Page 1 Installation Manual Air/Water Heat Pump R290 Series ES 100L ST / ES 100L ST UK ES 250L ST / ES 250L ST UK ES MCB ES MHB ES M8 R290 ES M12 R290 ES M15 R290 1 PH ES M15 R290 3 PH...
Page 2: Table Of Contents
Table of contents 1 Document history ......................1.1 Abbreviation List ......................... 2 Introduction........................2.1 Disclaimer........................... 2.2 Conformity to safety regulations ....................3 Safety..........................3.1 Symbols used in this document....................3.2 Safety precautions........................3.3 ...
Page 3 6.8 Mechanical installation ....................... 6.9 Placement of additional components..................6.10 Installing the MCB and MHB ....................7 Hydraulic installation ....................... 7.1 Piping............................8 Wiring ..........................8.1 Indoor units wiring connections ....................8.2 Outdoor units wiring connections ....................9 ...
Page 4: Document History
A valve that controls the flow of refrigerant into the Electronic Expansion Valve evaporator Energy related Products Performance test Energy Save The transfer of an electrical charge between two ElectroStatic Discharge electrically charged objects A safety device that shuts the electrical power off when...
Page 5: Introduction
Proper adherence to the directions provided herein is vital for both the smooth operation of this system, as well as for your safety and the safety of those around you. Energy Save is not responsible or liable for any losses incurred due to misuse or mishandling of this product, which includes, but is not limited to: –...
Page 6: Conformity To Safety Regulations
For this reason, follow them carefully. For further questions contact your installer or technical support from Energy Save. Contact details can be found on the last page of this document, or on the Energy Save website: https://energysave.se/contact/ 3.1 Symbols used in this document...
Page 7: Safety Precautions
3.2 Safety precautions DANGER – The outdoor unit contains R290 refrigerant, an extremely flammable gas that may explode if heated. – Work on the refrigerant system must only be carried out by authorised installation personnel which has completed adequate training for the use of flammable refrigerant (EN 378, Part 4 or IEC 60335-2-40, Annex HH).
Page 8 WARNING – Inspect the refrigerant circuit for leaks before starting work, as electrostatic discharge and sparks may cause an explosion. – Ensure that there is sufficient air flow in the work area around the outdoor unit for the duration of the work.
Page 9: Emergency Procedures
CAUTION – Installation, service, repairs and disposal must comply with all applicable national and international laws and standards. – The complete installation manual must be read before installation, service or repairs to be followed. – Installation, service, and repairs must be performed by properly trained and licensed professionals that is well-acquainted with the equipment.
Page 10: Regulations To Be Observed
CAUTION Power shut down in sub-zero temperatures In cold weather, extended power outages increase the risk of water in the system freezing, potentially causing permanent damage to the indoor unit, outdoor unit, and heating system. If the system will be without power for an extended period, ensure all components exposed to sub-zero temperatures are drained of water.
Page 11 – Any tools or equipment used must be classified for use in hazardous areas (ATEX and IEC Ex certification, Zone 2). – Ensure that all possible sources of static electricity are eliminated, by earthing of equipment, devices and clothing, and by wearing anti-static work shoes (ESD safety shoes).
Page 12: System Description
4 System description An air-to-water heat pump takes advantage of the energy in the outdoor air, using it to heat water for use in the household and for different types of space heating. 1. A compressor compresses refrigerant gas, which generates heat. ...
Page 13: Generic Flow Diagram
4.2 Configuration of Indoor and Outdoor Units Indoor unit DHW tank Buffer tank 8 kW 12 kW 15 kW ES 100L ST 100 liter tank Recommended ES 100L ST UK integrated ES 250L ST 250 liter tank Recommended ES 250L UK integrated ES MCB Optional* Recommended...
Page 14: Included In The Package
4.3 Included in the package The following accessories are included with your purchase. Please check that no items are missing or damaged, and contact your local distributor in that case. Product Component Quantity Notes ES M8 R290 Check valve for outdoor units 1 pcs Regulatory requirement to mitigate refrigerant leakage...
