jroo 8-GATES Quick Start Manual

Lyra-8 trigger converter
Hide thumbs Also See for 8-GATES:
1
2
3
4
5
6

Advertisement

Table of Contents

8-GATES
by jroo
8-GATES is a LYRA-8 trigger converter that allows you to sequence the LYRA-8 with your
own sequencer. It's an 8 port 3.5mm V-trig to SOMA-style pole S-trig converter with a
ground pole. CV gates from your sequencer will close the circuits that trigger voices on
the LYRA-8.
While the patch points work great with the official
adapter isn't required for this to work. You could just tape or affix the alligator cables to
the sensors on the LYRA-8 with the same results. Our recommendation would be to buy
an ORNAMENT-8 adapter from SOMA, though. It's one of the more beautiful hacks we've
seen and it's just a better experience.
It is available fully assembled or as a full kit with SMD components pre-soldered.
Contents
- Overview
Overview
ORNAMENT-8 adapter
for LYRA-8, the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8-GATES and is the answer not in the manual?

Questions and answers

Related Manuals for jroo 8-GATES

Summary of Contents for jroo 8-GATES

  • Page 1: Table Of Contents

    8-GATES by jroo 8-GATES is a LYRA-8 trigger converter that allows you to sequence the LYRA-8 with your own sequencer. It’s an 8 port 3.5mm V-trig to SOMA-style pole S-trig converter with a ground pole. CV gates from your sequencer will close the circuits that trigger voices on the LYRA-8.

  • Page 2: Getting Started

    8-GATES accepts 8 V-trig gates (from 0V to 10V) from your sequencer. Connect the 3.5mm jack from your sequencer to one of the 8 3.5mm jacks on 8-GATES. Ensure that your sequencer is sending V-trigs and is sending positive voltage of less than 10V.
  • Page 3 ● connect the other end of the alligator cable to just one of the two GND poles on the ORNAMENT-8 adapter ● connect as many 8-GATES poles as needed to the poles numbered 1-8 on the ORNAMENT-8 adapter If connecting directly to LYRA-8: ●...

  • Page 4: Sending Gates

    Sending gates V-trig gates greater than roughly 0.8V sent to an 8-GATES V-trig input (jack) will result in the output (pole) opening a S-trigger that will close the sensor circuit on your LYRA-8 and launch the envelope generator for the LYRA-8 voice. Up to 8 gates (one per channel) can be sent at a time.

  • Page 5: Troubleshooting

    Troubleshooting: No sound: ● make sure the 8-GATES GND pole is connected to LYRA-8 ground (see above on how to do this either directly or via an ORNAMENT-8 adapter) ● make sure that the 8-GATES S-trig pole for the channel that you’re receiving...

  • Page 6: Support & Latest Documentation

    Support & latest documentation yo@jroo.co https://jroo.co/products/8-gates Acknowledgements Special thanks to BbartokK, Christian Gibson, SOMA Laboratory, Synthesizer Keith, Ottawa Studios Discord, SOMA US Discord Designed and assembled in Canada ©2024 jroo music machines Documentation version: 20240915b...
