- Page 1 MULTI MOUNT INSERT Multi Mount Insert or Standalone Mount for Intercom & Radio Setup I NSTALL ATIO N I NSTR UCTIO N S MT-DMU-RUGGED MT-DMU-RDM MT-DMU-25WP MT-DMU-ICOM MT-DMU-KEN MT-DMU-MOTO v1.0 - 07/2024...
-
Page 2: Equipment Used
Motorola CM300D & Motorola Vertex VX2200 MT-DMU-MOTO NOTE: Instructions may vary slightly between mount part numbers. The mount shown in the instructions is the MT-DMU-RUGGED. NOTE: The only Intercoms that are compatible with these part numbers are the Rugged 696 & 696+ Intercoms. Equipment Used Parts List •... - Page 3 Installing the Intercom Step 1 First, insert the supplied hex bolt facing inward into the holes of the mount then insert the supplied lock washer and nut on either side. Step 2 Feed the intercom through the face of the mount, aligning the hex bolt heads with the channel on either side of the intercom.
-
Page 4: Installing The Radio
Installing the Radio Step 4 On your radio, remove the Phillips Hex screws from either side using the 7mm Socket or Open-End Wrench. Step 5 Position and Insert the radio face thru the back toward the front of the mount. Step 6 Align the holes on the mount with the holes on the radio then reinstall the Phillips Hex screws into either side. - Page 5 Step 7 Tighten the Phillips Hex Screws with the use of 7mm Open-End Wrench or Power Phillips Screwdriver to secure it in place. Radio & Intercom Mounting Complete Now that the Radio and Intercom are mounted, the unit can now be installed to your vehicle.
