Installation
manual
Air/water heat pump R32 V8 series
AWC 6/9/12/15/19 kW, AWST 6/9/12/15 kW monobloc indoor units
AWH 6/9/12 kW, AWST 6/9/12 kW split indoor units
AW 6/9/12/15/19 kW monobloc outdoor units
AW 6/9/12 kW split outdoor units
v3.1 2024-11-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V8 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Energy Save V8 Series

Summary of Contents for Energy Save V8 Series

  • Page 1 Installation manual Air/water heat pump R32 V8 series AWC 6/9/12/15/19 kW, AWST 6/9/12/15 kW monobloc indoor units AWH 6/9/12 kW, AWST 6/9/12 kW split indoor units AW 6/9/12/15/19 kW monobloc outdoor units AW 6/9/12 kW split outdoor units v3.1 2024-11-21...

  • Page 2: Table Of Contents

    Table of contents 1   Introduction........................1.1   Symbols used in this manual...................... 2   Safety precautions ......................2.1   Warranty ............................. 3   System description ......................3.1   Main system components......................4   System requirements ....................... 4.1   Environmental requirements....................... 4.2  ...
  • Page 3 15.1   Connection directly to house router..................15.2   Connection with a wireless network ..................15.3   Verifying connection to router ....................15.4   Adding the heat pump to the Energy Save server ..............16   Commissioning and testing ..................Table of contents...
  • Page 4 17   Service and maintenance ....................17.1   Requirements on service area and personnel................17.2   Inspections ..........................17.3   Maintenance intervals ......................17.4   Maintenance checklist hydraulic system................... 17.5   Maintenance checklist electrical system................... 17.6   Maintenance checklist refrigerant system ................17.7  ...

  • Page 5: Introduction

    1 Introduction This manual covers the main steps and detailed settings for the installation of the Energy Save air/water heat pumps R32 V8. The manual is intended for personnel involved in the installation of the heat pump as well as the connected equipment.

  • Page 6: Symbols Used In This Manual

    For this reason, follow them carefully. For further questions contact your installer or technical support from Energy Save. Contact details can be found on the last page of this document, or on the Energy Save website: https://energysave.se/contact/...
  • Page 7 Be sure only to use accessories which are specifically designed for use with the equipment. If not provided or agreed upon by Energy Save, the accessories must comply with the specifications given in this manual. The accessories must be installed by a professional.

  • Page 8: Warranty

    3-year warranty. A 5-year compressor warranty is only valid if the unit is registered within 30 days of installation in the Energy Save registration system, using the registration link provided by your Energy Save distributor. The registration form can also be accessed from http://www.energysave.se/register or by scanning this QR code.
  • Page 9 3.1.1 Monobloc system 3.1.2 Split system Installation Manual | 9...

  • Page 10: System Requirements

    4 System requirements 4.1 Environmental requirements Indoor unit The following considerations must be made regarding the placement of the indoor unit: – The indoor unit must be placed indoors.     – Ensure that the location is dry and well-ventilated.  ...
  • Page 11 Control box and Hydro indoor units AWH-R32-S-V8 is equipped with a mounting bracket. Indoor units with integrated tank Single fan outdoor units Installation Manual | 11...

  • Page 12: Hydraulic System Requirements

    Double fan outdoor units 4.3 Hydraulic system requirements System water supply The water used for the system must comply with local regulations or the following specifications: – Chloride ion (Cl-) concentration ≤ 300 ppm (300 mg/L)     – Ammonium ion (NH4+) concentration = 0 ppm  ...
  • Page 13 – Reduced efficiency: Glycol transfers heat less effectively than water. This means the pump has to work harder to circulate the solution, slightly reducing its efficiency (COP).     – Increased water pump power consumption: The higher viscosity of glycol requires more energy to pump it through the system compared to water.

  • Page 14: Working Range Heating And Cooling Modes

    Model (outdoor unit) Minimum buffer tank size (l) AW15-R32-M-V8 AW19-R32-M-V8 Conditions when a buffer tank must be installed: Table 15: Mandatory installation of a buffer tank System Specification Multiple zone regulation If more than one heat distribution circuits are used. Radiator system If radiators are used as the heat distribution system.

  • Page 15: Preparations Before Installation

    Energy Save takes no responsibility for any damages caused by improper handling of the equipment during transport.

  • Page 16: Tools

    6 Hydraulic installation NOTE Hydraulic schemes provided by the Energy Save distributor or Energy Save personnel contain official requirements for the installation of the Energy Save heat pump into a hydraulic system. 6.1 Hydraulic connections 6.1.1 Hydraulic connections for monobloc units...
  • Page 17 Table 16: AWST-R32-M-V8 Connection Size Connection Size Water outlet – to outdoor unit G1˝ Flow line – Heating system G1˝ Water inlet – from outdoor unit G1˝ Automatic Air purging valve G1/2˝ Fresh cold-water inlet G3/4˝ Sanitary hot water outlet G1˝...