Page 15 Antenna for Wi-Fi 1 pcs ES 100L ST THC Temperature sensor 1 × 5 m Extension cable ES 100L ST UK TV1 Temperature sensor 1 × 5 m Extension cable ES 250L ST TV2 Temperature sensor 1 × 5 m Extension cable...
Page 16: Heat Pump Circuit
4.4 Heat pump circuit Description Description Compressor Outdoor temperature sensor Condenser (plate heat exchanger) Evaporating temperature sensor Electronic expansion valve (EEV) Suction temperature sensor Evaporator Discharge temperature sensor 4-way valve Suction pressure sensor Refrigerant heat exchanger Discharge pressure sensor High pressure switch Condenser temperature sensor (liquid refrigerant) Refrigerant filters Condenser outlet water temperature sensor...
Page 17: Pressure Relief Valve
4-way valve connections Heating and DHW mode Cooling mode for high pressure flow for high pressure flow D→E D→C for low pressure flow for low pressure flow C→S E→S NOTE The arrow (→) represents the real refrigerant flow direction. 4.4.1 Gas separator valve A gas separator valve is already installed within the outdoor unit.
Page 18: Product Information
The R290 range of outdoor units has three main variants – 8 kW, 12 kW and 15 kW. The 15 kW unit is available in both single phase and three phase. The R290 range of indoor units includes an ES MCB, ES MHB and two all-in-one units (ES 100L ST and ES 250L ST) with different sizes of DHW volume.
Page 19: About The R290 Refrigerant
Figure 3: The ES R290 product range 5.1 About the R290 refrigerant The refrigerant used in this heat pump is propane (R290), a natural non-toxic hydrocarbon refrigerant with very low environmental impact and excellent thermal efficiency. This makes it an ideal choice for use in heating and cooling systems.
Page 20: Placement
WARNING Safety precautions must be followed during all times to minimize the risk of ignition in case of a propane leak. Only authorised personnel are allowed to service or remove refrigerant from the system. 5.2 Placement Follow the below instructions for the safe placement of your indoor and outdoor units. 5.2.1 Indoor unit placement The following considerations must be made regarding the placement of the indoor unit: –...
Page 21: Outdoor Unit Placement
Figure 4: Space requirement for indoor units 5.2.2 Outdoor unit placement CAUTION The heat pump may only be installed outdoors! Examples of suitable locations for the outdoor unit: – Open space – Corridor – Balcony ...
Page 22 – The heat pump must not be placed in sinks or in places where refrigerant can accumulate in the event of a leak. The heat pump must be positioned in such a way that no refrigerant enters the building in the event of a leak or can endanger people in any other way.
Page 23: Hydraulic Requirements
Figure 6: Protected area clear from windows, doors, and air inlets/outlets Figure 6 "Protected area clear from windows, doors, and air inlets/outlets", page 23 depicts the minimum boundaries from the outdoor unit to windows, doors and air inlets/outlets to prevent gas leakages into the home.
Page 24 – Ammonium ion (NH4+) concentration: 0 ppm – pH value: 6–8 5.3.2 DHW production specification Maximum freshwater pressure: 7 bar (regulated by pressure valve) CAUTION For sanitary hot water, always add a mixing valve before the water tap and set it to proper temperature.
Page 25: Indoor Units Technical Data
LCD touch screen / 5" Internet connection Wi-Fi and Ethernet Wi-Fi frequency/power GHz/dBm 2.4 / 15 5.4.2 ES 100L ST, ES 250L ST ES 100L ST ES 250L ST Unit ES 100L ST UK ES 250L ST UK Dimensions (W×D×H) 500×500×1100...
Page 26: Outdoor Units Technical Data
ES 100L ST ES 250L ST Unit ES 100L ST UK ES 250L ST UK Domestic hot water max. tank safety valve Electric heater - system heating 3 × 3 3-way diverting valve for DHW tank Expansion vessel - water heating...
