- Page 1 Smartfloor - Modular Floor System Smartfloor installation & assembly instructions General view of the Smartfloor Modular floor system SMARTFLOOR B.V. | Bedrijvenpark Twente 415 | 7602 KM Almelo Member of Tel. +31 546 45 55 65 | www.smartfloor.nl AMF-Bruns group...
-
Page 2: Table Of Contents
3.4 Connecting the profiles................10 3.5 Determine carpet size & glue applying..........1 1 3.6 Trimming carpet floor................12 3.7 Mount & secure the Airline Rails onto the Smartfloor......12 3.8 Cleaning the Smartfloor & vehicle floor..........13 3.9 Applying glue and plastic spacers............14 3.10 Placement of the Smartfloor into the vehicle........15... - Page 3 Foreword Dear reader, These Installation Instructions serve to provide all information required for a correct and safe installation of the Smartfloor. The Smartfloor is designed and constructed in accordance with state of-the-art technology and recognised safety standards. Inspect the underside of the vehicle floor and note wiring, cross members, frames, fuel tanks and other possible obstructions before beginning installation.
-
Page 4: Explanation Of Symbols And Signs
Gives a reference to important information in other sections and documents. Contains general notes and useful information. SMARTFLOOR B.V. | Bedrijvenpark Twente 415 | 7602 KM Almelo Member of Tel. +31 546 45 55 65 | www.smartfloor.nl... -
Page 5: Safety
Installation Manual 1. Safety The installation company itself is responsible for adherence to the safety regulations when installing the Smartfloor. Installation is carried out at the sole risk installation company. The manufacturer will accept no liability whatsoever for damage caused during installation of the Smartfloor. -
Page 6: Product Description
Modular floor system The Smartfloor consists of several aluminium profiles that can be linked together. The length of the profiles is tailored to the length of the vehicles, in which the Smartfloor is installed. The profiles are connected to each other by the use of our assembly plugs. -
Page 7: Orientation & Placement Possibilities Of The Smartfloor
Installation Manual 2. Product description 2.2 Orientation & placement possibilities of the smartfloor • The Smartfloor must be installed over the entire width of the FRONT vehicle floor (A). • It is permitted to place the Smartfloor at any position over the entire vehicle length (B). -
Page 8: Installation
1 1. Spirit level/Tri square sausage ) 12. Knife ( carpet cutter ) 6. Steel rod 13. Paint roller SMARTFLOOR B.V. | Bedrijvenpark Twente 415 | 7602 KM Almelo Member of Tel. +31 546 45 55 65 | www.smartfloor.nl AMF-Bruns group... -
Page 9: Installation Materials
Use these products according to the FIFO method. First in, first out! 5000mm 4000mm 3000mm 2000mm 1000mm Quantity of assembly plugs per set of profiles SMARTFLOOR B.V. | Bedrijvenpark Twente 415 | 7602 KM Almelo Member of Tel. +31 546 45 55 65 | www.smartfloor.nl AMF-Bruns group... -
Page 10: Alignment Of The Profiles
Installation Manual 3. Installation 3.3 Alignment of the profiles The Smartfloor is made up of a number of specially designed profiles. Check front and rear of panels, place back side towards you. 2. Position profiles in correct assembly order ( How to spot the rear of profiles: •... -
Page 11: Determine Carpet Size & Glue Applying
4. Wait for approximately 5 minutes to let the glue dry a little bit. 5. When drying is done fold back the carpet half evenly and in small steps. Push the carpet with pressure onto the Smartfloor. 6. Repeat previous steps for the other carpet half. -
Page 12: Trimming Carpet Floor
If this doesn’t correspond, than you have to switch sides and rotate the airline 180 degrees. 3. Mount the Airline Rail into the Smartfloor Basic profiles with the supplied M10x25 A2 stainless-steel bolts (class-70) . These bolts need to be tightened to a torque of 18Nm with a tolerance of ± 10%. -
Page 13: Cleaning The Smartfloor & Vehicle Floor
View underneath the Smartfloor Before accessing the vehicle for glueing, be aware to access vehicle only with clean shoes! SMARTFLOOR B.V. | Bedrijvenpark Twente 415 | 7602 KM Almelo Member of Tel. +31 546 45 55 65 | www.smartfloor.nl AMF-Bruns group... -
Page 14: Applying Glue And Plastic Spacers
Start from the front of the vehicle. 3. Apply glue to all the higher floor surfaces of the vehicle, that will make contact with the Smartfloor and start from the front. 4. Apply glue to all the holes in the vehicle floor, that are out of use. -
Page 15: Placement Of The Smartfloor Into The Vehicle
3. Installation 3.10 Placement of the Smartfloor into the vehicle For placement of a one piece or 2 halves fully assembled Smartfloor into the vehicle, a minimum of 2 persons are required. It is very advisable to dry fit the Smartfloor before applying the glue. -
Page 16: Drilling Positions Through Vehicle Floor
• Check underneath the bottom of the vehicle for the most suitable position to drill without any obstacles. • Use 1 of the first 3 holes in the rail of the Smartfloor to de- �� termine the drilling positions at the backside of the vehicle. -
Page 17: Mounting The Lock Plates
Installation Manual 3. Installation 3.12 Mounting the Lock Plates For securing the Smartfloor to the vehicle, use the supplied Lock Plates and M10x60 bolts A2 stainless-steel with nuts (class-70). If required, M10x200 bolts can be supplied with the Smartfloor kit. -
Page 18: Finalizing Installation Process
3.13 Finalizing installation process Applying Silicone ( optional ) For the finishing touch after the Smartfloor is installed, apply an evenly amount of silicone along the outer edges. Floor End Cover Strip ( optional ) Mount and apply a cover strip at the backside of the Smartfloor for the final touch to cover the profile holes and finishing look. -
Page 19: Maintenance
4.2 4. Perform a wet cleaning if necessary and let the floor dry before use ( see next section 4.2 The following cleaning products are not allowed to use when cleaning the Smartfloor: • Harsh detergents • Oily soaps •...
