Genoss Easy Check User Manual

Implant stability measuring device
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Easy Check
User Manual
Implant Stability Measuring Device
MADE IN KOREA
EMERGO EUROPE
Prinsessegracht 20 2514 AP, The Hague, The Netherlands
genoss co.,ltd.
Manufacturer
1F Gyeonggi R&D Center 105, Gwanggyo-ro, Yeongtong-gu,
Suwon-si, Gyeonggi-do, Korea
www.genoss.com
Dentium Co.,Ltd.
Distributor
76, Changnyong-daero 256beon-gil, Yeongtong-gu, Suwon-si, Yeongtong-gu,
Gyeonggi-do, Republic of Korea
www.dentium.co.kr
MS-P2518 / IFU-DE1802 (Rev.1,2104)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Check and is the answer not in the manual?

Questions and answers

Related Manuals for Genoss Easy Check

Summary of Contents for Genoss Easy Check

  • Page 1 Easy Check User Manual Implant Stability Measuring Device MADE IN KOREA EMERGO EUROPE Prinsessegracht 20 2514 AP, The Hague, The Netherlands genoss co.,ltd. Dentium Co.,Ltd. Manufacturer Distributor 1F Gyeonggi R&D Center 105, Gwanggyo-ro, Yeongtong-gu, 76, Changnyong-daero 256beon-gil, Yeongtong-gu, Suwon-si, Yeongtong-gu,...
  • Page 2 User Manual Easy Check Implant Stability Measuring Device genoss co.,ltd.

  • Page 4: Table Of Contents

    Table of Contents 1 Introduction 2 Product components 3 Specification 4 Instructions for use 5 Display 6 Precautions 7 Maintenance 8 Symbol 9 Electromagnetic Compatibility for EC-1.0 10 Warranty and service...
  • Page 5 Notice Thank you for purchasing the Easy Check (Dental implant stability measuring device) This manual details the usage, handling, care and overall use. Please read this manual in advance for proper use of the equipment. Please keep the User manual near the equipment so that you can refer to them at any time.

  • Page 6: Introduction

    1.1 Product Description Easy Check is the value on a scale that indicates the level of stability and osseointegration in dental implants. The scale ranges from 1 to 99, with higher values indicating greater stability. Easy Check values are obtained using mechanically hit. Easy Check is a clinically valuable measurement of the strength of implant anchorage in the bone during placement and in the post-osseointegration period.

  • Page 7: Product Components

    2 Product components Attack Pole ② Power and Operation Button ③ LCD Window ④ Front Housing ① Cradle ⑤ USB Connector Cradle ⑦ Accessory Download Port ⑥ Easy Check USB C-Type Calibrator ⑧ ⑨ / User Manual...
  • Page 8 2.1 Main Body Name Description ① Front Housing The part that acts as a guide to the attack pole in case of hit ② Attack Pole The Part that measures implant stability by striking the implant Healing Abutment. The power is turned on/off when the button is pressed long time. Power and Operation Button ③...
  • Page 9 2.2 Cradle assembly and instructions for use ① Insert the cradle into the metal inside the package. ② keep the main body on the cradle for storage. ▶ ▶ Metal Completed image Holding method / User Manual...

  • Page 10: Specification

    3 Specification Product Name Easy Check Model EC-1.0 Weight(g) Main Body Size(mm) 214.3x 26.0 x 26.0 Weight(g) Cradle Size(mm) 78.9 x 111.4 x 99.3 Accuracy Display value ±3 Measuring angle 0~90° Time of measurement Under 3 seconds Strength of hit Under 1.0N...

  • Page 11: Instructions For Use

    4 Instructions for use 4.1 Charging ① Connect the USB cable to back of main body. And then, Connect the opposite side to the adaptor. ② Approximately 1hour be taken to fully charge after discharge. ③ Rated voltage : DC 3.7V, 420mAh (USB C-type) Caution ·...

  • Page 12: Cleaning & Sterilization

    4.2 Cleaning & Sterilization Please follow the instructions in the below to prevent secondary infection due to contamination of the device. Cleaning ① Wash outside of the device body by using 80% of ethanol alcohol for prevention of infection. ② Do not let alien substances such as detergent or water get into the main body. Front Housing Caution ·...

  • Page 13: Method Of Operation

    4.3 Preparation Before Use ① Insert the Front Housing inside the Calibrator. Calibrator ② Press the power and operation button to measure the value of the Calibrator. ③ Confirm that the value shown on the LCD is within the error range(±3) of the value shown on the Calibrator. ④...

