- Page 6 Saddle KENDA Fat Tire Name Name Front LED Light Rear Wheel Fenders Front Rack Rear Rack Motor Controller Front Suspension Fork Twist Throttle Front Wheel Fender Parking Brake Lever Pedal Set Transmission Shifter Chain Wheel Adjustable Handle Stem Chain...
- Page 7 Front Frame Section Name Rear Frame Section Front Wheel Battery 3 Fenders Saddle Front and Rear Rack Bag for Front Rack Bag for Rear Rack...
- Page 22 Rear Basket Installation Step 1: Insert he battery into the rail, and connect the battery wire. Step 2: Turn the key to lock position, to lock the battery on the rail.
- Page 40 Maintenance Schedule Check Before Every Adjust / Tighten / Tyre Pressure *Check Periodically Clean / Lubricate █ █ Component / Condition Ride Replace as Required Tyre Wear / Damage █ █ Brake Adjustment █ █ Handlebar Tightness █ █ █ Controls and Displays █...
- Page 41 Pedal assistance not working Under-charged battery. Charge battery. Follow battery care procedures. Possible Cause Possible Solution Battery no longer serviceable. Have battery checked. Replace if faulty. Battery charger faulty. Have charger checked. Replace if faulty. Motor electrics or switches damaged / faulty. Seek diagnosis and repair from authorised service centre.
- Page 42 Grinding noise when pedaling Pedal bearings too tight. Adjust. Bottom bracket bearings too tight. Adjust. Rear wheel not straight. Align so chain straight. Chain too tight. Adjust. Derailleur dirty. Clean and lubricate. Brakes not effective Pads worn. Replace. Pads / discs dirty. Clean and degrease.
- Page 43 No power when pedal assistance Blown fuse. Replace. switched ON Loose connectors / wiring damage. Check connectors / wiring. Replace as required. Faulty switch. Replace. Faulty controller. Replace. Pedal assistance OK, but no display Loose connectors / wiring damage. Check connectors / wiring. Replace as required. Faulty controller.
- Page 45 Contact Information Website: www.dwmeigi.com Address: 9816, Crescent Center Drive, Suite702, Rancho Cucamonga, CA 91730 Email: support@dwmeigi.com...