  • Page 18: Piping

    Table 17: AWH-R32-S-V8 Connection Size Connection Size Return line – heating system G1˝ Gas line - refrigerant G5/8˝ Flow line – heating system G1˝ Liquid line - refrigerant G3/8˝ Table 18: AWST-R32-S-V8 Connection Size Connection Size Gas line - refrigerant G5/8˝...
  • Page 19 ES heat pump model Piping Buffer tank in Number of Max piping dimensions system elbows distance DN25 / DN32 20 m / 30 m AW9-R32-M AWC6/19-R32-M DN25 / DN32 10 m / 15 m AWST6/15-R32-M DN25 / DN32 20 m / 30 m AW12-R32-M AWC6/19-R32-M DN25 / DN32 10 m / 15 m AWST6/15-R32-M DN32 / DN40...

  • Page 20: Filters

    Refrigerant piping height difference Special measures need to be taken for units installed at a higher level than the evaporator in order to facilitate oil return to the compressor. – There must be syphons in the vertical sections of the suction line G.  ...

  • Page 21: Temperature Sensors

    Figure 2: DIRTMAGPLUS filter 6.4 Temperature sensors The temperature sensors need to be correctly positioned. For reference, always use the hydraulic schemes provided by Energy Save. NOTE Which temperature sensors to be used is dependent on the installation type. Description Position Room temperature sensor –...

  • Page 22: Mixing Valve For The Heating/Cooling Circuit

    Figure 3: Temperature sensor positioning, example 1 Figure 4: Temperature sensor positioning, example 2 6.5 Mixing valve for the heating/cooling circuit The heat pumps can control two heating and/or cooling mixing circuits. Required temperature sensors for two mixing circuits are included in the package. When controlling two circuits a buffer tank must be used in the hydraulic system.
  • Page 23 Description Scheme Mixing valve for Zone 1 Water pump for Zone 1 Temperature sensor for mixing circuit 1 Mixing valve for Zone 2 Water pump for Zone 2 Temperature sensor for mixing circuit 2 6.5.1 Type of mixing valve The heat pumps use proportional actuators – 24 V DC power supply and 0 to 10 V DC controlling signal. Zone 1 (heating / cooling circuit 1) Zone 2 (heating / cooling circuit 2) = N (0VDV)

  • Page 24: Refrigerant Charging (Split Units)

    ESBE ARA 639 – 4 cables Connection to ES heat pump (for controlling the first heating / cooling circuit) 7 Refrigerant charging (split units) The refrigeration circuit should be operated according to the proper procedures. The flammability of the page 83 refrigerant should also be considered.

  • Page 25: Refrigerant Amount

    7.1 Refrigerant amount The heat pump is prefilled with R32 refrigerant that is sufficient for a pipe length of 7.5 metres. If the piping is longer than 7.5 metres, then add 30 grams of refrigerant for each additional metre. Maximun allowed pipe length is 20 metres.

  • Page 26: Cable Connections For Indoor Unit

    8.1 Cable connections for indoor unit 8.1.1 AWC-R32-M-V8; 6-19 kW Connections Description Power supply 230 V 50 Hz, PE, N, L Power supply for the indoor unit 3×1.5 mm To outdoor unit, single phase PE, N L Connection to electrical heater for heat exchanger (230 V). Recommended is to use a separate fuse and supply it directly anti-freeze el.
  • Page 27 Connections Description AH signal N1, L1 Back-up heating signal for heating and DHW N1 = Neutral; L1 = 230 V AC NOTE Only for low power switching – relay coil. HWTBH signal N2, L2 Back-up heating signal for DHW only N2 = Neutral; L2 = 230 V AC NOTE Only for low power switching –...
  • Page 28 8.1.2 Temperature sensors AWC-R32-M-V8; 6-19 kW Room temperature Mixing circuit 1 temperature Mixing circuit 2 temperature Heating / cooling system temperature Sanitary hot water temperature 8.1.3 AWST-R32-M-V8; 6-15 kW Connections Description Power supply L1, L2, L3, N, PE Power supply for the indoor unit Recommended cable 5×2,5 mm RESERVE...
  • Page 29 Connections Description Pump 2 P2, N, PE Circulation pump for heating/cooling circuit Zone 2 PE = Earth; N = Neutral; P2 = 230 V AC LH, N Back-up heating signal for heating only N = Neutral; LH = signal 230 V AC NOTE Only for low power switching – relay coil. MS (mode signal) MS, N Gives signal when unit is selected mode (heating or cooling...
  • Page 30 Heating / cooling system temperature Sanitary hot water temperature 8.1.5 AWST-R32-S-V8 Connections Description Power supply L1, L2, L3, N, PE Power supply for the indoor unit Power supply to outdoor PE, N1, L1 Recommended to route the power supply to the outdoor unit unit, single phase separately with its own fuse.
  • Page 31 Connections Description Mixing valve 1 G, 24 V, COM, 1 Proportional actuator control G = -0 V DC; 24 V = 24 V DC; COM = -0 V DC; 1 = 0..10 V DC; Mixing valve 2 G, 24 V, COM, 2 Proportional actuator control G = -0 V DC; 24 V = 24 V DC; COM = -0 V DC; 2 = 0..10 V DC;...
  • Page 32 Connections Description Pump 1 P1, N, PE Circulation pump for heating/cooling circuit Zone 1 PE = Earth; N = Neutral; P1 = 230 V AC Pump 2 P2, N, PE Circulation pump for heating/cooling circuit Zone 2 PE = Earth; N = Neutral; P2 = 230 V AC AH signal N1, L1 Back-up heating signal for heating and DHW...

