Summary of Contents for Soundstream ST-NEBULA-GR
- Page 1 HOME SPEAKER & CHARGING TABLE OWNER’S MANUAL MODEL: ST-NEBULA-GR SAVE THIS INSTRUCTIONS MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Parts Specifications Functions Operations 5-12 Warranty 14-15 Contact... -
Page 3: Introduction
INTRODUCTION Thank you and congratulations on purchas- ing the Soundstream ST-NEBULA-GR Home Speaker & Charging Table! IMPORTANT SAFETY INSTRUCTIONS In order to make the best use of this product and to use it safely, please read the manual carefully before use and keep it for future reference. -
Page 4: Parts
PARTS x 1 Sound Table x 1 Owner’s Manual x 1 AC Adapter NOTE: Pictures are for reference only. -
Page 5: Specifications
SPECIFICATIONS Model ST-NEBULA-GR Drive Units Mid-Range: 3” 4Ω 15W x 2 Tweeter: 1” 8Ω 10W x 2 24W (12Wx2), Max Output: 30W (15W x 2) Max Power: 50W (15W x 2 + 10W x 2) Mood RGB Glow Light on top & bottom... -
Page 6: Functions
FUNCTIONS 1. Power ON/OFF/TWS 2. Volume Down - 3. Play/Pause/Bluetooth Connection 4. Volume Plus + 5. EQ (POP/ROCK/MOVIE) 6. RGB LED Light 7. Wireless Charger... -
Page 7: Operations
FUNCTIONS 8. USB-A Charging Port 9. Type-C Charging Port 10. DC Input Connection 11. Power Switch OPERATIONS Power ON/OFF To Power ON Sound Table for the first time 1. Connect the AC adapter to the DC input on the side of the table. You will need to remove the rubber gasket on the side to see the DC input, charging ports, and power switch. - Page 8 1. When the speaker is in Bluetooth mode, it will automatically enter pairing mode. The blue LED light will flash quickly. NOTE: Bluetooth device name will appear as “ST-NEBULA-GR.” 2. The speaker will pair with a smart phone via Bluetooth. Once connected the speaker will say “Bluetooth is connected.”...
- Page 9 OPERATIONS Bluetooth Connection and Play (LED indicator: The First LED) When playing music after connecting, the speaker will pause when is short pressed. It will play once it is short pressed again. When the speaker is connected, the speaker will switch off the connection of the paired device if the is long pressed.
- Page 10 OPERATIONS EQ Switch (LED indicator: The Second LED) When the speaker is power on, it will enter normal mode by default, the LED indicator will not be illuminated. The speaker will enter “POP” mode with a short press on the EQ button and the LED will turn red.
- Page 11 OPERATIONS TWS Function (LED indicator: The Third LED) 1. Turn on both Sound Tables. 2. Double tap the TWS button to enter Pairing Mode (Turn on both tables to start pairing). The LED will flash orange rapidly. After the pairing is complete, the LED of the master speaker will remain solid and the linked speaker will flash slowly.
- Page 12 OPERATIONS LED Operation (LED indicator: The Fourth LED) 2. Long press the button. The RGB LED light will turn on/off. Short press the button to switch the LED color: RED/GREEN/ BLUE/YELLOW/PURPLE/LIME/WHITE/CYCLE 3. When the RGB LED light is in single color status mode, the RGB LED light on top &...
-
Page 13: Volume Control
OPERATIONS Voice Reminder 1. POWER ON: Connect the power supply (voice prompt when the speaker turns on). 2. BLUETOOTH: Bluetooth Mode 3. POWER OFF: Shut off the power supply (voice prompt when the speaker turns off) 4. WAITING FOR CONNECTION: Pairing (enter Bluetooth Mode, and back to Bluetooth Mode) 5. -
Page 14: Wireless Charging
OPERATIONS Low Battery and Charging 1. When the battery capacity is low, the speaker sound “Battery Low” is to remind the user that the speaker needs to be charged. 2. Connect the power adapter to the DC input on the side of the table to charge the Sound Table. -
Page 15: App
1. Connect Device to Sound Table Go to your Device’s Bluetooth menu in your settings. Search for nearby Bluetooth devices. Tap “ST-NEBULA-GR” to connect to the Sound Table. You are now able to stream audio to the Sound Table. 2. Connect APP to Sound Table Once paired to your device via Bluetooth, the APP will automatically connect to the Sound Table. -
Page 16: Warranty
Soundstream authorized retailer. During this one-year period, there will be no charge for product repair or replacement,... - Page 17 Soundstream neither assumes nor authorizes any person to assume for any liability in connection with the sale of the product.
-
Page 18: Contact
CONTACT If you have any questions or comments, feel free to reach out to us: 1-(800)-832-4647 info@soundstream.com epsilonelectronicsinc.com... - Page 19 THANK YOU FOR YOUR PURCHASE! There are so many choices out there, but you chose us. That means a lot and we want to let you know that we truly appreciate your support.
- Page 20 Scan here for more product information Visit us at: epsilonelectronicsinc.com for more information 1-800-832-4647 info@soundstream.com...
