Air Cooled Scroll Chiller
Installation, Operation and Maintenance Manual
RHAG/RCAG***HA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHAG HA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Midea RHAG HA Series

Summary of Contents for Midea RHAG HA Series

  • Page 1 Air Cooled Scroll Chiller Installation, Operation and Maintenance Manual RHAG/RCAG***HA...

  • Page 2: Safety Precautions

    Safety Precautions To gain full advantage of the chiller's functions and to avoid malfunction due to mishandling, we recommend that you read this instruction manual carefully before use. This chiller is classified under "appliances not accessible to the general public". The precautions described herein are classified as WARNING and CAUTION.
  • Page 3 amount of any leaked refrigerant does not exceed the concentration limit in the event of a leakage. Otherwise, this may lead to an accident due to oxygen depletion. Contact professional personnel about attachment of accessories and be sure to use only accessories specified by the manufacturer.
  • Page 4 ! CAUTION Do not use the chiller for purposes other than those for which it is intended. Do not use the chiller for cooling precision instruments, food, plants, animals or works of art as this may adversely affect the performance, quality and/or longevity of the object concerned. Do not remove the chiller's fan guard.
  • Page 5 Do not remove the front panel. Touching certain internal parts will cause electric shocks and damage to the unit. Please consult your dealer about checking and adjustment of internal parts. Do not leave the control panel wherever there is a risk of wetting. If water gets into the remote controller there is a risk of electrical leakage and damage to electronic components.
  • Page 6 are opened or closed when they shouldn't be, water may leak and in worse cases, the equipment may catch fire or explode.
  • Page 7 Refrigerant 1. The refrigerant R410A used by the RHAG/RCAG***HA series units from Midea is a new type of environmentally friendly refrigerant that does not destroy the ozone layer. The operating pressure is about 1.6 times higher than the common R22. The new refrigerant R410A consists of two quasi azeotropic mixtures, R32 and R125, each of which accounts for 50%.

  • Page 8: Table Of Contents

    Contents 1 Introduction ....................... 9 1.1 Operation Range ......................9 1.2 The Unit ..........................9 2 Specifications......................11 2.1 Water Flow Rate ......................11 2.2 Variable Flow of Evaporator ..................11 3 Accessories ......................12 3.1 Standard Accessory Table ................... 12 3.2 Optional Accessories List ....................

  • Page 9: Introduction

    1 Introduction 1.1 Operation Range Operating range Content Cooling Heating Ambient temperature 0°C to 48°C -15°C to 48°C Water outlet temperature 5°C to 20°C 20°C to 50°C Water flow rate Rated flow rate 50% ~ 130% Max. water inlet/outlet 10°C temperature difference Voltage Rated voltage ±10%...

  • Page 10: Fan Motor

    1.2.2 Evaporator The 2-pass dual circuit shell and tube type direct expansion (DX) heat exchanger has refrigerant in the tubes and liquid flowing through the baffled shell. The waterside (shell) design working pressure is 1.0MPa. The refrigerant side is protected by pressure relief valve(s). The Victaulic connection is used. 1.2.3 Condenser The coils are seamless copper tubes, arranged in staggered rows, mechanically expanded into coated aluminium fins.

  • Page 11: Specifications

    2 Specifications 2.1 Water Flow Rate To ensure the normal operation of the unit, the water flow rate of the shell-and-tube heat exchanger must be within the rated flow 50% and 130%. If the water flow rate is too low, the internal copper tube for heat exchange of the shell-and-tube heat exchanger may crack and refrigerant may leak.

  • Page 12: Accessories

    3 Accessories 3.1 Standard Accessory Table No. Name Unit Accessory Qty Remarks Chiller Unit Certificate of Approval Copy Installation, operation and Copy maintenance manual Used on the general water 1 for a single unit Pipe Temperature Sensor outlet pipe when multiple 2 for dual units units are under joint control Used for communication of...

  • Page 13: Unit Installation

    4 Unit Installation ! WARNING The installation work must be completed by a qualified professional installation company. In consideration of factors such as the relative pressure inside the equipment, electrical components and the installation position, follow the safety instructions during operations, and carefully read the instructions and safety precautions on all labels beforehand.