Page 27 Unit ES M8 R290 ES M12 R290 Global warming potential (GWP) Type of connection between indoor and outdoor unit Hydraulic plus two signal cables Dimensions of hydraulic pipe connectors inch G1" G1" Sound power level LwA dB(A) 1 m dB(A) 5 m dB(A) Sound pressure level at a distance 10 m...
Page 28: Operating Range Diagrams
Unit ES M15 R290 1 PH ES M15 R290 3 PH Type of connection between indoor and outdoor unit Hydraulic plus two signal cables Dimensions of hydraulic pipe connectors inch G1 ¼" G1 ¼" Sound power level LwA dB(A) 1 m dB(A) 5 m dB(A) Sound pressure level at a distance 10 m...
Page 29: Cooling Mode
Cooling mode X-axis = Ambient temperature (°C), Y-axis = Water outlet temperature (°C) Air/Water Heat Pump R290 Series | 29...
Page 30: Product Overview
5.7 Product overview 5.7.1 Indoor units product overview ES 100L ST and ES 100L ST UK Ethernet/LAN cable Water outlet from outdoor unit (G1" male) Antenna cable 10 Cable glands RJ11 cable 11 Temperature and pressure relief valve (UK only) Cold domestic water inlet (G1"...
Page 31 ES 250L ST and ES 250L ST UK Ethernet/LAN cable 11 Immersion heater Antenna cable 12 Drainage valve RJ11 cable 13 Water outlet to outdoor unit (G1" male) Cable glands 14 Water inlet from outdoor unit (G1" male) Flow meter 15 Cold domestic water inlet (G¾"...
Page 32 ES MHB Ethernet/LAN cable Pressure relief valve Antenna cable Three-way valve RJ11 cable Three-way valve actuator Cable glands Flow meter Immersion heater ES MCB Antenna Cable glands 32 | Air/Water Heat Pump R290 Series...
Page 33 5.7.2 Outdoor units product overview ES M8 R290 Air inlet Water outlet Air outlet Water inlet Cable gland Outdoor temperature sensor ES M12 R290 Air inlet Water outlet Air outlet Water inlet Cable gland Outdoor temperature sensor Air/Water Heat Pump R290 Series | 33...
Page 34 ES M15 R290 1 PH and ES M15 R290 3 PH Air inlet Water outlet Air outlet Water inlet Cable gland Outdoor temperature sensor 34 | Air/Water Heat Pump R290 Series...
Page 35: Indoor Units Dimensions
5.8 Indoor units dimensions 5.8.1 ES 100L ST and ES 100L ST UK Figure 7: Dimensions (mm) Air/Water Heat Pump R290 Series | 35...
Page 36 5.8.2 ES 250L ST and ES 250L ST UK Figure 8: Dimensions (mm) 36 | Air/Water Heat Pump R290 Series...
Page 37 5.8.3 ES MCB Figure 9: Dimensions (mm) 5.8.4 ES MHB Figure 10: Dimensions (mm) Air/Water Heat Pump R290 Series | 37...
Page 38: Outdoor Units Dimensions
5.9 Outdoor units dimensions 5.9.1 ES M8 R290 Figure 11: Dimensions (mm) 5.9.2 ES M12 R290 Figure 12: Dimensions (mm) 38 | Air/Water Heat Pump R290 Series...
Page 39: Installation
5.9.3 ES M15 R290 Figure 13: Dimensions (mm) 6 Installation For a safe and successful installation of the heat pump system, follow the below instructions. Be aware that different requirements and considerations may apply depending on the choice of indoor and outdoor unit as well as on the conditions at the installation site.
Page 40: Preparing The Site For Installation
6.2 Preparing the site for installation When preparing the site for installation work, follow the applicable environmental and safety regulations. 1 Identify any potential risks or challenges. Consider the layout, dimensions, access, power, ventilation, earthing, and environmental factors. 2 Clear the site from any material and obstacles in order to provide adequate space for the whole workflow when it comes to safety and ergonomics.