  • Page 33: Cable Connections For Outdoor Unit

    8.2 Cable connections for outdoor unit 8.2.1 AW-R32-M-V8; 6-12 kW Connections Description Power supply 220 V 50 Hz, PE, L, N Power supply for the outdoor unit 3×2.5 mm PE = Earth; L = 230 V AC; N = Neutral To indoor unit signal PWM P0 OUT, GND, IN Connection for speed control of the P0 pump (not mandatory) To indoor unit pump P0 P0, PN...
  • Page 34 8.2.2 AW-R32-M-V8; 15-19 kW Connections Description Power supply 400 V AC L1, L2, L3, N, PE Power supply for the outdoor unit 50 Hz L1 = Phase 1; L2 = Phase 2; L3 = Phase 3; N = Neutral; PE = Earth  To indoor unit signal PWM P0 OUT, GND, IN Connection for speed control of the P0 pump (not mandatory) To indoor unit pump P0 P0, PN...

  • Page 35: External Modbus Control Connection

    (indoor or outdoor unit) 8.3 External modbus control connection The V8 series units can all be controlled by an external device using a standard Modbus protocol connection. Figure 5: BMS system with ES heat pump operation panel Modbus communication – T+ Wi-Fi module port 5 Modbus communication –...

  • Page 36: Backup Thermostat Settings

    9 Backup thermostat settings 9.1 Analog back-up NOTE Only applicable for AWST models (AWST6-15-R32-M-V8 and AWST6-12-R32-S-V8) Analog back-up is a function that will kick in as the last reserve, should a fatal failure occur in the unit. Fatal failure is a case where the indoor unit main control system fails (display or indoor PCB). If this happens, the system has no automatic control of the backup system.

  • Page 37: Thermostat Failures

    Press to increase the temperature. The setting is saved and automatically returns to the main screen. Press to decrease the temperature. The setting is saved and automatically returns to the main screen. Electrical heater is OFF Electrical heater is ON (a dot appears) 9.3 Thermostat failures Failure on display Possible causes...

  • Page 38: Disabling Analog Backup

    Press to select parameter (E1 to E5, according to section Digital thermostat parameters).     Press the button to show and change the value of the selected parameter.     If no button is pressed, the screen will automatically return to normal mode after 6 seconds. 9.5 Disabling analog backup 1 Set the thermostats to 10 °C.

  • Page 39: Control Unit

    11 Control unit The Energy Save heat pumps have an integrated LED touchscreen controller with a menu interface that has a big range of installation options developed to achieve optimal performance and reduce heating costs. The menu also offers sophisticated safety features for a carefree operation of the heat pump.
  • Page 40 Mode selection Tap to change the mode: Automatic alternation between heating, cooling, and domestic hot water. Auto NOTE External signals will be active only in Auto mode. In the other modes the unit will disregard the external switch control! Only heating is activated Heating Only domestic hot water is activated Domestic hot water...

  • Page 41: Menu Navigation

    Legionella function Vacation mode Floor curing function Electrical utility lock ECO heating function (yellow): The heat pump operates normally but authorized service personnel must be informed! Warning (red): To ensure the safety of the system and heat pump, the heat pump is switched off. If the Alarm function is activated (see the menu), the heat pump continues to operate,...

  • Page 42: Setting The Day And Time For Activation Of A Function

    11.3 Setting the day and time for activation of a function Some parameters require schedule settings in a separate screen. 1 Select the day of the week by tapping it in the upper bar.     2 Change the status between active and inactive by tapping the time fields. –...

  • Page 43: Initial Settings

    Parameters indicated in grey for the end user are protected by the installer password. NOTE The unit returns to the end user level automatically after 5 minutes. 13 Initial settings 13.1 Setting of room temperature 13.1.1 Setting room temperature with room temperature sensor (TR) The room temperature control can only be used if the room temperature sensor is located in a proper room (for example a living room), and the function Room temp.
  • Page 44 1 On the main screen, tap the indication for room temperature, next to the house icon.     2 Tap + or - to raise or lower the temperature.     3 Tap OK to confirm.     13.1.2 Setting room temperature without sensor When commissioning, the heating curve must be adjusted based on the type of heating system of the house and the desired indoor temperature.
  • Page 45 Parallel move of the heating curve – Zone 1 1 On the main screen, tap the indication for room temperature next to the house icon.     2 Tap + or – to raise or lower the heating curve by the selected temperature.  ...
  • Page 46 3 Tap + or – to raise or lower the heating curve by selected temperature.     4 Tap OK to confirm both settings.     13.1.3 Adapting (breaking) the heating curve If the heating curve needs to be adjusted at a certain outdoor temperature, a section of the curve can be broken to fit the water heating for that temperature.

