- Page 1 TRONIC DC M45 50/12 Works with 12v Mechanical Bidirectional Radio control battery limit switch protocol Compatible with solar panel TRONIC DC M45 50/12...
- Page 2 50Nm MOTOR + Battery with Bidirectional Radio Receiver This pack includes a 12V motor and an external battery with an integrated bidirectional radio receiver. For added convenience and sustainability, an optional solar panel can be included, allowing the battery to be charged using renewable energy, eliminating the need for frequent recharges and connection to the power grid.
-
Page 3: Battery Charging Options
Technical Features of the Motor Length Par- Nominal Working Degree of Speed Feeding Amperage Max laps measure nominal power time protection Weight ment 50 Nm 12 rpm 12 V D.C 142 W 11,8 A 6 min IP 44 660mm 80 Kg Technical characteristics of the battery Length working... - Page 4 Accessories: 50 octagonal pulley Corona 50 octagonal 61.005.010 61.005.110 DEPRAT 54 octagonal pulley 61.005.099 Pulley 56 61.005.003 Corona 56 Corona 54 octagonal DEPRAT 61.005.103 61.005.098 Pulley 60 round reinforced pulley 60 octagonal pulley 61.005.012 61.005.011 61.005.008 reinforced octagonal pulley Corona 60 octagonal Reinforced octagonal crown 60 61.005.111 40.005.111...
- Page 5 Accessories: Pulley 70 BAT Pulley 70 centered Corona 70 BAT 61.005.029 61.005.014 61.005.129 warhead warhead warhead Crown 78 Crown 70 centered ogive 70 octagonal pulley 61.005.114 61.005.006 61.005.107 Warhead Pulley 78 Corona 80 BAT Pulley 80 BAT 61.005.007 61.005.130 61.005.030 Warhead warhead warhead...
-
Page 6: Safety Warnings
Compatible with: Kikwalll15 Kikwalll Kumo wave Controller Controller KIK1 KIK15 weather vane NOX solar KIK SUN KIK move Kumo wave BD.100.001 Controller KIK1 BD.003.101 Controller KIK15 BD.003.115 Controller KKIKWALL1 90.003.101 Controller KIKWALL15 90.003.115 Controller KIK SUN BD.003.115SUN Weather vane NOX SOLAR BD.002.124 KIK move BD.001.125... -
Page 7: Change Of Address
INSTRUCTIONS: 1. Link first transmitter (x1) (5'') (x1) (3'') Click-Clack Click-Clack Procedure: Press the battery programming button for 3 seconds (3''). The motor will make a "CLICK-CLACK" sound (x1). Press (STOP) on the remote control to record for five seconds. The motor will make a "CLICK-CLACK"... - Page 8 INSTRUCTIONS: 3. Link/remove an additional transmitter: (x1) (x1) ( x2 ) Clik-Clak Click-Clack Clik-Clak Procedure: Press the button (P2) located behind the already linked transmitter (A). The motor will make a CLICK-CLACK (x1) and a beep (x1). We will press the button (P2) of the same transmitter (A) again. The motor will make a "CLICK-CLACK"...
- Page 9 INSTRUCTIONS: 5. Delete all transmitters / factory mode (15'') (x4) Click-Clack Procedure: Press the battery programming button for 15 seconds (15''). The motor will make 4 "CLICK-CLACK" sounds (x4) and four beeps (x4).
- Page 10 C/Pica d'Estats, 108-118 Polígono pedidos@eurotronic-europe.com Industrial Sant Isidre 08272 Sant Fruitós de Tel: +34 932 420 108 Bages (Barcelona) SPAIN Follow us on social media:...
