HOTO QWXCJ003 Instruction Manual

Electric power washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HOTO
ELECTRIC POWER WASHER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QWXCJ003 and is the answer not in the manual?

Questions and answers

Related Manuals for HOTO QWXCJ003

Summary of Contents for HOTO QWXCJ003

  • Page 1 HOTO ELECTRIC POWER WASHER...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use or subsequent owners. Apart from the notes contained herein the general safety provisions and rules for the prevention of accidents of the legislator must be observed.

  • Page 4: Electric Components

    Electric components DANGER Risk of electric shock. Never touch the mains plug and the socket with wet hands. Check the power cord with mains Plug for damage prior to every use. Do not use the machine if a supply cord or important parts of the machine are damaged, e.g.

  • Page 5: Safe Handling

    WARNING ‒ Risk of Injection or Injury‒ Do Not Direct Discharge Stream At Persons. This Product Is Provided With A Ground Fault Circuit Interrupter Built Into The Power Cord Plug. If Replacement Of The Plug Or Cord Is Needed, Use Only Identical Replacement Parts.
  • Page 6 and safety installations, for damage prior to every operation. Immediately replace damaged components. Do not operate appliance with damaged components. The appliance has been designed for use with the cleaning agent supplied or recommended by the manufacturer. The use of the other cleaning agents or chemicals may adversely affect the safety of the appliance.

  • Page 7: Other Risks

    reduced physical, sensory or mental capacities, or lacking experience and knowledge. Children must not play with this appliance. Supervise children to prevent them from playing with the appliance. Create stability for the appliance prior to any work on or with the appliance to prevent accidents damage.
  • Page 8 WARNING According to applicable regulations, the appliance must never be used on the drinking water net without a system separator. Ensure that the connection of your building water installation on which the high pressure cleaner is operated is equipped with a system separator pursuant. Water that has flown through backflow preventers is considered to be non-potable.

  • Page 9: Residual Risks

    WARNING The improper use of detergents can cause severe injuries or oxidation. Store cleaning agent away from the reach of children. Discharge residual pressure before disconnecting the hose from the product. Check before each use , and at regular intervals, that all metal fasteners are tight and the product’...

  • Page 10: Personal Protective Equipment

    CAUTION Safety installations serve the protection of the user and may not be modified. GROUND FAULT CIRCUIT INTERRUPTER The appliance is provided with a ground-fault circuit-interrupter (GFCI) built into the plug of the power-supply cord. This device provides additional protection from the risk of electric shock. Should replacement of the plug or cord become necessary, use only identical replacement parts that include GFCI protection.

  • Page 11: Proper Use

    CAUTION Wear protective clothing and safety goggles to protect against splash back containing water or dirt. During the use of high-pressure cleaners aerosols can develop. Inhaling aerosols can cause health damage. —Depending on the application, completely shielded nozzles(e.g. surface cleaner)that significantly reduce the emission of aqueous aerosols can be used for high-pressure cleaning.

  • Page 12: Description Of The Appliance

    terraces, facades and garden equipment using clean water and biodegradable chemical detergents. Likewise the product can be used to clean paving slabs or rain gutters. This product may not be used to clean clothing, shoes and other textiles. The water jet should not be directed against persons. Animals, any electrical equipment or on the product itself.

  • Page 13: Technical Specifications

    Technical specifications Voltage: 120V~ Allowable pressure: 2300PSI Frequency: 60Hz Rated flow: 1.1GPM Protection Class: II Max. flow: 1.6GPM Degree of protection: IPX5 Max. inlet pressure: 0.7MPa Rated pressure: 1800PSI Net Weight: Approx. 10.54kg Assembly Mount loose parts delivered with appliance prior to start-up 1.
  • Page 14 2. Installing the high-pressure hose hook with four screws, as below. 3. Slide the trigger gun holder into position as shown. 4. Slide the spray wand holder into position as shown.
  • Page 15 5. Installing the spray wand and nozzle. To fit the spray wand into the trigger gun, insert the locking lugs on the spray wand into the end of the trigger gun. Rotate them counter-clockwise until the two parts are completely locked. Snap the desired nozzle onto the Quick-Connect collar until it clicks into place.
  • Page 16 6.Connect the high pressure hose to the trigger gun Connect the sliver end of the high-pressure hose to the trigger gun and secure the connection. 7. Connect the garden hose adaptor to the water inlet. Connect the garden hose adaptor (female coupler) to the water inlet of the pressure washer, then thread your garden hose(male...
  • Page 17 8. Connect the high-pressure hose to the water outlet Connect the other end of the high-pressure hose to the water outlet on the washer and twist the black rotatable end-piece as indicated to secure the connection. Start up Park the appliance on an even surface. Impurities in the water can damage the high-pressure pump and the accessories.
  • Page 18 Check that the power supply voltage and frequency (Volt/Hz) correspond to those specified rating plate on the pressure washer. Plug the GFCI into the power outlet. Water supply from mains. Drawing in water from the open reservoirs. This high-pressure cleaner is suited to work with the YILI suction hose 2m with backflow vale to draw in surface water, e.g.

