Summary of Contents for A-iPower PWE3001
- Page 1 3000 PWE3001 REV_00...
- Page 3 PWE3001 3000 PSI 1.1 GPM and Turbo Nozzle Selection 0° Owner’s Manual, Quick Start Guide, Open End Wrench, Included Nozzle Cleaning Tool and Allen Wrench...
- Page 6 For cold water only. Outdoor use only. Household use only. If connection is made to a potable water system, the system should be Caution protected against backflow.
- Page 7 Caution If connected to circuit protected by fuses, use time delay fuse marked "D"...
- Page 9 Risk of Explosion DO NOT spray flammable liquids.
- Page 10 DO NOT discharge stream at persons.
- Page 11 WARNING Risk of electrocution 1. Inspect cord before using. Do not use lf cord ls damaged. 2. Keep all connections dry and off the ground. 3. Do not touch plug with wet hands. 4. Double insulated - when servicing use only ldentent parts. 5.
- Page 12 A - Handle F - Water Inlet K - Power Cord P - Allen Wrench B - Nozzles G - Detergent Tank L - Hose Hanger Q - Owner's Manual C - Storage Panel H - Trigger M - High Pressure Hose R - Quick Start Guide D - Push Botton I - Spray Gun/Wand...
- Page 13 1. Insert the axle through the frame, wheels and 4. Install the gun holder to the handle by tightening the flat washer, then use the open end wrench to knob nut manually. tighten the nut securely. Finally push the wheel See Figure D.
- Page 14 7. Pull the collar on the high pressure hose back and 10. Attach the nozzle to the wand by pulling back push the hose fitting into the threaded outlet on the quick connect collar and pushing the nozzle the pressure washer. Screw the collar onto the onto the end of the wand.
- Page 16 On the top of the product is the MAIN ON / OFF push button switch (See Figure I). This switch works in conjunction with the AUTO ON / OFF switch built into the product. The AUTO switch turns on and off when the trigger of the gun is squeezed and / or released. Because of this, the system can have pressure, even when the motor is not running.
- Page 17 Turbo Nozzle Soap SOAP Turbo Nozzle 0° Nozzle - Red: This nozzle delivers a pinpoint stream of pressurized water and is extremely powerful. Use it for the toughest cleaning jobs, although It covers only a small area. This nozzle should only be directed at surfaces that can withstand intense high pressure such as metal or concrete.
- Page 19 push Push to off position.
- Page 23 26 23 比例 1.000...
- Page 24 Parts List Part Number Description Qty. 20100-00699-00 Motor & pump assembly 20135-00637-00 Handle tube assembly 20090-02507-00 Frame assembly 33013-01661-00 Base plate assembly 33013-01660-00 Upper shell assembly 20134-00469-00 Wheels assembly 33089-00968-00 Panel 33275-00055-00 Nozzle holder 34031-00397-00 Axel 30125-00027-00 Hex flange nut 33624-00505-00 Hose hook 34035-00076-00...
- Page 28 Made in China...
- Page 30 Made in China 32082-00000-00...
