- Page 1 Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 2 BEFORE YOU START We understand that installing a True Handleless kitchen is a little more complicated than a standard kitchen. It is important to fully read through these guides fully to understand the fitting requirements and notes.
-
Page 3: Profiles Overview
● Vertical End Profile 8023 is used when a "Double Handle Opening" is when a "Single Handle Opening" is required when 2x opening doors meet. required on a single unit. 8023 8024 Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024... -
Page 4: Unit Dimensions
● Set the plinth height from the "planned position" of the Integrated Appliance. ● If the floor is out, a suitable packer will be required under the legs (not supplied). ● True Handleless Plinths are supplied at 160mm H. 35mm WALL OFFSET ●... - Page 5 ● To adjust, simply turn the piston required between the clockwise for an inwards adjustment cabinet and door for the and anti-clockwise for an outwards piston to action . adjustment. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 6 Horizontal Drawer Profile GG8006 SU136DS59 Linear Junction Fixing Blocks - Horizontal Profiles Horizontal Worktop Profile Dowel Fixing CSP0149-01SF 712.63.511 Mechanical Fastener Fixing Blocks - Horizontal Profiles Aluminium Front Rail Screw Fixing Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 7 820 H Wood-Glue for a waterproof finish. INTEGRATED PANEL APPLIANCE PLINTH CUT OUTS ● Seal Plinth cut-outs using a suitable Silicone or PVA Wood Glue for a waterproof finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 8 (4x blocks supplied with each profile) (4x blocks supplied with each profile) ● The Oven Filler Profile 1275 fits onto the Vertical Profile. It is used 1275 to hide the Appliance Screw-fixings. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 9 2x Tall Unit Run 3x Tall Unit Run Pull-Out Tall Units with 8023 Vertical End Profiles 3x Tall Units run with Pull-Out in the middle (Both LH & RH Sides are reduced). Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
-
Page 10: Profile Cutting
Spray with WD40 to give a better cut. COLOUR REFERENCES Brass - BRS Black - BLK Silver - SLV Copper - CPR Anthracite -ANT (S2Q) (V12) (S2R) (50S) (V52) Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024... - Page 11 Horizontal Worktop Profiles are cut-outs and any exposed fitted using the Fixing Bocks edges are sealed using a SU136. suitable silicone or PVA Wood Glue for a waterproof finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 12 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 13 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 14 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 15 Simply slot onto the rail and screw the two pieces together. This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 16 We recommend the handleless cut-outs and any exposed edges are sealed using a suitable silicone or PVA Wood Glue for a waterproof finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 17 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 18 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 19 Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 20 MEASURE TWICE BEFORE CUTTING. Cut using a circular chop saw with a metal blade. CUTTING Plan cuts to avoid errors. Check squareness with a test cut. Debur profile edges to ensure good fit. Always wear hand and eye protection. HOW TO FIT Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 21 4x Fixing Blocks are supplied with each Vertical Profile as standard. Screw fix Fixing Blocks to the adjacent full depth cabinet/ full depth end panel and then into the reduced cabinet end. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 22 4x Fixing Blocks are supplied with each Vertical Profile as standard. Screw fix Fixing Blocks to the adjacent full depth cabinet/ full depth end panel and then into the reduced cabinet end. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 23 2x Oven Fillers are required for Filler Profile to the inside the every Double Oven Aperture. Cabinet End Panel. This part has a lacquered finish that may vary slightly from the profile finish. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 24 Fastens the Front Rail to the Worktop. Simply clip-insert the worktop fixing plate into the rear top edge channel of the front rail and slide along to the desired position. PART FITTING LOCATION Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 25 ● Used with External Corner Joints SG8006 & SG8007. Below: A Plan View of the fitted ECP and return panel shown with the fitted Horizontal Profiles and External Corner Joints. The end gap will be approximately 8mm. Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
- Page 26 Unwind the Space-Plug until it firmly contacts both surfaces. Use a suitable wall packer if the off-set is greater than 35mm. Step 4 Tighten The Screw FOR A STRONG SECURE FIX Diagrams are for illustrative purposes only. TRUE HANDLELESS FITTING GUIDE 2024...