  • Page 19: High Pressure Operation

    Operation ATTENTION Dry running of more than 2 minutes leads to damage of the high-pressure pump. If the appliance does not build up pressure within 2 minutes, switch the appliance off and proceed in accordance with the instructions in Chapter “Troubleshooting”...

  • Page 20: Operation With Detergent

    Connect the product to power and water supply as described. Open the water supply Hold the spray gun with both hands. Direct the nozzle of the chosen accessory away from you towards the surface to be cleaned. Unlock the trigger and press it until a constant amount of water flows through the nozzle, to allow air trapped in the hose to escape.

  • Page 21: Recommended Cleaning Method

    the foam cannon will click into place. Turn the foam-volume knob on the foam cannon to vary the amount of foam. Turn on the pressure washer. Pull the trigger to operate the unit. The liquid detergent will automatically mix with water and be discharged through the nozzle.

  • Page 22: Interrupting Operation

    Interrupting operation Release the lever of the trigger gun. Lock the lever of the trigger gun. Put the trigger gun with the spray lance into the parking position. During longer breaks(more than 5 minutes), also turn the appliance off using the “OFF/ON”...

  • Page 23: When Transporting In Vehicles

    Transportation CAUTION Risk of personal injury or damage! Mind the weight of the appliance during transport. When transporting by hand Switch the product off and disconnect it from the water and power supply. Pull out the transport handle until it audibly snaps into place. Attach transportation guards, if applicable.

  • Page 24: Storing The Appliance

    Storage CAUTION Risk of personal injury or damage! Consider the weight of the appliance when storing it. Storing the appliance Park the machine on an even surface. Detach spray lance from the trigger gun. Push the disconnect button on the trigger gun and pull the high-pressure hose out of the trigger gun.

  • Page 25: Frost Protection

    Frost protection ATTENTION Appliance and accessories that are not completely drained can be destroyed by frost. Completely drain appliance and accessories and protect them against frost. To avoid damage: Detach the appliance from the water supply. Detach spray lance from the trigger gun. Turn on the appliance “ON/OFF”...
  • Page 26 High pressure hose The high pressure hose is specially constructed with reinforced walls it can be easily damaged and should be stored carefully. Do not kink. Do not drive vehicles over the hose. Do not expose the hose to sharp edges or corners. Misuse will lead to ballooning or premature failure and will invalidate warranty.
  • Page 27 Clean the nozzle with the needle clean-out tool provided . Remove the spray wand from the gun. Remove any dirt from the nozzle hole and rinse. ATTENTION The sieve must not be damaged. Pull the sieve out using flat pliers. Clean the sieve under running water.
  • Page 28 Know how to stop the product and bleed pressures quickly. Be thoroughly familiar with the controls. Stay alert ‒ watch what you are doing. Do not operate the product when fatigued or under the influence of alcohol or drugs. Keep operating area clear of all persons. Do not overreach or stand on unstable support.
  • Page 29 In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated product, nor should a means for grounding be added to the product. Servicing a double-insulated product requires extreme care and knowledge of the system, and should be done only by qualified service personnel.
  • Page 30 Symptom Cause Recommended action Machine Machine not plugged in. Plug in machine. refuses to Defective socket. Try another socket. start Fuse has blown. Replace fuse. Switch off other machines. Defective extension cord. Try without the extension cord. Fluctuating Pump sucking air. Check that hoses and connections are pressure Valves dirty, worn out or...

  • Page 31: Warranty

    Accessories A choice of accessories is supplied in the scope of the delivery of this product. Please check the technical specification of any accessories that you purchase to ensure they are compatible with this product. Warranty This product has been manufactured to a high quality standard. The warranty period is 3 months from date of purchasing.
  • Page 32 Federal Communications Commission Supplier’ s Declaration of Conformity This supplier’ s declaration of conformity is hereby for Product: HOTO ELECTRIC POWER WASHER Model Number(s): QWXCJ003 Brand/Trade: HOTO We declare that the above mentioned device has been tested and found in compliance with CFR 47 Part 15 Regulation.
  • Page 33 Consult the dealer or an experienced radio/TV technician for help. Representative of Responsible Party for SDoC Company: HOTO (US) TECHNOLOGY CO LTD Address: 919 North Market Street, Suite 950, Wilmington DE 19801 Country: U.S.A. Customer Service(US): +1 855-577-2659 Mon-Fri 9:00am-5:00pm(CST) Manufacturer: Shanghai HOTO Technology Co., Ltd.
