Installing Memory Riser Boards

NOTICE: System board memory sockets 3 and 4 can either be empty or
contain CRIMMs. Sockets 3 and 4 cannot contain RIMMs with memory riser
boards installed in sockets 1 and 2.
If any RIMMs occupy memory sockets on the system board, remove
1
those modules.
NOTE: See "Removing a Memory Module."
To locate the memory sockets on the system board, see "System Board
Memory Components."
NOTICE: To avoid damage to the memory riser board, press the riser board
straight down into the socket with equal force applied at each end of the riser
board.
Install memory riser board B (see the following figure):
2
Align the slots on the bottom of riser board B with the ridges
a
inside memory socket 2 on the system board.
The memory sockets on the riser board will face away from the
microprocessor(s).
Press riser board B straight down into socket 2 until the securing
b
clips snap into place at the ends of the riser board.
Install memory riser board A:
3
Align the edges of riser board A with the retention brackets on riser
a
board B.
Align the slots on the bottom of riser board A with the ridges
b
inside memory socket 1 on the system board.
The memory sockets on the riser board will face away from the
microprocessor(s).
Press riser board A straight down into socket 1 until the securing
c
clips snap into place at the ends of the riser board.
Install the memory riser board retention bracket:
4
Lower the bracket to the chassis so that the two bracket tabs insert
a
into the chassis slots.
Press the bracket straight down until it is secured in the chassis.
b
M e mo r y R i s er B o a rd Re p la c e m en t
19