Page 41: Drainage Preparation
6.5 Drainage preparation The drainage of the condensation water must work properly not to cause damage to the building. – Make sure that the outlet of the condensation water pipe is correctly positioned. – If the water pipes are at risk for exposure to frost they must be provided with a suitable heating cable. ...
Page 42: Placing The Outdoor Unit
Gutter drainage Figure 15: Gutter drainage For the gutter drainage it is important that the drainage pipe has a water seal to prevent air from circulating in the drainage pipe. The outlet of the condensation water pipe must be located at a depth below the frost line to prevent freezing. 6.6 Placing the outdoor unit For information regarding outdoor unit placement, see Section 5.2.2 "Outdoor unit placement", page 21.
Page 43: Connecting Water Pipes To The Outdoor Unit
4 Ensure that the unit is tilted slightly backwards to prevent ice build-up. 5 Secure the unit in place using a chain or strap to prevent tip-over accidents. The metal grid in the back right side or one of the pipe connection screws can be used to anchor the unit. ...
Page 44: Mechanical Installation
Number of elbows Max piping model system distance ES M8 R290 DN25 / DN32 20 m / 30 m ES 100L ST / UK DN25 / DN32 10 m / 15 m ES 250L ST / UK ES MHB ES MCB ES M12 R290...
Page 45: Temperature Sensors
Figure 16: DIRTMAGPLUS filter 6.9.2 Temperature sensors The temperature sensors need to be correctly positioned. For reference, always use the hydraulic schemes provided by Energy Save. NOTE Which temperature sensors to be used is dependent on the installation type. Description Position Room temperature sensor –...
Page 46: Mixing Valve
Figure 17: Example of temperature sensor positioning 6.9.3 Mixing valve The heat pumps can control two heating and/or cooling mixing circuits. Required temperature sensors for two mixing circuits are included in the package. When controlling two circuits a buffer tank must be used in the hydraulic system.
Page 47: Installing The Mcb And Mhb
MHB", page 53 and Section 8.2.3.1 "Installing magnet rings on the power supply cable", page 55. 7 Hydraulic installation NOTE Hydraulic schemes provided by the Energy Save distributor or Energy Save personnel contain official requirements for the installation of the Energy Save heat pump into a hydraulic system. Air/Water Heat Pump R290 Series | 47...
Page 48: Piping
7.1 Piping 7.1.1 Hydraulic connections for ES 100L ST and ES 100L ST UK Connection Size Connection Size Temperature and pressure relief Flow line heating system G1" male valve, TPRV placement (UK only) Water outlet to outdoor unit G1" male Hot domestic water outlet G1"...
Page 49: Wiring
Also, a RCD (residual-current device) / GFCI (ground fault circuit interrupter) must be added before the fuses for the heat pump. 8.1 Indoor units wiring connections 8.1.1 ES 100L ST and ES 100L ST UK Connections Description PE, N, N, L1, L2, L3...
Page 50 Connections Description CS, +12V Cooling signal -CS- digital input SG1, SG2, +12V SG ready TX, RX, GND Communication indoor - outdoor unit TX = A RX = B GND = G TX2, RX2, GND Communication - RF dongle THC, GND Buffer tank temperature sensor - THC TV1, GND Mixing circuit 1 temperature sensor - TV1...
Page 51 Connections Description TX, RX, GND Communication indoor - outdoor unit TX = A RX = B GND = G TX2, RX2, GND Communication - RF dongle THC, GND Buffer tank temperature sensor - THC TV1, GND Mixing circuit 1 temperature sensor - TV1 TV2, GND Mixing circuit 2 temperature sensor - TV2 TR1, GND...
Page 52 Connections Description L2M2, L2M1, N Mixing valve 2 - ZONE 2 MS, N Mode signal output - 230 V AC DV, LDV, N Diverting valve - LDV = permanent 230 V; DV = signal output 230 V (in DHW mode) RV1, RV2, RV3, RV4, RV5, RV6 Reserve (RV1 –...