  • Page 14: Equipment Entry Inspection

    4.1 Equipment Entry Inspection (1) Check the unit for any damage or missing parts. If you find damage or if any parts are missing, contact the freight company immediately. (2) Confirm that the received unit matches the order. Compare the nameplate data as required. (3) The unit must include the following information: ...
  • Page 15 The water inlet and outlet sealing covers of the shell-and-tube heat exchanger for the unit should be kept intact. Do not open the sealing Please contact the distributor. cover before the unit is connected to the water pipe. (2) Load/unload the unit with cautions without damaging any unit components. Use a crane to load/unload the unit.

  • Page 16: Installation Base Requirements And Unit Appearance

    4.3 Installation Base Requirements and Unit Appearance 4.3.1 Installation Base Requirements The unit is designed for outdoor installation and can be installed on a roof or floor or beside a building. The unit must be installed on a solid foundation. A whole concrete slab is recommended, and its bearing capacity must be sufficient to withstand the total weight of the unit and the maintenance personnel.
  • Page 17 4.3.2 Unit Appearance and Base Diagram 1. External dimensions The number of fans shown below is for reference only Φ Water Outlet Water Inlet 1 Power incoming line 4 Lifting Piont DN125-Victaulic Connection DN125-Victaulic Connection External unit dimensions (unit: mm) Model RHAG100HA 3530...
  • Page 18 The number of fans shown below is for reference only Φ 1 Power incoming line 2 Water Outlet DN125-Victaulic Connection 3 Water Inlet DN125-Victaulic Connection 4 Lifting Piont External unit dimensions (unit: mm) Model RHAG200HA 3530+3530 2300 2500 3530 3530 3530 1500 2030...

  • Page 19: Base Diagram

    2. Base diagram Installation Foundation Electric Control Box 4 - Φ14 Spring Isolator Mounting Hole Unit base dimensions (unit: mm) Model RHAG100HA 3530 2300 2220 2200 RCAG100HA Spring isolator model at each point Model RHAG100HA MHD-1050 MHD-1050 RCAG100HA Notes: 1. The spring isolator is optional. 2.
  • Page 20 Installation Foundation Electric Control Box 6 - Φ14 Spring Isolator Mounting Hole Unit base dimensions (unit: mm) Model RHAG130HA 4700 2300 2220 1412 1600 RCAG130HA Spring isolator model at each point Model RHAG130HA MHD-850 MHD-850 MHD-850 RCAG130HA Notes: 1. The spring isolator is optional. 2.
  • Page 21 Installation Foundation Main Electric Auxiliary Electric Control Box Control Box 8 - Φ14 Spring Isolator Mounting Hole Unit base dimensions (unit: mm) Model RHAG200HA 3530+3530 2300 2220 2200 1330 2200 3530 3530 RCAG200HA Spring isolator model at each point Model RHAG200HA MHD-1050 MHD-1050...
  • Page 22 Installation Foundation Main Electric Auxiliary Electric Control Box Control Box 10 - Φ14 Spring Isolator Mounting Hole Unit base dimensions (unit: mm) Model RHAG230HA 3530+4700 2300 2220 2200 1530 1412 1600 3530 4700 RCAG230HA Spring isolator model at each point Model RHAG230HA MHD-1050...
  • Page 23 Installation Foundation Main Electric Auxiliary Electric 12 - Φ14 Spring Isolator Control Box Control Box Mounting Hole Unit base dimensions (unit: mm) Model RHAG260HA 4700+4700 2300 2220 844 1412 1600 1688 1412 1600 4700 4700 RCAG260HA Spring isolator model at each point Model RHAG260HA MHD-850...

  • Page 24: Installation Space Requirements

    4.4 Installation Space Requirements The unit requires enough fresh air for heat exchange through the air side heat exchanger; therefore, be sure to reserve sufficient space around and between units. To enable maintenance and repairs, do not store materials around the unit. Note the following points when installing the unit in areas affected by snow.
  • Page 25 Incorrect installation In monsoon regions where the air heat exchanger faces the monsoon, air flow is like the broken line in the following figure because the air speed is higher than the air inlet speed of the fan. In this case, air that has undergone heat exchange will undergo it again in another heat exchanger, reducing cooling capacity and possibly causing a fault.
  • Page 26 If restricted by the installation site, multiple units can be installed in the following way and the space between units for overhaul must comply with the following figures: Series connection: Parallel connection:...

