Operating Instructions
Before the first commissioning read this manual thoroughly and completely and keep it in a safe
Observe and follow the safety instructions and only use the machine if you are sure that you have
Pneumatic Blind Stapler
Type/description:
Page 1 of 16
18.11.24
P:\Technik\TOP_MG_JK\Bedienungsanleitung\englisch\Operation Instructions TOP P EN 11_2024.docx
USER GUIDE
Pneumatic Blind Stapler
TOP SP P
Pneumatic Blind Stapler
Type TOP SP P
IMPORTANT
completely understood all the instructions.
Failure to comply can lead to injuries!
If you have any questions, contact the manufacturer
MEZGER Heftsysteme GmbH
Saganer Straße 24
90475 Nürnberg
See label on tool
place.
Germany
Page:
1
Version: 11/2024
ET
572
Advertisement
Table of Contents
Related Manuals for MG TOP SP P
Summary of Contents for MG TOP SP P
- Page 1 Pneumatic Blind Stapler TOP SP P Operating Instructions Pneumatic Blind Stapler Type TOP SP P IMPORTANT Before the first commissioning read this manual thoroughly and completely and keep it in a safe place. Observe and follow the safety instructions and only use the machine if you are sure that you have completely understood all the instructions.
-
Page 2: Table Of Contents
Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Preface It is necessary to acquire the knowledge conveyed by this ORIGINAL-OPERATING INSTRUCTION for a safe operation. The information is presented in brief and clear form. The chapters are sorted by numbers. - Page 3 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Symbol Signal word Meaning Warning notice Risk of fingers being crushed! Prohibition Protect from moisture! warning notice Risk of fingers being crushed! warning notice Warning of cut and puncture hazard! Read and understand the device labels and manual.
-
Page 4: Warranty And Liability
Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 2 Warranty and liability Our “General Terms of Sale and Delivery” shall generally apply” These terms were made available to the operator by the time of contract award at the latest. -
Page 5: Ambient Conditions
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 4 Ambient conditions The machine should be operated at room temperature, protected against environmental influences. Use within an explosive atmosphere is permitted only with prior consent and written permission of the manufacturer. -
Page 6: Fundamental Notes On The Work Technique And Handling
Version: 11/2024 Pneumatic Blind Stapler TOP SP P It is necessary to install a filter regulator consisting of a filter, water separator and pressure reducer. A hose with a clear diameter of 6 mm is required as the connection hose. -
Page 7: Scope/Intended Use
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 8 Scope/Intended Use The stapler may only be used only for the following purposes: for stapling single and double corrugated cardboard. Do not staple into hard (e.g. metal plates, nails, etc.) and brittle materials. -
Page 8: General/Function
Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P The stapler is easy to maintain, but should be cleaned and serviced regularly. Dirt must be removed directly by the operator after processing. Appropriate care helps to keep the stapler in a functional condition over the long term. The stapler should be thoroughly cleaned at least once a week. -
Page 9: Loading Of Staples
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Position of staple magazine for staples Staple Pusher Trigger Pneumatic connection The penetration depth of the staples is determined by the type of staple. There is no adjustment for setting the stapler. -
Page 10: Error Detection
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Error detection During any kind of defect, the machine is to be shut down and separated from the pressurized air supply until the flawless operation is ensured again. Please do not try to dismantle or repair the machine. - Page 11 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 13.1 No staple or staple not fully bent or left in the stapler Error Reason Solution No pressure Shut-off valve closed. Open shut-off valve. Pressure not set. Set the pressure with the pressure adjustment knob.
- Page 12 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 13.3 Driver change/ Conversion to staple TOP SP 11 TOP SP 18 (s. according spare parts list) Open the 4x screws (3) and carefully pull the angle holding piece (19) with the staple magazine (23) off the front plate (15).
-
Page 13: Technical Data
TOP SP 18. For single corrugated cardboard the staple TOP SP 11 can be used with the stapler TOP SP P 11. For pneumatic staplers, we supply accessories such as balancers, spiral hoses, maintenance units, swivel arms, compressors, etc. -
Page 14: Note On Residual Risks
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Note on residual risks When the stapler is operational, you must not touch the staple exit or the stapling area! !RISK OF INJURY! Protect the stapler from moisture! Do not operate in a wet or damp environment! -
Page 15: Technical Documentation/Service
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P Slips, trips and falls are the main causes of accidents in the workplace. • Pay attention to slippery surfaces caused by using the device and also to the risk of stumbling. - Page 16 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP P 16.2 Declaration of conformity EC declaration in accordance with EC Machine guide line 2006/42/EG, Att. II A The manufacturer of this pneumatic blind stapler, the company MEZGER Heftsysteme GmbH Saganer Straße 24 D-90475 Nürnberg...
