DALCNET LESVECTOR SLIM-1CC-CASAMBI-LV Device Manual

FEATURES
 CASAMBI © LED DIMMER with LESVECTOR
 Power supply (DC IN): 12-24-48 Vdc
 Constant Current output (L1) for dimmable Spotlights and LED modules
 Output (LENSVECTOR) for electronically controllable LensVector© liquid crystal lenses
 WHITE and MONOCHROME Light Control
 Output dimming up to 1.6 A
 Local command: up to N°2 Normally Open (N.O.) pushbuttons
 Remote control via Bluetooth Low Energy (CASAMBI
 Device configuration via CASAMBI
Constant Current output level (via Fixture)
o
Transition Parameters (Fade)
o
 Soft ON/OFF
 Soft brightness dimming
 Extended temperature range
 100% Functional test
PRODUCT DESCRIPTION
SLIM-1CC-CASAMBI-LV is a 1-channel Constant Current (CC) modulated LED dimmer, which can be powered from a SELV constant
voltage (12 ÷ 48) Vdc power supply. This dimmer is suitable for driving loads such as Spotlight and white, single-colour, constant
current LED modules and LENSVECTOR
LED module; it can be controlled remotely via Bluetooth through the CASAMBI
pushbuttons. SLIM-1CC-CASAMBI-LV can deliver a maximum output current of 1.6 A and has the following detections and
protections: open-circuit and short-circuit internal protection, over-power and under-power protections, reverse polarity protection
and input fuse protection.
SLIM-1CC-CASAMBI-LV enables you to make not only simple brightness adjustments but also more dynamic lighting control
systems. This is made possible through the creation of multiple scenarios, animations, timers, daylight controls, and more.
Through the CASAMBI © mobile application and smartphones equipped with Bluetooth technology, it is possible to configure multiple
parameters, including maximum output current, maximum/minimum brightness levels, and dynamic beam shaping. CASAMBI
mobile application can be downloaded free of charge from the Apple APP Store and Google Play Store.
⇢ For the most up-to-date manual, please consult our website
⇢ For the correct functioning of the CASAMBI
https://support.casambi.com/support/home
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) – Italy
Via Lago di Garda, 22
SLIM-1CC-CASAMBI-LV
Device Manual
© lens driver
© mobile app)
© mobile application, parameters can be set:
© electronically controllable lens that allows dynamic shaping of the beam coming from the
www.dalcnet.com
© mobile app, consult the forum on the Casambi website:
© mobile application or locally by means two N.O.
or QR Code.
www.dalcnet.com
Rev. 14/11/2024 - Pag. 1/15