  • Page 27: Water System Installation And Recommended Water System Diagram

    4.5 Water System Installation and Recommended Water System Diagram 4.5.1 Installation Requirements of the Water System Installation of the water system must comply with conventional installation criteria to achieve the best operating efficiency. Ensure that no foreign material exists in the pipes. All cooling water pipes must comply with the local rules and regulations.
  • Page 28 JRA-GL-02.  The amount of water kept in the system should be within the operating range. Insufficient water will cause scale deposits, which may degrade performance or cause pitting corrosion and refrigerant gas leaks. Excessive water will lead to corrosion. ...

  • Page 29: Water Inlet

    c) All the chilled water pipelines must be rinsed thoroughly to remove foreign matter before being put into operation. Do not rinse any foreign matter into the evaporator. d) For convenient maintenance, install a thermometer and a pressure gauge respectively on the inlet and outlet water pipes.
  • Page 30 4.5.2 Relationship Between the Water Quality/Scale and Corrosion Water quality Scale Corrosion Remarks Easily accumulates Acidic water with PH ≤ 6 Hard High insoluble CaSO Soft liquid sediment Alkaline water with PH ≥ 8 Soft —— generated by iron or aluminum ions Water containing more Ca Hard...
  • Page 31 4.5.3 Diagram of the Recommended Water System...
  • Page 32 <1.0 Sulfide Not found Not found ion (S Reference items Ammonium mgNH <0.2 <1.0 Silicon dioxide mgSiO <30 <50 (SiO Midea is not responsible for the corrosion, flushing, or unit performance deterioration caused by untreated water or improper water treatment.

  • Page 33: Configuring The Electrics

    4) The power cable and grounding cable must be crimped firmly. Check them regularly for looseness. 5) Only electrical devices designated by Midea can be used. Users can apply for installation services or technical support from the manufacturer or authorized dealer. The controller may malfunction or cause electric shock if the unit is not wired according to electrical installation standards.
  • Page 34 Table of electrical properties: Unit data Fan data Compressor data Rated Power Voltage Model Start Max. Rated Start Max. operating current supply range (RHAG/R spee curre curren operatin curren current current CAG) g current cooling fans ±% 100HA 257.7 175.4 130HA 343.6 236.1...

  • Page 35: Power Specifications And Application

    core. The number of cables for the same layer bridge shall be calculated according to the sum of the three phases of cables listed in the table. 2. If the cable insulation material, laying method, the number of cables on the same layer bridge is inconsistent with the recommendation (such as multi-layer bridge, pipe threading, high temperature), or the line voltage drop is >...

  • Page 36: Wiring Requirements

    and even burning the motor. If the voltage imbalance is high, torque will be reduced and operating requirements will not be met. In this case, the rotating speed of the motor will not reach the required level. Keep the minimum start voltage of the unit to more than 90% of the rated value. 5.4 Wiring Requirements General power wiring diagram Specifications of the general power line: Refer to national standards.
  • Page 37 Configure a no-fuse air switch with sufficient capacity for each group of power input wires to the unit to avoid damaging the transformer, wiring, and other electrical appliances and allow manual control of start and shutdown for the compressor if a short circuit occurs in the line. Note: A no-fuse air switch is provided for each unit.

  • Page 38: Trial Operation

    6 Trial Operation 6.1 Check before Trial Operation 6.1.1 Water Part  Keep all the water system pipelines clean, and make sure that the waterway is connected properly and the water flow direction is correct.  Check whether the inlet and outlet pipes are well connected. ...

  • Page 39: Trial Operation Instructions

    (RHAG130HA/RCAG130HA, number of protection plates:4. RHAG100HA/RCAG100HA, number of protection plates: 2)  Check whether the unit valve is in the correct position and if the unit sends an alert for fluorine leakage.  Check whether the compressor coil winding is normal (including the phase resistance, inter-phase resistance and resistance relative to the ground).
  • Page 40 the suction/discharge pressure of the unit. Check the discharge temperature of the discharge pipe to ensure a good oil separation effect.  Observe the refrigerant flow through the sight glass on the liquid supply tube.  Observe the opening degree of the electronic expansion valve through the superheat degree of return air to see whether it is in a reasonable range.

  • Page 41: Start/Stop Process

    6.3 Start/stop process Power on Initialization complete Whether there is any system available Stop signal Choose running mode and send start signal Meet the min. running time Start water system Stop signal Detect cycle: temp. control cycle Compressor main Compressor main Water temp.

  • Page 42: Capacity Adjustment

    6.4 Capacity adjustment Each system of a unit is adjusted according to the outlet temperature of this unit. The control logic is as follows: （℃） （℃） Stop one Start one system system System System number number remains remains unchanged unchanged Start one Stop one system...

