- Page 1 ThinkVision 27 3D 3D Applications and Application Plug-ins User Manual Machine Type: 63F1...
-
Page 2: Table Of Contents
CONTENTS Disclaimer ........................... 5 Instructions for Use ......................5 3D Service Engine (EESVR) ....................6 Introduction to the Product ..................6 Product Usage ..................... 6 Installation Instructions ..................... 6 Device Preparation ....................6 Installation ......................6 Product Operation Instructions ................7 Tray ........................ - Page 3 Supported Media Formats ................ 18 Supported Media Layout Mode ..............18 Plugin compatible with Creo ..................19 Overview ........................19 Please Note ....................... 19 Start ..........................19 3D Parameter Setup ....................19 Export Setup ......................19 Plugin compatible with 3ds Max ..................21 Overview ........................
- Page 4 3D Display in Slide Show Status ..............27 3D Display Status Interface Operation ............28 Attitude Adjustment Operation ................ 28 Animation Control Operation ................29 Settings Menu Options ..................29 Party APPs ........................30 Instructions on Enabling 3D in Native Applications ..........30 General Steps to Enable 3D Display ...............
-
Page 5: Disclaimer
⚫ Best user experience distance: Keep your eyes about 60-100 cm (approximately 23-39 inches) away from the screen ⚫ Currently, only connection to a single ThinkVision 27 3D device is supported. Supported resolutions: 3840x2160, 1920x1080; recommended resolution: 3840x2160 ⚫ Move your head accordingly to observe from different angles, but do not make any sudden or large movements, as you may not be able to experience the 3D effect ⚫... -
Page 6: Service Engine (Eesvr)
3D Service Engine (EESVR) is a required service engine for 3D Master and other 3D software and plug-ins; if you accidentally delete it, please reinstall it according to the following steps Installation Instructions Device Preparation Before installation, please connect ThinkVision 27 3D to your computer, and perform start-up to install the software. Installation... -
Page 7: Product Operation Instructions
The 3D Service Driver (EESVR) will be installed on your computer along with 3D Explorer. If you accidentally delete it, there will be an installation prompt when entering 3D Explorer. Please follow the instructions to reinstall it. Figure 1-1 3D Reminder that service driver has not been detected After installation, the software icon will appear in the system tray. - Page 8 Figure 1-3 Device is working properly Abnormal status Abnormal status list Possible Cause Interface Prompt Information USB cable connection is unstable USB device connection error, please check the USB cable Eye tracking device connection failed Eye tracking device is abnormal, please restart the computer Firmware version error It is displayed that device data is abnormal,...
- Page 9 Customization calibration Obtain the best viewing effect by adjusting settings in line with the subtle differences in human pupillary distance; you can save these settings in customization calibration Figure 1-5 New customization calibration ⚫ When using for the first time, the second-level menu will contain two items: New and Factory Settings.
-
Page 10: Display Application (3D Master)
3D Display Application (3D Master) Introduction to the Product Overview 3D Master is an application software that provides users with 3D display services for 3D models and media, and can open and play multiple types of 3D models and media. Product Usage ⚫... -
Page 11: Installation Instructions
Search for 3D Master in the Control Panel/Applications and Functions interface of the Windows system, and click the Uninstall key. Product Operation Instructions Preparation before running: When running on ThinkVision 27 3D, please ensure that the device status displayed in the 3D Service Driver (EESVR) is normal. Startup Interface... -
Page 12: Model Browsing Interface
to be opened, and click Open; you can also manually enter the path of the media in the path field and click the Enter key on the keyboard to continue; or you can drag the file in the window to insert the file. Figure 2-3 Startup interface 3D Master will recommend the corresponding opening method or layout method based on the model or media file you selected. - Page 13 Figure 2-5 Basic operation tips page Rendering effect key : Light adjustment, used to adjust the rotation angle and color of the light; : Restore the initial status of the current model or component; : Opaque material, forcing opaque rendering of the model; : Grid material;...
- Page 14 : Mouse visible mode; : Mouse hidden mode; the 3D mouse will not be superimposed on the model surface; Disassembly Operation : Control whether to enter disassembly mode, click to expand other related menus; : Switch the list menu on the right; : Restore previous step;...
-
Page 15: Media Playback Interface
: Export the currently displayed model in GLB format; Animation Control Operations When the model has its own animation, you can toggle between whether the animation playback is paused or not by pressing the space key. You can also toggle the animation playback speed by pressing the Ctrl+space key. - Page 16 : Vertical parallax adjustment. When the left and right eye images of the input source file shift vertically, you can use this key to reduce the discomfort caused by vertical parallax to a limited extent; : Adjust contrast. Due to the functional limitations of the monitor itself, interference may occur between the left and right pictures.