Page 53 8.1.4 ES MHB Connections Description PE, N, N, L1, L2, L3 Main power supply - 400 V AC P1, N, PE Water pump P1 - 230 V AC output P2, N, PE Water pump P2 - 230 V AC output LH, N Additional buffer tank heating source (signal only) L1M1, L1M2, N...
Page 54: Outdoor Units Wiring Connections
8.2 Outdoor units wiring connections 8.2.1 ES M8 R290 and ES M12 R290 Connections Power supply 220-240 V/50 Hz L1, N, PE Drain pan heater 230 V, max 150 W (for connecting an LDP, NDP, PE external drain pan heater) Signal P0 water pump PWM PWM, GND Communication to indoor unit...
Page 55 Connections Communication to indoor unit A, B, G Outdoor temperature sensor (pre-installed) Ta, Ta 8.2.3 Installing magnetic rings See the following instructions for installing a magnet ring on the power supply and communication cable. NOTE For ES MCB indoor unit installations, the magnetic ring should be installed on the communication cable.
Page 56 4 Put the magnet ring on the power supply cable and close it. Figure 19: Installation of magnet ring (ES M15 R90 1 PH) F9 SCRC 200D 8.2.3.2 Installing magnet rings on the communication cable For ES M8 R290 and ES M12 R290 installation 1 Make sure that the communication cable has been installed correctly.
Page 57 4 Put the cable in the magnet ring and wrap it around the ring three times and close it. Figure 20: Installation of magnet ring (ES M8 R290 and ES M12 R290) F9 SCNF 130A For ES M15 R90 1 PH and ES M15 R90 3 PH installations 1 Make sure that the communication cable has been installed correctly.
Page 58: Commissioning And Configuration
9 Commissioning and configuration 9.1 Commissioning and registration Commissioning here refers to an activity by the installer in setting up the configuration of the system, mostly through the display interface. It typically happens after physical installation and before other general configurations and leaving the site. The action order suggested below is based on: –...
Page 59: Warranty
5-year compressor warranty is valid only if the unit is registered within 30 days of installation in the Energy Save registration system. The unit is considered to be registered if the unit is connected to the ES Cloud (online registration) or if the unit is registered via the offline registration procedure.
Page 60 Symbol Description Space heating is in progress. An additional heating source is activated. Space cooling is in progress. Domestic hot water production is in progress. The defrosting function is activated. The compressor is running. The anti-legionella function is activated. Reduced mode is activated. Quiet mode is activated.
Page 61: Alert Symbols
Alert symbols Symbol Description Action ALARM Tap to view information. WARNING Tap to view information. INFORMATION Tap to view information. 9.3.2 Menu navigation The main navigation tools used to access parameters and information in the menu are: Symbol Function icon Tap to access the menu system.
Page 62 Symbol Function Apply to all Tap to apply a changed setting to all instances. icon icon Tap to remove a setting. NOTE A green icon means the function is enabled. A grey icon means the function is disabled, or that you need to tap the icon to enable it.
Page 63 Zone 1 and Zone 2 settings Parameter Description Zone heating/cooling Type of temperature adjustment in the zone. (Read-only - installer level access required) – Heating – Cooling – Heating&Cooling Room temperature Current detected room temperature in the zone. NOTE Only applicable if a room temperature sensor is present in the zone.
Page 64: Adjusting The Heating Curve
9.3.4.1 Heating curve settings To reach the settings for the Zone 1 heating curve, go to Zones » Zone 1 » Flow temperature set point - heating. For Zone 2 heating curve, scroll down to Zone 2 » Flow temperature set point - heating. Tap the value to the right to change the settings.
Page 65: Domestic Hot Water (Dhw)
NOTE The parameter is only visible if Zone heating/cooling is set to Cooling or Heating&Cooling. The flow temperature range will be affected by the setting of Flow temperature min limit and Flow temperature max limit, found under Installer settings » Commissioning » Zones. Zone 1: Flow temperature set point - cooling Outdoor temperature (°C) Flow temperature (°C)
Page 66 Domestic hot water (DHW) DHW temperature 40°C DHW temperature set point 60°C > Anti-legionella Anti-legionella Domestic hot water (DHW) settings Parameter Description DHW temperature Current detected domestic hot water temperature. DHW temperature set point Setting of the desired domestic hot water temperature. Tap to open the temperature selector.