  • Page 43: Unit Use And Controller Operation Instructions

    7 Unit Use and Controller Operation Instructions Note: The unit is equipped with Remote Service Module, which could realize the information transmission and global positioning. The Remote Service Module would collect some information of the unit including temperature, pressure and running frequency, etc. while private information is not in the list. 7.1 Check before Use (1) Judge whether the compressor refrigerant oil has been heated for enough time.
  • Page 44 7.4.1 Welcome Interface Figure 1 shows the first welcome interface. Main control board and HMI program version number Figure 1 Welcome interface 7.4.2 Password interface Tap the "Enter" button to enter the password input page, as shown in the figure below: Figure 2 Password interface...

  • Page 45: Main Interface

    Figure 3 Password input interface Enter the password 40828, tap ENTER on the keyboard, and tap "Login" to enter the main interface. 7.4.3 Main interface Figure 4 Main interface When the unit is not online-controlled, "Stand-alone" is displayed, and the online mode is set by dial code S6-2 (do not set to online mode when there is only one unit).

  • Page 46: Power-On Operation

    Figure 5 Mode setting Set the control mode and operation mode on this page. The current system control mode and operation mode are displayed on the main interface. Notes: During operation, you can only switch the control mode and cannot select other modes. The control mode is used for selecting the on/off modes.

  • Page 47: Power-Off Operation

    7.4.3.3 Power-off operation , and a “Confirm Stop?” window pops up, as shown in Figure 7. Tap Yes, and the unit status displays "Shutdown". (Note: The interface still displays "Shutdown”, even if the shutdown conditions have not been met. After the shutdown conditions have been met, the unit will automatically shut down.) Figure 7 Power-on/off and status description: 1.
  • Page 48 Figure 8 Status information Notes: Startup must meet the following conditions: "Restart Delaying" must be "0". If it is not "0", the delay required for startup has not concluded. "Water Temp. Allow Compressor Start" must be "YES". If it is "NO", the current water temperature does not meet the compressor's startup conditions.

  • Page 49: Input Status Display

    Figure 9 Real-time data display 7.4.4.2 Input status display Figure 10 Input status "ON" indicates that the input point is connected to the power supply, and "OFF" indicates that the input point is disconnected from the power supply. Notes: “Remote Start/Stop” is valid in the “REMOTE” mode. The remote switch hardware need to select hold type.

  • Page 50: Parameter Settings

    Figure 11 Output status "ON" indicates that the output point is closed, and "OFF" indicates that the output point is disconnected. 7.4.5 Parameter Settings On the main interface, tap to access the User parameters setting interface. The User parameters setting interface is as follows: Figure 12 User parameters setting interface On the interface, tap to access the User parameters setting interface, as shown in Figure 13.
  • Page 51 Figure 13. User parameters setting Notes: Set the MAX of the input window to the upper limit of set parameter and MIN to the lower limit of the set parameter. Press "Enter" to confirm the input. Press "Esc" to cancel the input. The interface display relevant cooling parameters setting in the Cooling mode and relevant heating parameters setting in the Heating mode.
  • Page 52 temperature); in Heating mode, the unit starts only when the (outlet) temperature is lower than (control target temperature-restart difference temperature). Anti-snow enable: represents the switch of anti-snow enable in winter. When enabling, the fans will intermittently open and close according to the ambient temperature to prevent of snow under standby condition.
  • Page 53 Note: The date and time must be set in a reasonable manner. For any consequences resulting from an unreasonable date/time setting, Midea does not shoulder any liability. 7.4.7 Serial Port Setting Interface On the interface shown in Figure 12, tap to enter the interface as shown in Figure 16.
  • Page 54 Figure 17 Multi-connection setting The Multi-Control Selection is displayed as "Stand-alone" or "Online" (set via dial code S6-2; when S6-2 is ON, it indicates online mode; when S6-2 is OFF, it indicates stand-alone mode), the Address is displayed as 0-15 (set via dial code S5), where 0# is the only multi-connection master unit. Tap “Multi-Control Status”...

