- Page 1 USER MANUAL Aquarius 2S...
- Page 2 Handheld remote / Set sticker Receiver sticker English Deutsch Français Table of contents Inhaltsverzeichnis Table des matières • Introduction • Introduction • Einleitung • Sicherheit • Sécurité • Safety • Abmessungen und Gewicht • Dimensions et poids • Dimensions & weight •...
- Page 3 Introduction Please read all instructions in this manual carefully before use These operating instructions are intended for the technician and the end user. The operating instructions depend on the application, for which the end user is responsible. Keep these operating instructions carefully. Pass on all documents if the product is given to third parties.
- Page 4 Safety Caution: danger of injury or property damage! To avoid dangerous situations, always observe the following rules: In case of deviation, ambiguity or doubt about the rules below, always contact Tyro Remotes. Check before use Always check before use that all keys and (emergency) stop button* function properly (*if present). The operator must have a view of the hazard area at all times.
- Page 5 Receiver dimensions & weight Aquarius 2S - 6F / 10F Aquarius 2S - 20F Weight: 480 gram / 1.05 lbs Weight: 900 gram / 1.98 lbs...
-
Page 6: Receiver Description
Receiver description Aquarius 2S *Actual receiver may differ Physical characteristics: Antenna Connection cable(s) Status-LED • 6F / 10F 1x connection cable Identi昀椀cation sticker • 20F 2x connection cables Fuse holder Mounting holes Ø6mm Pairing button Receiver speci昀椀cations Aquarius 2S - Technical speci昀椀cations Frequency 434 MHz 915 MHz... -
Page 7: Receiver Features
Receiver features Antenna SMA antenna. The color ring on the antenna indicates the frequency. • Red: 434 MHz • Yellow: 915 MHz • Pink: 2.4 GHz Status-LED The Status LED on the Aquarius is a duo LED that can light up red or yellow for various indications. Status-LED functionality Transmit indicator If a key is pressed, with active handheld transmitter... -
Page 8: Receiver Functions
Receiver functions Function key con昀椀guration The characteristics of the function keys can be con昀椀gured in two ways: • Function key operation: momentary or latching • Function key blocking: horizontal or vertical key lock, freely adjustable The con昀椀guration can be at the default settings or set at the factory to a customer-speci昀椀c con昀椀guration. A con昀椀guration can be changed by the user as desired or reset to the default settings via the handheld transmitter. - Page 9 Safety package • Not applicable to the Aquarius 2S...
- Page 10 System identi昀椀cation Identi昀椀cation via sticker The system can be identi昀椀ed by an identi昀椀cation sticker on the receiver. The actual position of the sticker varies by product type. The 昀椀gure below explains the contents of the handheld transmitter identi昀椀cation sticker. Set sticker When the system is part of a complete set, consisting of a handheld transmitter and a receiver, a set sticker is also generated.The set sticker can be found on the box and optionally in the front of the manual.
- Page 11 QR code explanation On the identi昀椀cation sticker is a scannable QR code. This code displays the relevant information about the system. For each product, this QR code is uniquely generated based on the system properties. QR code in this example can be scanned to show a generic sample of the content Example QR string When the QR is scanned, a code string becomes visible.
- Page 12 Pairing a handheld transmitter to the receiver Please note that all systems are already paired at the factory! This part can be skipped unless an additional or replacement handheld transmitter needs to be paired on to the receiver! Note: check primary/secondary setting! Check that the system is correctly con昀椀gured with the correct Primary / Secondary settings.
- Page 13 Delete memory To clear the memory of the handheld transmitter and/or receiver follow these steps: Delete memory (receiver) The following steps apply to all receivers: Locate the black pairing button on the bottom of the receiver. Press and hold the pairing button for 8 seconds. The status-LED will light yellow continuously.
-
Page 14: Changing Functions
Changing functions From the factory, the system is set to momentary mode with horizontal function key lock active (see Table 2). To change functionality, a transmitter must 昀椀rst be programmed on the receiver. In a complete set, this is done at the factory. With the following steps the functions can be changed. - Page 15 Out-of-range protection (N/A for Musca 2S and ISO 13849-1 certi昀椀ed systems) Enable out-of-range protection Press the ON-key and function key 1 simultaneously until the green status-LED 昀氀ashes 2x. The function changes to out of range protection enabled. Return to default settings (out of range protection off) Press the ON-key and function key 1 again simultaneously until the green status-LED 昀氀ashes 1x.
- Page 16 System assembly (standard system) Note: For customer-speci昀椀c products, the cable connection and assembly may differ Always read the customer-speci昀椀c manual, if applicable. Note: The receiver must always be connected after a main fuse (10A) from the power source! The location of the receiver is very important for the range, so please consider the points described in section 'Range Optimization'. See also http://www.tyroremotes.com/tyropedia for more range information.
- Page 17 Range optimization The location of the receiver is very important for the range, therefore take into account the points below to optimize the range of your system: • Place multiple receivers at least 50 cm apart. • Never place the receiver or antenna directly against or on a metal object, at least 50cm away from it. •...
-
Page 18: Resolving Problems
Resolving problems If the system is not working properly check the following points: The receiver does not respond to a command on the handheld transmitter The receiver has no power supply. Check that the receiver is properly connected and that the fuse is intact. *Please note that not every receiver has a removable fuse. The handheld transmitter is out of range of the receiver. -
Page 19: Maintenance
Maintenance Note: This section only applies to ISO 13849-1 PL certi昀椀ed systems Maintenance Checklist To ensure that the system continues to function optimally over its lifetime, it is essential that annual maintenance will be performed. The checklist below should therefore be performed annually: Check the system annually for the items listed below: Visible damage to any of the devices, if so submit the set for repair. -
Page 20: Manufacturer Details
Cattron makes no warranties as to the absence of infringement or as to the suitability, merchantability or durability of Cattron products for speci昀椀c or general use. Cattron Holdings Inc. or its af昀椀liates or agents shall not be liable for incidental or consequential damages of any kind. -
Page 21: Declaration Of Conformity
Declaration of Conformity CE declaration V:0.1... - Page 22 V:0.1...
- Page 23 FCC statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 24 V1.0.1 VERSION M1003 ART.CODE Copyright © 2022-2024 Tyro Products B.V., The Netherlands. All rights reserved. Manufacturer: Bedrijvenpark Twente 299 +31 (0)546 588 790 Tyro Remotes 7602 KK Almelo info@tyroremotes.eu The Netherlands www.tyroremotes.eu...
