- Page 1 CANopen Card Model FBC0232-01 User's Manual Description – Installation – Technical Data Hardware Revision: 1.0.0 Software Revision: 2.0.0 Manual Revision: 1.0.0...
- Page 2 Technical specifications of the CANOpen card General Model FBC0232-01 Dimensions 10 cm (length) × 5.6 cm (height) × 18.5 cm (depth) Weight 0.2 Kg Operating Temperature -10°C to 45°C Storage Temperature -20°C to 60°C Operating Humidity 0% to 60% Warranty...
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS (Before using this product, read the precautions) Please carefully read this manual before using the product and pay full attention to the mentioned points to use the product correctly. In this guide, safety measures are classified into two levels: " Warning"... - Page 4 ● Use the CANOpen card in an environment that complies with the general specifications provided in this manual. Using the CANOpen card in any other operating environment may result in electric shock, fire, malfunction, or damage, and degrade the quality of the module. ●...
- Page 5 Disposal precautions Caution ● Dispose of the CANOpen card as industrial waste. ● When discarding the card, separate it from other waste in accordance with local regulations and and properly dispose of it at the local waste collection/recycling center.
- Page 6 1. Introduction CANopen data card model FBC0232-01 is one of the cards to receive data from CANopen sensors. Data received from sensors can be analog or digital. The CANopen card has the ability to simultaneously receive data from all the sensors connected to it.
- Page 7 2. Indicators on the card Figure 2 : Image related to the card surface Item color Description It shows receiving data from nodes. Since many sensors are sending data simultaneously, this light is always on and LED1 Blinking orange constantly blinking. It shows the health status of the sensors.
- Page 8 3- Installing the CANOpen card on the FIDAQUIRE data logger The process of identifying and initializing the CANOpen card is fully automated, and after installing and starting up the data logger, the card will appear on the "Cards list" page. For initial setup, refer to the FCD6455-01 product manual. After initializing the card, the input channel information (input sensors) will also be displayed on the same page (Figure 3).
- Page 9 4- Card and Nodes settings ● To configure the CANOpen card, follow the steps below: (1) Select the "Config" menu and enter the settings page (Figure 5). (2) Fill in the fields "Card Name" and "Card Description ," then select the "Baud Rate "...
- Page 10 ● The "Alarms" menu displays the list of alarms defined for each channel or subchannel. It allows for editing alarms, enabling or disabling them, and deleting alarm alerts. Additionally, the "Logs" menu provides a detailed list of alarm information and the time of occurrence (Figure 6). Figure 6: View page of alarms defined for the card ●...
- Page 11 Figure 8: General Menu of the Node Settings Page The "Config" menu varies in number depending on whether the Node is single- channel or multi-channel, and you can add additional configuration settings for the Node on the "Config" page (Figure 9). Figure 9: Config Menu of the Node Settings Page For instructions on configuring each Node, refer to its specific manual .
- Page 12 ● The "SDO" menu is used to modify the parameters of Interval , Baud Rate , and (Figure 10). Heart Beat The "Write" sub-menu is used for changing settings, and the "Read" sub-menu is used for reading settings. Note: The Baud Rate of the card and the Node must be the same. For precise values, refer to Table 1.
- Page 13 ● To change each of the parameters: Interval, Baud Rate, and Heart Beat: (1) Click on "Write". (2) Select the desired parameter. (3) Enter the desired value in the "Data" field. (4) By selecting "Send Command", the information related to that parameter will be saved.
- Page 14 5. The relationship between the number of sensors, wire length and data baud rate from each sensor Table 1: Baud Rate selection guide Cable length 20 m 40 m 100 m 250 m 500 m 20 kbps 20 kbps 50 kbps 20 kbps 50 kbps 125 kbps...
-
Page 15: Contact Information
Contact information Fidar Electronics co. Add: West Azarbaijan, Urmia, Iran Tel: 021- 91308515 E-mail: info@fidarelectronics.com Website: www.fidarelectronics.com...