Page 67 Parameter Description Anti-legionella duration Setting of the time (minutes) during which the heat pump should maintain the anti-legionella temperature set point once it has been reached. (Only visible if the anti-legionella function is activated). page 67 See Section 9.3.5.1 "Setting up the anti-legionella treatment", settings.
Page 68 2 Tap to open the time selector. Select the time (in 1 minute increments) by tapping the + (plus) and - (minus) buttons or by tapping the time value and changing it with the keypad that appears. To set the time-out for the anti-legionella treatment (if the temperature is not reached): 1 Go to Anti-legionella time-out.
Page 69: Alert History
Compressor discharge temp. sensor failure - Td Occured Resolved 2024-07-22 2024-07-23 12:03 10:12 Some alarms and warnings require confirmation, which is done by tapping in the upper right of the alerts list. Alert history To view the alert history list, go to Installer settings » Alert history. Installer level access is required. Alert history The coloured dots in the alert history list represent the same categories as the alert symbols, that is: red for alarm, orange for warning, and blue for information.
Page 70: Operation Settings
Space heating/cooling Automatic heating & cooling Automatic heating (Information text for the selected setting) Automatic cooling Operation settings Parameter Description Operation Tap the switch symbol to switch on or off the entire heat pump system. – System is OFF ...
Page 71: Real Time Data
9.3.8 Real time data In the Real time data menu all the current state or running data for the whole system is listed, such as temperatures, status of different elements, digital inputs, and more. Real time data Electric grid protection Status Requested Basic power consumption settings...
Page 72 Parameter Description Current season The current season the system is in. – Cooling – Heating – Neutral Hydraulic parameters: System heat balance Heat balance of the system Heating/cooling water Water temperature (°C) in the buffer tank (or flow line after 3-way valve) temperature THC DHW tank temperature TDW Domestic hot water temperature (°C) in the DHW tank...
Page 73 Parameter Description Additional inline heating source – : 1 stage on (regardless of which one) Active 1/3 – : 2 stages on (regardless of which ones) Active 2/3 – : 3 stages on (regardless of which ones) Active 3/3 ...
Page 74: User Settings
Scroll down to reach the below parameters. Energy data parameters Parameter Description Tap to view real time power data. Last 24 hours Tap to view the total amount of energy used and produced in the last 24 hours. Last 7 days Tap to view the total amount of energy used and produced in the last 7 days.
Page 75: User Menu Settings
User settings Vacation mode Off > Reduced mode Scheduled > Quiet mode Scheduled > Wi-Fi #home > Ethernet Not connected > Scroll down to reach the below parameters. User menu settings Parameter Description Vacation mode Scheduling of periods of absence when space heating and/or hot water temperatures should be reduced.
Page 76 Tap to request a verification code for pairing, then enter the code in the user app. For detailed information, see the instructions. Energy Save App Season start/stop conditions: Heating season start/stop Setting of the desired outdoor temperature for system to go in and out of, hence start and stop, heating season.
Page 77 Parameter Description Date & Time Current date and time. Information: About System information such as serial numbers and software and hardware versions. Dealer information Contact details for the dealer of the equipment. 9.3.10.1 Setting up the vacation mode schedule To set the schedule when the vacation mode should be active: Vacation mode 2024-08-09 to 2024-08-25 Vacation mode will automatically activate during the...
Page 78 Reduced mode Room temperature delta (°C) DHW delta (°C) Remove this schedule Cancel Monday Save Clear time slot Apply for all days 1 Go to User settings » Reduced mode. Tap to change the setting. 2 Tap Add reduced mode schedule to open a screen with time slot settings for each day (night) of the week.
