Toro Haven 163-1940 Installation Instructions
Toro Haven 163-1940 Installation Instructions

Toro Haven 163-1940 Installation Instructions

Robotic lawn mower front caster rework

Advertisement

Quick Links

Front Caster Rework
Haven
Model No. 163-1940
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
No parts required
No parts required
No parts required
Upper bearing support
Lower bearing support
Bolt (5/16 x 2 inches)
Nut
Bushing
Washer
Caster wheel assembly
Cotter pin
No parts required
Preparing the Machine
1.
Press the STOP button and wait for all moving parts to stop.
2.
Turn the mower on its side.
3.
Turn the power switch to the O
1. O
position
FF
© 2025—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Robotic Lawn Mower
Qty.
2
2
1
1
2
4
2
2
position.
FF
Register at www.Toro.com.
Prepare the machine.
Remove the shroud.
Remove the existing bearings.
Install the kit.
Install the shroud.
Figure 1
2. O
position
N
Original Instructions (EN)
Printed in the USA
All Rights Reserved
Form No. 3473-370 Rev A
Installation Instructions
Use
*3473-370*
g535280
