large volumes of air pass through your Vornado Air Purifier each day, it will need regular cleaning. 1. Unplug the unit before cleaning. Note: Do not use gasoline, thinners, solvents or other chemicals for cleaning.

  • Page 16: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE AND SOLUTION Unit fails to power on. Unit is not plugged in. Plug power cord into electrical outlet. Front Panel may not be properly installed. Remove and reinstall the Front Panel to assure proper placement. Refer to FILTER REPLACEMENT. Household circuit breaker / ground fault interrupter has tripped or blown a fuse.

  • Page 17: Warranty

    PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS within the warranty period, Vornado, at its discretion, will repair or replace the Product at WARRANTY. Some states do not allow the exclusion or limitation of incidental or conse- no cost.
  • Page 18 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | vornado.com CL3-0223 RC, V01...
