Page 5: General Safety Information
SAFETY GENERAL SAFETY INFORMATION CAUTION- Indicates a potentially hazardous WARNING situation which, if not avoided, may result in minor or moderate injury. It may also be used to Do not operate or perform any maintenance on this alert against possible damage to the machine machine until instructions... -
Page 6: Safety Precautions
SAFETY PRECAUTIONS WARNING WARNING Do not operate this machine unless you have read and understand the instructions in the OPERATOR’S The proper and safe lubrication and maintenance for MANUAL. Improper machine operation is dangerous this machine, recommended by Manufacturer, are and could result in injury or death. - Page 7 SAFETY 13. Always use the proper tools that are in good 21. Do not operate a machine if any rotating part is condition and that are suited for the job at hand. damaged or contacts any other par t during Be sure you understand how to use them before operation.
- Page 8 NOTE: This Manual may be properly revised due to the i m p r o v e m e n t o f p r o d u c t s , m o d i f i c a t i o n o f This Manual is prepared as a technical material in specifications, etc.
-
Page 9: Safety And General Information
SERVICE MANUAL - SECTION 1 ED150 BLADE RUNNER ACERA SR EXCAVATOR DOZER TIER 3 SAFETY AND GENERAL INFORMATION Issued 06-2008 Book/Form Number 5-15210 NA Copyright © 2008. CNH America LLC. All Rights Reserved. Printed in U.S.A. • Bur Source Code No. 87480999... -
Page 10: Section Table Of Contents
SECTION 1 - SAFETY AND GENERAL INFORMATION SECTION 1 SAFETY AND GENERAL INFORMATION SECTION TABLE OF CONTENTS CHAPTER 1 GENERAL PRECAUTIONS FOR MAKING REPAIRS TABLE OF CONTENTS ..............1-1 GENERAL PRECAUTIONS FOR MAKING REPAIRS . - Page 11 SECTION 1 - SAFETY AND GENERAL INFORMATION NOTES Issued 06-2008 Bur 5-15210 NA...
- Page 12 SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 ED150 BLADE RUNNER ACERA SR EXCAVATOR DOZER TIER 3 GENERAL PRECAUTIONS FOR MAKING REPAIRS Issued 06-2008 Book/Form Number 5-15220 NA Copyright © 2008. CNH America LLC. All Rights Reserved. Printed in U.S.A. • Bur...
- Page 13 For exact information about any particular product, please consult your Dealer Revision History Issue Issue Date Applicable Machines Form Number Remarks First Edition 06-2008 ED150 BLADE RUNNER ACERA SR 5-15220 1-II Issued 06-2008 Bur 5-15220 NA...
-
Page 14: Table Of Contents
SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 GENERAL PRECAUTIONS FOR MAKING REPAIRS TABLE OF CONTENTS GENERAL PRECAUTIONS FOR MAKING REPAIRS ..........1-3 Preparation Before Disassembling . - Page 15 SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 - GENERAL PRECAUTIONS FOR MAKING REPAIRS NOTES Issued 06-2008 Bur 5-15220 NA...
-
Page 16: General Precautions For Making Repairs
SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 - GENERAL PRECAUTIONS FOR MAKING REPAIRS GENERAL PRECAUTIONS FOR MAKING REPAIRS PREPARATION BEFORE DISASSEMBLING 5. Choose a hard, lever and safe place, and put attachment on the ground without fail. 1. Knowledge of operating procedure Read Operator’s Manual carefully to understand 6. -
Page 17: Inspecting Parts
SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 - GENERAL PRECAUTIONS FOR MAKING REPAIRS Inspecting Parts 4. For air bleed of travel motor and hydraulic cylinder, starts engine and operate it for 10 1. Check that the disassembled parts are free from minutes or more at no-load and low speed. -
Page 18: Hydraulic Parts
HYDRAULIC PARTS Wash with soap and water. O-ring 4. Others For spare parts, grease and oil, use KOBELCO Check that O-ring is free from flaw and has genuine ones. elasticity before fitting. Even if the size of O-ring is equal, the usage... -
Page 19: International Unit System
SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 - GENERAL PRECAUTIONS FOR MAKING REPAIRS INTERNATIONAL UNIT SYSTEM INTRODUCTION Although this manual uses the SI units system. 4. Derived Units bearing Peculiar Designations Outline of SI units system is described here. Table 4 Given below are an excerpt of the units that are related to this manual :... - Page 20 SECTION 1 - SAFETY AND GENERAL INFORMATION CHAPTER 1 - GENERAL PRECAUTIONS FOR MAKING REPAIRS 6. Unit Conversion Table QUANTITIES REMARKS Mass Force 1kgf=9.807N Torque kgf/m 1kgf/m=9.807Nm 1kgf/ Pressure kgf/cm =0.098MPa Motive power 1PS=0.7355kW –1 –1 Revolution r.p.m 1r.p.m=1min 5-15220 NA Issued 06-2008 Bur...