  • Page 47: Setting Of Domestic Hot Water Temperature

    Zone 1 (For example first floor/underfloor heating): Zone 2 (For example second floor/radiators): NOTE If the zone icon is grey this means that the zone is not activated. 13.2 Setting of domestic hot water temperature 1 On the main screen, tap the temperature indication next to the icon for domestic hot water.  ...

  • Page 48: Specific Settings

    2 Tap + or – to raise or lower the temperature. The temperature that is suitable to set depends on the user's needs and habits. The recommended setting is between 47 °C and 50 °C.     3 Tap OK to confirm.  ...

  • Page 49: Accessing Submenus

    14.1 Accessing submenus 1 Select MENU icon in the lower right corner. This opens the first submenu which mostly contains settings concerning the end user.     2 To access the second submenu which mostly contains settings concerning the installer (commissioning), select MENU icon in the lower right corner again.
  • Page 50 Allowed overheating temperature of the heating system. Heating / cooling stops - water ∆T Recommended setting: 2 °C. The heat pump is allowed to slightly overheat the system to maintain a low working speed and to avoid frequent stopping and starting of the compressor. Allowed temperature deviation in the heating/cooling circuits before the Heating / cooling restarts - water compressor restarts.
  • Page 51 (Zone 1 and Zone 2 parameter) Heating curve 1 (HC1) / Heating curve 2 (HC2) Select the checkbox to enable the function. Enabled: The heat pump produces hot water for the heating system according to the heating curve setting. Disabled: The heat pump produces hot water for the heating system according to the fixed temperature setting ( without heating Set temp.
  • Page 52 High temperature limit (Zone 1 and Zone 2 parameter) Highest allowed water temperature that the end user can set (without accessing the service level). Applicable for heating mode only. Default setting: 42 °C. NOTE If higher temperatures are required in the system the limitation must be increased (e.g.
  • Page 53 Water / Outdoor temp. 1 - HC1 /HC2 Water / Outdoor temp. 2 - HC1 /HC2 Water / Outdoor temp. 3 - HC1 /HC2 Heating curve - water temperatures Zone 1 / Zone 2 Water / Outdoor temp. 4 - HC1 /HC2 Water / Outdoor temp.

  • Page 54: Zone 2

    14.2.2 Cooling curve settings = cooling curve, = cooling curve for Zone 1, = cooling curve for Zone 2 Outdoor temp. 1 - CC Outdoor temp. 2 - CC Cooling curve - outdoor temperatures Outdoor temp. 3 - CC Water / Outdoor temp. 1 - CC1 / CC2 Water / Outdoor temp.

  • Page 55: Dhw

    14.4 DHW Table 52: Setpoint DHW Desired temperature for domestic hot water. DHW restart ∆T setting Allowed temperature deviation before the heating of the domestic hot water restarts. Recommended setting: 5 °C. Example: The Setpoint DHW parameter is set to 47 °C and the DHW restart ∆T setting parameter is set to 5 °C.
  • Page 56 Sanitary water min. working time The minimum time in minutes that the heat pump will heat the domestic hot (minutes) water for before it switches to heating mode. Applicable only if Shifting is enabled. priority NOTE This parameter has precedence although all other conditions for Shifting priority are met.

  • Page 57: Dhw Storage

    14.5 DHW storage When active, this function is indicated with the symbol in the top bar of the screen. Sanitary hot water storage Select the checkbox to enable the function. function Enabled: Hot water will be prepared only in the selected day and time periods set in parameter Sanitary hot water storage schedule Disabled: Normal operation of DHW mode.

  • Page 58: Night

    Reheating set temp. Desired temperature setting for the second mode of domestic hot water heating. This temperature will be the default temperature for the domestic hot water heating in the . The temperature can be lower or higher Reheating function than the primary setting of the desired domestic hot water temp.

  • Page 59: Legionella

    Schedule for Reduced Setpoint Schedule for activation of Reduced setpoint Function If the fields are green, is active. Reduced setpoint If the fields are grey, is not active. Reduced setpoint See section Section 11.3 "Setting the day and time for activation of a page 42 function", Quiet Operation...

  • Page 60: Vacation

    Day and time Schedule for activation of the anti-legionella program Set the day and time for the function to be switched on. Recommended setting: Monday at 2:00 AM Setpoint Desired temperature (setpoint) of the anti-legionella program Duration Time during which the heat pump should maintain the desired temperature in anti-legionella program Finish Time Time during which the anti-legionella should run.