Page 79 Quiet mode Remove this schedule Cancel Monday Save Clear time slot Apply for all days 1 Go to User settings » Quiet mode. Tap to change the setting. 2 Tap Add quiet mode schedule to open a screen with settings, where the time slot for the function is preset to 23:00 to 07:00 for each day (night) of the week.
Page 80: Installer Settings
9.3.11 Installer settings The Installer settings menu is intended for installers. To reach the menu a four-digit installer PIN code must be entered. Installer settings Commissioning Commissioning > Alerts Active alerts > Alert history > Manual mode Scroll down to reach the below parameters. Installer settings parameters Parameter Description...
Page 81 Parameter Description – Digital input None – BMS Modbus Command – CS/EGP – HS/EGP Activation signal type Tap to select the activation signal type. – Normally open – Normally closed ...
Page 82 Parameter Description Cooling season settings Tap to reach settings for the cooling season. – Based on outdoor temperature – Based on digital input P0 water pump speed setting Settings for the P0 water pump. Tap to open selectors for , and .
Page 83 Parameter Description Real time data View real time data Manual mode Selection of manual mode – Manual mode is OFF – Manual mode is ON menu opens. Manual mode 9.3.11.2 Installer settings submenu: Manual mode The Manual mode submenu contains heat pump functions that can be manually activated and set. Tap the switch symbol to activate or deactivate the function.
Page 84: Before Leaving The Installation Site
This ensures that the technicians have the necessary knowledge, skills, and experience to complete the job correctly and in accordance with safety regulations and specifications of Energy Save. Make sure the service area is not enclosed and provide good ventilation (opening doors and windows). The service area must be properly isolated.
Page 85: Maintenance Checklist Electrical System
Legend Indoor unit / distribution system Outdoor unit IN + OUT Indoor and outdoor unit IN / OUT Indoor or outdoor unit, depending on the heat pump type SYSTEM External installation (not included in the heat pump) Or / and according to the local regulations 10.3 Maintenance checklist electrical system Maintenance check Applies to: Annual...
Page 86: Other Maintenance Checks
10.5 Other maintenance checks Maintenance check Applies to: Annual Every 2 years Every 4 years Check for strange / unregular sounds while system is IN + OUT working. Check positioning of temperature sensors. Check the anode rod and exchange if needed. (Systems with R32 refrigerant only) NOTE Only applies for units with enameled DHW tank.
Page 87: Appendix A: Wiring Diagrams
11 Appendix A: Wiring diagrams 11.1 Indoor units 11.1.1 ES 100L ST and ES 100L ST UK Air/Water Heat Pump R290 Series | 87...
Page 88 11.1.2 ES 250L ST and ES 250L ST UK 88 | Air/Water Heat Pump R290 Series...
Page 89 11.1.3 ES MCB Air/Water Heat Pump R290 Series | 89...
Page 90 11.1.4 ES MHB 90 | Air/Water Heat Pump R290 Series...
Page 91: Outdoor Units
11.2 Outdoor units 11.2.1 ES M8 R290 Air/Water Heat Pump R290 Series | 91...
Page 92 11.2.2 ES M12 R290 92 | Air/Water Heat Pump R290 Series...
Page 93: Appendix B: Hydraulic Schematics
11.2.3 ES M15 R290 3 PH 12 Appendix B: Hydraulic schematics The most common setups are presented here. There are more schematics available that can be provided upon request. Air/Water Heat Pump R290 Series | 93...
Page 94: M100L St, M8/12 R290, Dhw, Bt100Tc-1/Bt200Tc-1
12.1 M100L ST, M8/12 R290, DHW, BT100TC-1/BT200TC-1 Figure 22: 2 × mixing heating/cooling circuits 94 | Air/Water Heat Pump R290 Series...
Page 95: M250L St, M8/12 R290, Bt100Tc-1/Bt200Tc-1
12.2 M250L ST, M8/12 R290, BT100TC-1/BT200TC-1 Figure 23: 2 × mixing heating/cooling circuits Air/Water Heat Pump R290 Series | 95...