  • Page 14: Measuring Method

    ① The abbreviation for the mobility measurement value is ISV (Implant Stability Value). ② Easy Check does not work while charging. After charging is complete, separate the charging cable from the device. ③ Front Housing and Attack Pole should be sterilized to prevent cross-infection before use.
  • Page 15 Primary Secondary Front Housing Healing Abutment Measurement Measurement 90˚ ⑤ When the operation button is pressed shortly, the buzzer and the striking rod strike the healing abutment to measure the implant stability. First measurement, the ISV is displayed on the lower part of the LCD. Second measurement, the ISV is displayed on the LCD and the previous value is displayed in small size.
  • Page 16 ⑧ If Easy check is measured at a negative angle, the result is not displayed and an “X” is displayed on the LCD with a beep sound If the unit is operated with the unit tilted at a negative angle while the unit is level with the ground, the unit does not operate and the “X” letter is displayed on the LCD with a beep sound Use 0~90°...
  • Page 17 4.6 Confirm Result ① Healing Abutment is based on H3.5mm. Please refer to the table below for correction. ② H 0.5mm higher is corrected for ISV +1, lowered by -1 correction for ISV. Healing Abutment 3.5mm ③ Dual Abutment is based on G/H1.0mm. Please refer to the table below for correction. ④...
  • Page 18 4.7 Storage method after use ① User sterilization for Front Housing and Attack Pole is required after use. ② To keep the body clean, lightly wash it with a alcohol cotton and dry cloth. ③ Storage in a place not exposed to direct sunlight or in a safe place out of water. 4.8 Limitation on processing ①...

  • Page 19: Display

    5 Display 5.1 Operation Mode Indication Condition Method of operation LCD Display Sound Vibration Operation Vibration Power On Press the Operation Button. (3times) (1time) Operation Vibration Power Off Press the Operation Button again. Turned off. (3times) (1time) Press the Operation Button shortly, Operation Operation the device operate.
  • Page 20 Indication Condition Method of operation LCD Display Sound Vibration Vibration Start Charging The charging cable is connected with the main body. No Operation (1time) Operation Operate error When the main body angle exceeds 0℃~90℃ No Operation (1time) End Charging The charging cable is removed from the main body. Turned Off No Operation No Operation...

  • Page 21: Precautions

    6 Precaution ④ The use is prohibited in high-temperature environments such as heaters, 6.1 Precautions for Use heat fans, and fire-resistant products. ① Be sure to understand the user manual completely before using. ⑤ Maintenance is prohibited during operation. Be sure to turn off the power ②...

  • Page 22: Maintenance

    7 Maintenance Refer to following contents how to change the battery. ① Loosen the screw at Battery Cover using screwdriver. ② Remove the Battery Cover. ③ Remove the connector and socket of the main board. ④ Connect the connector of the new Battery to the socket of the main board. ⑤...

  • Page 23: Symbol

    8 Symbol Symbol Description Symbol Description Manufacturer Refer to instruction manual / booklet Date of manufacture Type B applied part Lot Number Recycle: Electronic equipment Serial Number Caution and warning Storage Temperature Do not use if package is damaged CE Mark Control Device Authorized representative / User Manual...

  • Page 24: Electromagnetic Compatibility For

    9. Electromagnetic Compatibility for EC-1.0EMC Guidance and Manufacturer’s Declaration – Electromagnetic Compatibility Guidance and manufacturer’s declaration – electromagnetic emissions EC-1.0 is intended for use in the electromagnetic environment specified below. The customer or the user of the EC-1.0 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment-Guidance...
  • Page 25 Guidance and manufacturer’s declaration – electromagnetic immunity The EC-1.0 is intended for use in the electromagnetic environment specified below. The customer or the user of the EC-1.0 should assure that it is use in such an environment. IMMUNITY test IEC 60601 test level Compliance level Electromagnetic environment –...
  • Page 26 Recommended separation distances between portable and mobile communication equipment and Derma LD Scalp Care The EC-1.0 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EC-1.0 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EC-1.0 as recommended below, according to the maximum output power of the communications equipment.
  • Page 27 Guidance and manufacturer's declaration - electromagnetic immunity The EC-1.0 is intended for use in the electromagnetic environment specified below. The customer or the user of the EC-1.0 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment- guidance Portable and mobile RF communications...
  • Page 28 a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy b. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the EC-1.0 is used exceeds the applicable RF compliance level above, the EC-1.0 should be observed to verify normal operation.
  • Page 29 Guidance and Manufacturer`s Declaration – Electromagnetic Immunity This product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. Portable RF communications equipments should be used no closer than 30 cm (12 inches) to any parts of the product. Otherwise, the performance of this equipment could be degraded. Guidance and manufacturer's declaration - electromagnetic immunity The EC-1.0 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
  • Page 30 Immunity test Band a Service a Modulation IEC60601 test level Compliance level GSM 1800 CDMA 1900 GSM 1900 1700 – 1990 MHz Pulse modulation 217 Hz 28 V/m 28V/m DECT LTE Band 1,2,4,25 Proximity fields from UMTS RF wireless Bluetooth Communications WLAN IEC61000-4-3...

  • Page 31: Warranty And Service

    10 Warranty and Service GENOSS Co.,Ltd. Warrants to customer that there are no defects in materials and workmanship under normal use and service for a certain period of one year from the date of purchase of Easy Check. The product warranty is conditioned on the correct use of the product by the customer. During the warranty period, GENOSS Co., Ltd will repair or replace defective parts of the product free of charge to the customer.
  • Page 32 Easy Check Implant Stability Measuring Device User Manual...