  • Page 61: User

    14.9 User The User menu is intended for both installers and users, but some parameter settings require installer level access. For those parameters the user can see the settings but is not allowed to change anything. Permission level Enter the service password to access the service / installer level. Installer code: 87654321 Heating / cooling ON/OFF Select the checkbox to enable the function.

  • Page 62: Working Mode

    Save current settings Installer code protected setting, not available for end user. Saves all the settings at the end of a start-up. The end user can recall the saved settings by selecting Load saved , which resets the system to the settings done during the start-up. settings Load saved settings Reset of the system to the installation settings stored during the last...
  • Page 63 Sanitary hot water Select the checkbox to enable the function. Production of sanitary hot water (DHW) if demanded from the system. Heating Select the checkbox to enable the function Production of hot water for the heating system and control of the heating circuits if needed.
  • Page 64 Heating / cooling switch Selection of switch function. – OFF: Manual switching only.     – Outdoor temp.: Automatic switching between heating mode and cooling mode according to the average outdoor temperature.     – External signal control: Automatic switching based exclusively on a signal received to contacts HS - COM (heating signal) and CS –...

  • Page 65: Back-Up

    NOTE To prevent too frequent switches between operation and non-operation, the control unit monitors the current temperature and temperature within a certain period and decides based on this whether heating should be activated or blocked. Example (cooling): The set temperature to start cooling is 25 °C. Heat pump will cool the facility depending on the set values if the outdoor temperature rises above 25 °C.
  • Page 66 Backup heating sources for Select the checkbox to enable the function. heating Enabled: The heat pump connects two additional backup heating sources in two stages (AH + HBH). Disabled: The heat pump uses only AH as a backup heating source. Priority for backup heating Selection of relays to be connected in the first and second stage.

  • Page 67: Water Pump Settings

    Block the working of auxiliary Select the checkbox to enable the function. heater (AH) according to outdoor Enabled: Blocking of the AH heating function according to the outdoor temp temperature set in parameter Set outdoor temp. to block the working of auxiliary heater Disabled: Normal operation of the AH backup heating source (according to settings).
  • Page 68 P2: Heating / cooling circuit 2 – Zone 2 (after buffer tank) Circulation pump P0 type Control setting of the P0 circulation pump. PWM control – speed controlled DC Variable speed pump: ON/OFF control AC Pump: Working Mode of Circulation Function of the circulation pump P0 Pump P0...
  • Page 69 P2 for cooling operation Select the checkbox to enable the function. Enabled: P2 is used for cooling circuit 2 – Zone 2 Disabled: P2 is not used for cooling circuit 2 – Zone 2. During cooling mode P2 will be OFF. P2 with high temp.

  • Page 70: Floor Curing 1

    Speed setting of circulation pump will run in high speed during DHW High speed: circulation pump P0 in DHW operation operation. will run in middle speed during Middle speed: circulation pump P0 DHW operation. will run in low speed during DHW Low speed: circulation pump P0 operation.
  • Page 71 When the floor curing procedure is finished the heat pump returns to normal operation. 14.13.1 Accessing floor curing settings 1 Tap the Floor curing icon on the Submenu 2 screen.     2 Tap Floor curing (default OFF).     3 Select one of the two options Floor curing 1 or Floor curing 2, and tap OK.

  • Page 72: Electric Lock

    14.14 Electric lock When active, this function is indicated with the symbol in the top bar of the screen Electrical Utility Lock, or EUL, is used in some countries where the industry has a particularly high demand on electrical power one or multiple times a day. The electricity distribution companies send a signal to the households that stops all high-power electrical consumption systems for a period of time.

  • Page 73: Other Options

    14.15 Other options Motorized diverting valve Switching time of the diverting valve (minutes). switching time Diverting valve - power on time Time setting that determines how long the diverting valve will have power in a particular mode. Setting range: 0 to 16 minutes (0 minutes = Always with power) Refrigerant recycle function Function used for pumping the refrigerant back to the outdoor unit.
  • Page 74 Control panel backlight light Selection of the standby time for the backlight of the control panel display After the set minutes of inactivity, the display turns black. Always on 3 min 5 min 10 min To turn on the display backlight again, tap the screen. NOTE It is not recommended to set this parameter to Always on as this will shorten the life of the display.
  • Page 75 Mode signal output Function that determines during which mode (heating or cooling) the Mode Signal (MS) contact will be active. When the unit goes to cooling mode, MS gives a signal according to Cooling: the setting in Mode Signal Type When the unit goes to heating mode, MS gives a signal according to Heating: the setting in...

  • Page 76: Real Time Data

    The MAC address is the identity of the unit. If the address is 00-00-00-00-00-00, check the LAN cable connection or the connection from the unit to the Wi-Fi module. NOTE The MAC address is different if connected via LAN cable or Wi-Fi module.