  • Page 55: Timer Set

    Figure 19 Multi-connection serial system display The 8-15# units correspond to the 0-7# unit serial system, which needs to be set according to the actual situation. By querying the n# unit, tap "Enter" to query the multi-connection unit information, as shown in Figure 20. Figure 20 Multi-Connection unit information 7.4.9 Timer Set On the interface shown in Figure 12, tap...
  • Page 56 Figure 21 Timer Set Figure 22 Timer Set You can set eight timed periods, each of which is to be enabled with the "enable" buttons. indicates that timing is disabled, while indicates that it is enabled. indicates the timing is applicable to Monday (in blue), rather than Tuesday.

  • Page 57: Alarm Information

    Time" of the other segments of the current day, when the set start/stop time comes, the unit will be stopped normally and will not be started again during this period of time. ③ It is advised to set a difference of over 15 minutes between the "Start Time" of other segments of the current day and the "Stop Time"...
  • Page 58 Figure 24 Detailed Alarm information interface 7.4.11 Quick Start and Start-up after Restoration of Power This function needs to be customized. On [Main interface]-[Parameter settings]-[User Para.], click Quick Start and then set the time. If the power-off time is less than the set time, perform Quick Start; otherwise, do not perform Quick Start.

  • Page 59: Unit Operation Flowchart

    7.5 Unit Operation Flowchart Welcome interface Password input Note: The user password (58806) can be used to access the white window. The user management password (40828) can be used to access the light purple window. Home interface Status Parameter settings Alarm information Mode selection information...

  • Page 60: Unit Operation Precautions

    (4) The electronic expansion valve controller parameters cannot be adjusted without the authorization of Midea after-sales personnel; otherwise, the unit cannot operate normally. (5) If the safety valve on the liquid reservoir is opened, ensure good ventilation in the environment around the unit.

  • Page 61: Troubleshooting

    8 Troubleshooting Faults Causes and Troubleshooting Methods Confirm whether the system pump is operating and whether the water flow rate meets system requirements. Check whether the flow switch is properly installed and whether the set value of the water switch is correct. Main circuit cut-off prot.
  • Page 62 Check that the value set for compressor overload protection is consistent with the factory parameters. Once startup conditions are satisfied, power on the unit again, and then Comp. Overload Prot. check whether the compressor current exceeds the maximum allowable operating current of the compressor. Check whether the current operating condition of the unit exceeds the allowable limit range.
  • Page 63 Please check whether the EXV is stuck at a large opening. Check whether the ambient temperature is too high. Check whether the fan turns in reverse or stops. Check whether the fin heat exchanger is blocked by dirt and whether High Discharge Press.

  • Page 64: Standard Maintenance

    9 Maintenance Standard maintenance The air conditioning equipment must be installed by professional technician. Routine sampling should be conducted by local professionals. Simple preventive maintenance is conductive to the optimal operation of equipment: Improving the cooling performance   Reducing power consumption Preventing unexpected events ...

  • Page 65: Maintenance Items

    Move or disassemble the unit.  Handle operation interruption due to improper maintenance.  Handle other faults specified in the policy. Note: Midea is not liable for faults due to negligence during use. Maintenance Items Maintenance Qualification Benchmark Maintenance Item...
  • Page 66 Maintenance Qualification Benchmark Maintenance Item Remarks Frequency (Handling Method) during operation Use a DV500V high resistance Insulation Once/year meter to test it (must be above resistance 5MΩ). Aging of Qualified if found to be elastic when shockproof Once/year pressed with a hand rubber Interim Once/...
  • Page 67 Maintenance Qualification Benchmark Maintenance Item Remarks Frequency (Handling Method) Use a 500 VDC high-resistance Insulation Once/month meter to test it, which must be resistance above 1MΩ Contact The wire insulation layer cannot be X. Electrical property of Once/month broken, contact is good, and the control wire bolt is fastened...

  • Page 68: Field Acceptance List And Trial Operation Parameter List

    Date, Year Fill in the following items and fax the table to Midea's after-sales service department for confirmation and to arrange commissioning by engineers and their schedule. If conditions do not comply with the following table, the customer will bear the related labor and traveling expenses on commissioning.
  • Page 69 tightened. Yes ( ) No ( )  The unit is grounded.  Yes ( ) No ( ) Wiring of weak-current part and power cable distribution meet the anti-interference specification. 5. Confirmation of the chilled water system of the unit ...
  • Page 70 Customer's signature: Midea's signature: Company: Company: Date: Date:...