- Page 17 Settings Menu Options Eye tracking: Follow the position of the viewer's eyes to present the 3D effect of the model in real time; Auto 2D: Control whether to automatically switch between 2D and 3D when switching focus and when the viewer leaves; Movement compensation: Level of compensation applied when the viewer’s head moves suddenly;...
-
Page 18: Appendixes
Appendixes 1. Supported 3D Output Methods Options Function Automatic Use default hardware device configuration The left and right split screen mode is used for picture layout output, and the 3D Left and right display is used for the hardware layout. Switch to pure 2D screen 2. -
Page 19: Plugin Compatible With Creo
3D lens type 2 Lens media layout Plugin compatible with Creo Overview Please install the Plugin compatible with Creo plugin to view the stereo effect of the 3D models in Creo software. Please Note It is necessary to declare that this product supports Creo 4.0-10.0 but will not be updated simultaneously with Creo software updates. - Page 20 Figure 3-2 Export setup...
-
Page 21: Plugin Compatible With 3Ds Max
Plugin compatible with 3ds Max Overview The Plugin compatible with 3ds Max is a plug-in for users to open and play various types of 3D models in 3DMax software. Please Note It is necessary to declare here that this product supports 3ds Max 2018 and 3ds Max 2022, but this product will not be updated simultaneously with the updates of 3ds Max software. -
Page 22: Export Settings
Figure 4-2 3D Renderer settings Export Settings Export the Selected Part: Export and view only the selected parts of the assembly components; Export the Texture: Whether to export texture data; Ambient Light Map Merging: Merge AO shadow map into Metalness and Roughness map; Functional items supported by Glb mode when exporting the model Function Description... - Page 23 Basic transparency Ignore transparency color, depth, thin-walled, transparency roughness Color and transparency textures must be of the same size Metalness and Roughness The two textures must be of the same size in order to be merged. Self-luminous Supports emission weight, color, luminance and Kelvin Ambient occlusion Uses diffuse roughness map Bump/Normal map...
- Page 24 DirectX Shader Material Transparent Texture PNG, DDS and TGA formats supported VRay Material Only VRaymtl, VRayMtlWrapper, VRayLightMtl, VRayOverrideMtl Other Materials Unlit Backface culling...
-
Page 25: Plugin Compatible With Microsoft 365
Plugin compatible with Microsoft 365 Overview Plugin compatible with Microsoft 365 is a 3D model 3D display extension program designed for Microsoft Office 365. It currently supports Word, Excel, and PowerPoint, and can switch the inserted 3D model to 3D or naked-eye 3D display with one click. Please Note It is necessary to declare here that this product will not be updated simultaneously with the updates of Microsoft 365 software. -
Page 26: Uninstall Instructions
After installing Microsoft 365, a 3D model key should be displayed in the Insert column. Uninstall Instructions Search for Microsoft 365 in the Control Panel/Applications and Features interface, and click the Uninstall key to uninstall all assemblies. To uninstall the plug-ins in word/excel/powerpoint individually, please search for the AS3DBridge keyword and select to uninstall as needed. -
Page 27: Enter The 3D Display Interface
Figure 5-2 Highlight 3D display service program switch Enter the 3D Display Interface Select the model, and right-click and select "Rendering" to enter the 3D display interface. Figure 5-3 3D display triggering entrance Your pupillary distance: This option allows selection of the user's pupillary distance, with automatic and forced options available. -
Page 28: Display Status Interface Operation
Figure 5-4 3D display triggering entrance 3D Display Status Interface Operation Figure 5-5 3D display interface Attitude Adjustment Operation ⚫ Click the left mouse key to control model rotation; ⚫ Click the right mouse key to control the movement of the model in the X and Y directions; ⚫... -
Page 29: Animation Control Operation
⚫ Or click the left and right arrow keys of the keyboard to control the tilt of the model; ⚫ The default zoom range of the model is 0.5x to 1.5x. When the model is moved in the Z direction and the out-of-screen model collides with the screen, the screen is broken. -
Page 30: Rd Party Apps
Party APPs Supported 3 Party APP list App Type App Name Native 3D App iTwin Capture Modeler Native 3D App Vred Native 3D App Deltagen Native 3D App Patchwork3D Native 3D App Maestro Industrial conversion App converter TechVizXL Game converter 3DGameMarket Instructions on Enabling 3D in Native Applications General Steps to Enable 3D Display... -
Page 31: Game Converter 3Dgamemarket
However, please note that the decoders provided by these third parties are not affiliated with Lenovo, and Lenovo makes no warranty whatsoever about such products themselves or their suitability for use with Lenovo products. -
Page 32: Microsoft 365
vertical parallax at the edges and cannot be corrected. It is not recommended to watch these for a long time. ⚫ Model operation is not sensitive enough First make sure the hardware is connected correctly and the frame rate is set to 60Hz.Stuttering may occur when loading large models. -
Page 33: Developers
Developers We will provide SDK to developers, please refer to the following link: https://pcsupport.lenovo.com/solutions/27_3d...