  • Page 77: Info Page

    Discharge temp. – Td Hot gas temperature of the compressor. Suction temp. – Ts Suction temperature of the compressor. Outdoor coil temp. Tp Evaporator temperature. Heat pump accumulated operation time Heat pump accumulated operation time. Preserved Preserved Fan speed 1 Fan 1 running speed.
  • Page 78 Heating / Cooling (direct circuit or Buffer Tank) DHW Temperature Mixing Circuit 1 Mixing Circuit 2 Room Temperature Line status 1 Communication – Touch Screen controller to the Indoor PCB 90–100% = normal communication Line status 2 Communication – Touch Screen controller to the Outdoor PCB 90–100% = normal communication Pump speed 100 = Pump P0 Activated...

  • Page 79: Error Codes

    Condenser Outlet Temperature Sensor Liquid Refrigerant Temperature Sensor Suction Temperature (Compressor) Sensor Discharge Temperature (Compressor) Sensor – Hot Gas Temperature Evaporation Temperature Sensor Low pressure – Suction pressure High pressure – Discharge pressure Fan 1, 2 Fan speed for Fan 1 and Fan 2 14.18 Error codes If some faults happen and some errors appear, it is not always because of the heat pump itself.

  • Page 80: Internet Connection

    to go to the Info Page.     Tap the right arrow icon in the lower right corner until a list of active and historic errors opens.     4 To view detailed information about the error, tap to select the error code, then tap More info. Additional info is displayed regarding the status of the heat pump at the time when the error happened.

  • Page 81: Connection Directly To House Router

    The heat pump can also be connected via an additional Wi-Fi repeater which is freely available on the market. For the connection to be possible the Wi-Fi repeater requires an RJ45 port. Heat pump controller Wi-Fi repeater (not supplied by Energy Save) LAN cable Router...

  • Page 82: Verifying Connection To Router

    15.4 Adding the heat pump to the Energy Save server 1 Log in to http://www.myheatpump.com with your installer access data. NOTE If you do not have the access data (username and password), contact your Energy Save heat pump dealer.  ...

  • Page 83: Service And Maintenance

    This ensures that the technicians have the necessary knowledge, skills, and experience to complete the job correctly and in accordance with safety regulations and specifications of Energy Save. Make sure the service area is not enclosed and provide good ventilation (opening doors and windows). The service area must be properly isolated.
  • Page 84 Inspection of pump Check the water pump. Listen for the pump! With the system on, there should be a consistent hum or whirring sound. Feeling the pipes near the pump for vibration can also confirm operation. Visually check for leaks around the pump connections. Leak inspection Perform a leak test of the system.

  • Page 85: Maintenance Intervals

    Emergency treatment An emergency plan should be prepared for the service site, and daily preventive measures should be carried out. For example, fire is forbidden at the service site, and it is prohibited to wear clothing or shoes which can generate static or sparks.

  • Page 86: Maintenance Checklist Hydraulic System

    Legend Indoor unit / distribution system Outdoor unit IN + OUT Indoor and outdoor unit IN / OUT Indoor or outdoor unit, depending on the heat pump type SYSTEM External installation (not included in the heat pump) Or / and according to the local regulations Some of the following specified procedures might apply to some models only.

  • Page 87: Maintenance Checklist Refrigerant System

    17.6 Maintenance checklist refrigerant system Hydraulic system Applies to: Annual Every 2 years Every 4 years Visually inspect all connections for any damage. * Perform a leak detection check. Clean the heat exchanger (Evaporator) with clean water. Don’t use high pressure water. 17.7 Other maintenance checks Hydraulic system Applies to: Annual...

