- Page 1 User Manual for Wireless 3-channel 0-10-Volt DC Node Model FAV0010-12 Description – Initialization – Technical Information...
- Page 2 Node Technical Information General Model FAV0010-12 Dimension Length × Height × Depth 10.4 cm × 2.4 cm × 9.4 cm Weight 300 g Working Temperature -10 to 45 °C Storage Temperature -20 to 60 °C Working Humidity 0 – 60%...
-
Page 3: Security Considerations
Security Considerations Before using this product, please read the precautions Please carefully read this manual before using the product and pay full attention to the mentioned points to use the product correctly. In this manual, safety measures are classified into two levels: “Warning ”... - Page 4 • Do not disconnect and reconnect the Node while the FIDAQUIRE data logger is on. Doing so will damage the Node and the FIDAQUIRE data logger. Setup and maintenance precautions Warning • Do not touch the conductive or electronic parts of the Node during activation. Doing so may result in electric shock or damage to the Node.
- Page 5 Waste disposal precautions Caution • Dispose the node as an industrial waste. • Ensure Nodes are segregated from other waste in accordance with local regulations. Dispose of Nodes correctly at your local waste collection/recycling facility.
-
Page 6: Contents Of The Box
Contents of the box Please verify that the box contents match the packing list. The following items should be included: • A wireless 3-channel 0-10-volt DC Node, model FAV0010-12 • An input socket • 12-volt adaptor • A user manual. -
Page 7: Table Of Contents
Table of Contents 1. Initialization of the Node ................... 8 2. Connecting Node to LoRa Card ..............10 3. Calibration ......................11 4. Settings related to Node Software ..............11 5. Node Dimension ....................17 Contact us .......................18... -
Page 8: Initialization Of The Node
1. Initialization of the Node Figure 2: Side view of a Wireless 3-channel 0-10-volt DC node Figure 3: Front view of a Wireless 3-channel 0-10-volt DC node... - Page 9 Node Negative Input _____ 8, 10, 12 (Ground) If the Node's power is connected (on the Node Power Connection LoRa bus), the ELFI symbol will be Display displayed in green. _____ Wall Mounting Location 1. Factory reset 2. Please refer to Section 3 for calibration settings.
-
Page 10: Connecting Node To Lora Card
2. Connecting Node to LoRa Card To pair the Node with the LoRa card, follow these steps: 1) Initially, press and hold the FUNC button on the LoRa card for three seconds. The LEDs on the top and bottom rows of the card will start to light up. This indicates that the card has entered pairing mode, and the LED corresponding to the first channel will turn on. -
Page 11: Calibration
3. Calibration To calibrate a Node or set its minimum and maximum values, follow these steps: Step 1: Press and hold the F key for 4 seconds. The node will enter calibration mode and the MCU LED will blink once per second. At this point, you can perform zero- point calibration (enter the Low range value). -
Page 12: Settings Related To Node Software
4. Settings related to Node Software To identify and initially activate the Node, after connecting the Node to the FIDAQUIRE LoRa card datalogger, first enable the Active mode in the Node settings menu and then select the Initialize option (Figure 4). Figure 4: How to Initially Activate a Node To apply the settings to the Node, click on it to display the Node settings page (Nodes Config) (Figure 5). - Page 13 Note: Table 2 shows all possible Node status states Figure 2: All Possible Node Status States Status Description Offline Power disconnected Operational Node is sending data To remove a Node from the LoRa card, first unplug the network cable from the Node to make it Offline.
- Page 14 ■ The SDO menu is used to change the parameters of Interval , Spread Factor, and Channel (Figure 7). Figure 7: SDO Menu from Nodes Setting page To read any of the Interval, Spread Factor, or Channel parameters: ● (1) Click on the "Read" option. (2) Select the desired parameter.
- Page 15 Note: If the Node is offline, first test the power connection, and if the connection is correct, reset the Node. To do this, unplug the power from the Node. Press and hold the F key, then connect the power and hold the F key until the ELFI light turns off, then release it.
- Page 16 Table 3: Guide for selecting the Interval value based on the number of Nodes and Spread Factor. Number of Nodes (Sensors) 9-12 13-16 > 0.5s > 1s > 1.5s > 2s > 1s > 2s > 3s > 4s > 2s >...
-
Page 17: Node Dimension
5. Node Dimension... -
Page 18: Contact Us
Contact us Behineh Farayand Electronic Fidar Company Telephone: +9802191308515 Address: West Azerbaijan Province, Urmia, 10 KM Sero Road, Science and Technology Park Email: info@fidarelectronics.com Website: www.fidarelectronics.com...
