TRI tool THE TUBE SAW Quick Start Manual

Maintenance
Keep the saw clean and free from
chips when not in use. During
repeated use, ensure chip build-up
does not occur. Use a chip brush to
clear chips.
The saw bearing and gears are
greased at the factory and are not
maintenance items. There are no
components of The Tube Saw that
require user lubricating.
When the tool is to be stored or left
out of service for 30 days or more it
should be thoroughly cleaned and
wiped down.
Safety Precautions
Use standard safety equipment
such as hard hats, safety glasses,
protective clothes, and other
safety devices when appropriate.
Operate this tool only in accordance
with operating instructions. Only
personnel who are trained or are
being trained may operate the
equipment.
Do not use damaged tools.
Always check your tools for
damage especially if a tool has
malfunctioned, been dropped or
hit.
Store tools properly. Disconnect
tools from the power source, remove
blades/bits, and store in a safe place.
Use the right tool for the job.
Contact Tri Tool Technologies to
help with your application.
Notes
3041 Sunrise Blvd. • Rancho Cordova, CA 95742
+1 (916) 288-6100 • +1 (800) 345-5015
www.tritool.com
For more information on engineered solutions,
products, and trainings, visit tritool.com or
contact our engineers at +1 (916) 288-6100.
Quick Start
Guide
The Tube Saw is a table-mounted or
pipe stand-mounted OD clamping machine
designed to swiftly and easily clamp and
sever tube and pipe.
This machine uses a rotating saw blade to cut
material to length in one pass by travelling
around its perimeter.
PLUNGE
LEVER
LASER
JAW
SPINDLE
ASSEMBLY
SLIDE
ASSEMBLY
CLAMP
JAW
HANDWHEEL
ROTATION
HANDWHEEL
MOTOR
ASSEMBLY
P/N 92-2070