  • Page 88: Appendix A: Error Codes

    19 Appendix A: Error codes 19.1 Heat pump error list Code Name Heat pump status Possible reasons and solutions Main line current protection Compressor stops Input current is too high or too low or the system works in over-load condition. Unit recovers automatically after 5 minutes when it happened the first time.
  • Page 89 Code Name Heat pump status Possible reasons and solutions Compressor shut down due Compressor stops If system pressure is too high or too low, it to high/low pressure switch activates this protection. Unit recovers open caused by abnormal automatically after 5 minutes when it happened the high/low pressure first time.
  • Page 90 Code Name Heat pump status Possible reasons and solutions Compressor speed limited Compressor speed down Not enough refrigerant in the system, low inlet due to low condensing water temperature, Air flow on the evaporator pressure restricted, EEV not working properly, broken cable to the EEV.
  • Page 91 Code Name Heat pump status Possible reasons and solutions System evaporating pressure Compressor stops If system too low-pressure protection detected by too low evaporating pressure sensor happened 3 times in a certain period, it gives this failure code and unit can't be restarted until repowered.
  • Page 92 Code Name Heat pump status Possible reasons and solutions Compressor phase current Compressor stops Check if the power cable to the compressor is failure broken or short-circuited. Compressor phase current Compressor stops Check if the power cable to compressor is broken overload (over current) or short-circuited.
  • Page 93 Code Name Heat pump status Possible reasons and solutions Power plus offline Unit stops Communication between CPP controller and driver is OFF. Check if the wiring is loosened or not. Power plus generic AL Unit stops Check if the 3-phase power for outdoor unit is OK or not.
  • Page 94 Code Name Heat pump status Possible reasons and solutions High evap. temp. EVO Unit stops Bad ventilation condition for outdoor unit fans. Check if there is an obstacle at the fan system. Not enough water flow leads to low heat exchange in condenser.
  • Page 95 Code Name Heat pump status Possible reasons and solutions Amb. temp. probe fault (B1) Unit stops Sensor wiring is loosened, or sensor is defective. Check the wiring, if wiring is OK, check the sensors resistance. If resistance is not OK, replace the sensor.
  • Page 96 Code Name Heat pump status Possible reasons and solutions High press. swtich defect Unit stops Too much refrigerant. Reclaim and vacuum and inject the correct amount. There is air inside the refrigerant system. Vacuum again and inject new refrigerant. Not enough water flow leads to low heat exchange in condenser.
  • Page 97 Code Name Heat pump status Possible reasons and solutions Unit water outlet temp. Unit keeps on working, use Check if unit water outlet temperature sensor is sensor failure unit water inlet temperature open, short-circuited or value drifts too much. as reference. Replace it if necessary.
  • Page 98 Code Name Heat pump status Possible reasons and solutions Indoor anti-freezing Compressor speed down or Compressor speed down if coil temp. lower than protection in cooling stop 2 °C; Compressor stops if coil temp. lower than -1 °C; Compressor restarts if coil Temp. higher than 6 °C. Check if the set temperature for cooling is too low;...
  • Page 99 Code Name Heat pump status Possible reasons and solutions Water outlet temp. too low Compressor stops Compressor stops if water outlet is lower than 5 °C protection in cooling in cooling mode. Check if the temperature sensor Tc is OK and well connected;...

  • Page 100: Appendix B: Wiring Diagrams

    20 Appendix B: Wiring diagrams 20.1 Indoor unit wiring diagrams 20.1.1 Monobloc units Figure 6: AWC-R32-M-V8; 6-19 kW 100 | Installation Manual...
  • Page 101 Figure 7: AWST-R32-M-V8; 6-15 kW Installation Manual | 101...
  • Page 102 20.1.2 Split units Figure 8: AWH-R32-S-V8; 6-12 kW 102 | Installation Manual...
  • Page 103 Figure 9: AWST-R32-S-V8; 6-12 kW Installation Manual | 103...

  • Page 104: Outdoor Unit Wiring Diagrams

    20.2 Outdoor unit wiring diagrams 20.2.1 Monobloc units Figure 10: AW-R32-M-V8; 6-12 kW Figure 11: AW-R32-M-V8; 15-19 kW 104 | Installation Manual...

  • Page 105: Dip Switch Default Settings Aw-R32-M-V8; 15-19 Kw

    20.2.2 Split units Figure 12: AW-R32-S-V8; 6-12 kW 20.3 Dip switch default settings AW-R32-M-V8; 15-19 kW NOTE 0: OFF 1: ON Compressor drive PCB SW1: Compressor model selection Compressor model no. SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 AW15-R32-M-V8 AW19-R32-M-V8 SW2: Reserved SW3: Reserved Installation Manual | 105...
  • Page 106 Main PCB (Power PCB) Table 88: SW1 Default Setting Function SW1-1 Fixed setting for 15-19 kW model SW1-2 SW1-3 Reserved SW1-4 Reserved SW1-5 Reserved SW1-6 Communication address selection for outdoor unit SW1-7 000: Address 1 SW1-8 001: Address 2 (default) 010: Address 3 011: Address 4 100: Address 5 101: Address 6...

  • Page 107: Appendix C: Dimension Drawings

    21 Appendix C: Dimension drawings 21.1 Indoor unit dimensions Figure 13: AWC-R32-M-V8; 6-19 kW Figure 14: AWST-R32-M-V8; 6-15 kW and AWST-R32-S-V8; 6-12 kW Installation Manual | 107...

  • Page 108: Outdoor Unit Dimensions

    Figure 15: AWH-R32-S-V8; 6-12 kW 21.2 Outdoor unit dimensions Figure 16: AW6-R32-M-V8 108 | Installation Manual...
  • Page 109 Figure 17: AW-R32-M-V8; 9-12 kW Figure 18: AW-R32-M-V8; 15-19 kW Installation Manual | 109...
  • Page 110 Figure 19: AW6-R32-S-V8 Figure 20: AW-R32-S-V8; 9-12 kW 110 | Installation Manual...

  • Page 111: Appendix D: Technical Data

    22 Appendix D: Technical data 22.1 AWC-R32-M-V8; 6-12 kW Unit AWC6-R32-M-V8 AWC9-R32-M-V8 AWC12-R32-M-V8 Min/max heating capacity 3.50 / 6.50 4.30 / 9.20 5.50 / 11.60 El. power input in heating min/max 758 / 1410 927 / 2097 1107 / 2683 COP min/max 4.50 / 4.70 4.38 / 4.71 4.30 / 4.90...