  • Page 71: Unit Commissioning Record Table

    10.2 Unit Commissioning Record Table Unit Model: Compressor model: Product code: The user's power supply system: V--3Ph-- Location: Country Province City Owner name: Contact/Tel: Installation company: Contact/Tel: Distributor: Contact/Tel: Commissioning date: Month/Date/Year The parameters of the following items are the basis for confirming that the unit has passed the acceptance check.
  • Page 72 L3 phase current/A Discharge temperature/°C Discharge pressure/MPa Suction temperature/°C Suction pressure/MPa Evaporator Inlet water temperature/°C Inlet water pressure//MPa Outlet water temperature/°C Outlet water pressure//MPa Time of recording Maintenance performed or not: Notes: Signature of the Signature of the Signature of the Customer Signature: supervisor/consultant: distributor:...

  • Page 73: Precautions For Prolonged Stop Period

    11 Precautions for Prolonged Stop Period ! WARNING Do not allow water to remain in the water piping during prolonged stop periods. For prolonged idle periods you should fill the water pipes with antifreeze or drain all the water from the pipes.

  • Page 74: Appendix

    Appendix Wiring diagram of RHAG100HA/RCAG100HA /4.B8 /4.B8...
  • Page 75 A1.CN4.DI16 A1.CN1.DI15 A1.CN1.DI14 A1.CN1.DI14 A1.CN1.DI13 A1.CN1.DI13...
  • Page 76 /4.B7 /4.B7...
  • Page 77 AIP-1 AIP-2 AIP-3 AIP-4 AIP-5 AIP-6 485-5 CN17 CN24 CN10 CN11 CN11 CN14 COM4 /3.E9 /3.E9 CN29 CN30 CN28 CN27 DI2 DI1 EEV4 EEV3 EEV2 EEV1...
  • Page 78 Wiring diagram of RHAG130HA/RCAG130HA /4.B8 /4.B8...
  • Page 79 A1.CN4.DI16 A1.CN4.DI16 A1.CN1.DI15 A1.CN1.DI15 A1.CN1.DI14 A1.CN1.DI14 A1.CN1.DI13 A1.CN1.DI13...
  • Page 80 /4.B7 /4.B7...
  • Page 81 AIP-1 AIP-2 AIP-3 AIP-4 AIP-5 AIP-6 485-5 CN17 CN24 CN10 CN11 CN11 CN14 COM4 /3.E9 /3.E9 CN29 CN30 CN28 CN27 DI2 DI1 EEV4 EEV3 EEV2 EEV1...
  • Page 82 Note: For RHAG200HA/RCAG200HA wiring diagram, see the wiring drawing of RHAG100HA/RCAG100HA. For RHAG230HA/RCAG230HA wiring diagram, see the wiring drawings of RHAG100HA/RCAG100HA and RHAG130HA/RCAG130HA. For RHAG260HA/RCAG260HA wiring diagram, see the wiring schematic for RHAG130HA/RCAG130HA. All RHAG200~260HA/RCAG200~260HA units are equipped with one communication cable for connecting two units.
  • Page 83 Table 1 Daily Inspection Record Table Ambient Inlet water Outlet water Discharge pressure Suction pressure Discharge Suction Date Time temperature (°C) temperature (°C) temperature (°C) (bar) (bar) temperature (°C) temperature (°C) Note: The customer needs to fill in and keep this form properly. It can be copied for use.
  • Page 84 Table 2 Inspection Record Table of Key Parts Item Compressor Water side heat exchanger Air side heat exchanger Valves Electric control box Others Frequency Date Inspector Content Date Inspector Content Date Inspector Content Date Inspector Content Date Inspector Content Date Inspector Content Date Inspector Content...

  • Page 85: Attached Table

    Attached Table 3 Maintenance Record Fault Description Handling Measures Handling Results Recorded by Note: Fill in this form carefully and store it properly.
  • Page 86 Table 4 Air Cooled Scroll Chiller Harmful substances Hexavalen Polybrominate Polybrominate Part name Plumbum Hydrargyru Cadmium t chromium d biphenyls d diphenyl (Pb) m (Hg) (Cd) (PBB) ethers (PBDE) (Cr(VI)) Compressor and × × × × × × accessories Ο Ο...
  • Page 88 MCSM22-C-03A 16100101007624 Chongqing Midea-General Refrigeration Equipment Co., Ltd. Add.: No.15, Qiangwei Road, Nan'an District, Chongqing, China Tel: +86-757-26338266 mbt.midea.com www.midea-group.com Email: service@midea.com...