Page 96: M250L St, M15 R290, Bt100Tc-1/Bt200Tc-1
12.3 M250L ST, M15 R290, BT100TC-1/BT200TC-1 Figure 24: 2 × mixing heating/cooling circuits 96 | Air/Water Heat Pump R290 Series...
Page 97: Mcb, M15 R290, Dhw, Bt100Tc-1/Bt200Tc-1
12.4 MCB, M15 R290, DHW, BT100TC-1/BT200TC-1 Figure 25: 2 × mixing heating/cooling circuits and DHW production Air/Water Heat Pump R290 Series | 97...
Page 98: Appendix C: Accessories
13 Appendix C: Accessories 13.1 Electrical meter 13.1.1 Connection of electrical meter There are two versions of the electrical meter: – ET340 3 phase (400 V) - can be used for all indoor unit models (two different connection options depending on heat pump indoor unit model) ...
Page 99 ET340, connection for models ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST, ES 250L ST UK Figure 27: ET340 connection, ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST, ES 250L ST UK Fuse box, power supply...
Page 100 ET340, connection for model ES MCB Figure 28: ET340 connection, ES MCB Fuse box, power supply Indoor unit, terminal connections, communication Electrical meter, ET340 Indoor unit, main power supply terminals ET340 Indoor unit, terminal connections 100 | Air/Water Heat Pump R290 Series...
Page 101: Wireless Room Thermostat
ET112, connection for model ES MCB Figure 29: ET112 connection, ES MCB Fuse box, power supply Indoor unit, terminal connections, communication Electrical meter, ET112 Indoor unit, main power supply terminals ET112 Indoor unit, terminal connections It is also possible to connect both the wireless thermostat and the electrical meter in combination, see Section 13.2.2 "Connection of wireless room thermostat combined with electrical meter", page 104.
Page 102 Connection for models ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST and ES 250L ST UK Figure 30: Wireless room thermostat connection, ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST and ES 250L ST UK...
Page 103 Connection for model ES MCB Figure 31: Wireless room thermostat connection, ES MCB Wireless room thermostat RF Dongle Indoor unit, terminal connections, communication ES Wireless room thermostat Indoor unit, terminal connections Yellow (A) Green (B) Brown (V) White (G) It is also possible to connect both the wireless thermostat and the electrical meter in combination, see Section 13.2.2 "Connection of wireless room thermostat combined with electrical meter", page 104.
Page 104 Wireless room thermostat and electrical meter ET340, connection for ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST, ES 250L ST UK Figure 32: Wireless room thermostat and ET340 connection, ES MHB, ES 100L ST, ES 100L ST UK, ES 250L ST, ES 250L ST UK...
Page 105 Wireless room thermostat and electrical meter and ET340, connection for ES MCB Figure 33: Wireless room thermostat and ET340 connection, ES MCB Fuse box, power supply Indoor unit, terminal connections, communication Electrical meter, ET340 Indoor unit, main power supply terminals Wireless room thermostat RF Dongle ES Wireless room thermostat Indoor unit, terminal connections...
Page 106 Wireless room thermostat and electrical meter ET112, connection for ES MCB Figure 34: Wireless room thermostat and ET112 connection, ES MCB Fuse box, power supply Indoor unit, terminal connections, communication Electrical meter, ET112 Indoor unit, main power supply terminals Wireless room thermostat RF Dongle ES Wireless room thermostat Indoor unit, terminal connections Yellow (A)
Page 107 Air/Water Heat Pump R290 Series | 107...
Page 108 Sweden (HQ) Energy Save Holding AB Metallgatan 2-4, SE-441 32 Alingsås, Sweden Norway Energy Save AS Kirkeveien 50, 1396 Hvalstad, Norway Slovenia Energy Save Nordic D.O.O. Ulica Heroja Nandeta 37, 2000 Maribor, Slovenia www.energysave.se We reserve the right to make changes that do...