  • Page 112: Awc-R32-M-V8; 15-19 Kw

    Unit AWC6-R32-M-V8 AWC9-R32-M-V8 AWC12-R32-M-V8 Power supply, grounded V/Hz/A 230 / 50 / 10 230 / 50 / 16 230 / 50 / 16 Refrigerant type R32 / 0.90 R32 / 1.40 R32 / 1.80 Dimensions Outdoor unit 1025×397×750 1207×412×900 1207×412×900 (W×D×H) Indoor unit 380×115×450 Net weight Outdoor unit 79.5 98.5...

  • Page 113: Awst-R32-M-V8; 6-9 Kw

    Unit AWC15-R32-M-V8 AWC19-R32-M-V8 Residual current device and overvoltage protection Required Power supply, grounded V/Hz/A 400 V/3 N/50 Hz/3-p 16 A 400 V/3 N/50 Hz/3-p 16 A Refrigerant type R32 / 2.55 R32 / 2.60 Outdoor unit 1106×416×1498 1106×416×1498 Dimensions (W×D×H) Indoor unit 380×115×450 Outdoor unit Net weight Indoor unit Article number indoor/outdoor 120315 / 120320 120315 / 120321...

  • Page 114: Awst-R32-M-V8; 12-15 Kw

    Unit AWST6-R32-M-V8 AWST9-R32-M-V8 Type / mass of refrigerant R32 / 0.90 R32 / 1.40 Type of connection between indoor-outdoor unit Hydraulic connection Dimensions of refrigerant pipes connectors Inch G1" SOUND POWER AND SOUND PRESSURE LEVEL Sound power level LwA - indoor unit dB(A) Sound power level LwA - outdoor unit*** dB(A)

  • Page 115: Awh-R32-S-V8, 6-12 Kw

    Unit AWST12-R32-M-V8 AWST15-R32-M-V8 Indoor unit + electric flow heater V/ph/fuse 230 V/3-ph/25 A/C or 400 V/3-ph/16 A/C Anti-freeze protection outdoor V/ph/fuse 230 V/1-ph/6 A/C REFRIGERANT SPECIFICATION Type / mass of refrigerant R32 / 1.80 R32 / 2.55 Type of connection between indoor-outdoor unit Hydraulic connection Dimensions of refrigerant pipes connectors Inch G1"...

  • Page 116: Awst-R32-S-V8, 6-12 Kw

    Unit AWH6-R32-S-V8 AWH9-R32-S-V8 AWH12-R32-S-V8 REFRIGERANT SPECIFICATION Type / mass of refrigerant R32 / 0.90 R32 / 1.40 R32 / 1.80 Type of connection between Refrigerant flare connection indoor-outdoor unit Dimensions of refrigerant pipes Inch ¼ and ½ 3/8 and 5/8 connectors SOUND POWER AND SOUND PRESSURE LEVEL...
  • Page 117 Unit AWST6-R32-S-V8 AWST9-R32-S-V8 AWST12-R32-S-V8 EER max – energy efficiency 4.45 4.60 3.80 ratio** Min. temperature of cooling °C water Operating range cooling °C +8 to +65 POWER SUPPLY – SPECIFICATIONS Outdoor unit V/ph/fuse 230 V/1-ph/10 A/C 230 V/1-ph/16 A/C Indoor unit + electric flow V/ph/fuse 230 V/3-ph/25 A/C or 400 V/3-ph/16 A/C heater...

  • Page 118: Appendix E: Included In The Package

    23 Appendix E: Included in the package 23.1 AWC-R32-M-V8; 6-19 kW Description Quantity Manuals 1 pcs Temperature sensors: 1 pcs / each TC - Heating / cooling temp. sensor TW - Domestic hot water temp. sensor TR - Room temperature temp. sensor TV1 - Mixing circuit 1 temp. sensor TV2 - Mixing circuit 2 temp.

  • Page 119: Awst-R32-S-V8; 6-12 Kw

    23.3 AWST-R32-S-V8; 6-12 kW Description Quantity Manuals 1 pcs Temperature sensors: 1 pcs / each TC - Heating / cooling temp. sensor TR - Room temperature temp. sensor TV1 - Mixing circuit 1 temp. sensor TV2 - Mixing circuit 2 temp. sensor Extension cables for temperature sensors 4 pcs Communication cable (indoor - outdoor unit) 1 pcs...
  • Page 120 For more information, feel free to contact us. Your ES team. www.energysave.se We reserve the right to make changes that do not impair the functionality of the device.

This manual is also suitable for:

Awc6-r32-m-v8Awc9-r32-m-v8Awc12-r32-m-v8Awc15-r32-m-v8Awc19-r32-m-v8Awst6-r32-m-v8 ... Show all

Table of Contents
