HUBER+SUHNER Optibox 6 Installation Manual

INSTALLATION
MANUAL
Optibox 6
Table of contents
• ASSEMBLY INSTRUCTION ............................................................... 1
ASSEMBLY INSTRUCTION
Scope of delivery:
- OTB6 cover
- OTB6 base with snapped-in inlay
- 3 x U-Shape grommets for cable diameter 3-5mm
- 3 x U-Shape grommets for cable diameter 6-8mm
- 3 x U-Shape grommets or cable diameter 9-12mm
- 3 x U-Shape grommets closed
- 4 x cable tie large 3.5 x 100mm
- 6 x cable tie small 2.5 x 87mm
- 4 x PT screw KA 40 x 16mm raised head
- 1 x PT screw KA 40 x 12mm flat head
Required tools:
-
-
-
-
-
-
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
general handling of these products please contact HUBER+SUHNER.
Screw driver cross recess
Drill
Knife
Wire cutting pliers
Cable stripper
Screws and anchor bolt for wall mounting
HUBER+SUHNER AG
Fiber Optics
Fiber Management Systems
DOC-0000424718 Rev C
Date: 19/08/2016
Page 1 of 6
