EchoPoint Installation Manual
© Copyright 2022, Fiber SenSys®, Inc. all rights reserved. No part of this publication
may be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopy, recording, or any information storage and retrieval system, without
permission in writing from Fiber SenSys®, Inc., 6175 NE Century Blvd., Hillsboro,
Oregon 97124, USA.
This application note is provided by Fiber SenSys, Inc. While reasonable efforts have
been taken in the preparation of this material to ensure its accuracy, Fiber SenSys, Inc.
makes no express or implied warranties of any kind with regard to the documentation
provided herein. Fiber SenSys, Inc. reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of Fiber SenSys,
Inc. to notify any person or organization of such revision or changes.
Terrain Defender™, EchoPoint™ Microwave Defender™, and Reveal™ are a trademark of
Fiber SenSys, Inc.
Fiber SenSys® and Fiber Defender® are registered trademarks of Fiber SenSys, Inc.
Sealevel® is a registered trademark of Sealevel Systems, Inc.
Windows® is a registered trademark of Microsoft Corporation.
Fiber SenSys, Inc. (FSI)
6175 NE Century Blvd.
Hillsboro, OR 97124
USA
Tel: 1-503-692-4430
Fax: 1-503-692-4410
info@fibersensys.com
www.fibersensys.com
PM-ENG-096 EchoPoint Installation Manual – Limited Distribution
EchoPoint Installation
Manual
Page 1 of 15
Advertisement
Table of Contents
Related Manuals for FIBER SENSYS EchoPoint EP9000 Series
Summary of Contents for FIBER SENSYS EchoPoint EP9000 Series
- Page 1 This application note is provided by Fiber SenSys, Inc. While reasonable efforts have been taken in the preparation of this material to ensure its accuracy, Fiber SenSys, Inc. makes no express or implied warranties of any kind with regard to the documentation provided herein.
-
Page 2: Table Of Contents
EchoPoint Installation Manual Contents OVERVIEW ..............................3 SITE SURVEY ............................. 3 Fences ..............................3 SITE PLANNING FOR CABLE DEPLOYMENT ....................4 PROCURING COMPONENTS ........................5 Fiber-optic cable ........................... 5 End module ............................5 Splice enclosure ............................ 6 Cable ties .............................. 6 2RU EP9000 SERIES controller ...................... -
Page 3: Overview
EchoPoint Installation Manual OVERVIEW Proper installation of the fiber-optic cable is critical for the performance, longevity, and maintainability of EchoPoint system. Installation of the fiber-optic cable is to be carried out by a trained and certified contractor, skilled in the safe cable handling procedures commonly used in the telecommunications sector. -
Page 4: Site Planning For Cable Deployment
• No vegetation, bushes, or tree branches should be in contact with the fence. Fiber SenSys sensors work well for weld mesh, rigid, and decorative fences. The minimum recommended height for such fences is 2.4 m (8 ft.) and climb-over deterrent hardware should be securely mounted on top. -
Page 5: Procuring Components
EchoPoint Installation Manual PROCURING COMPONENTS Fiber-optic cable A single-mode fiber cable is used with following key specifications • Refer to Datasheet for detailed fiber/cable specifications • A gel-filled single mode fiber is recommended for all installations, specifically for buried when footstep detection is required •... -
Page 6: Splice Enclosure
EchoPoint Installation Manual Splice enclosure This houses all splices in the field to protect from weather elements. The double end module is designed to be installed in the specific Coyote LCC enclosure. Cable ties Sensing cable is preferably attached to the fence with stainless steel cable ties if a long life and a high level of security is needed. -
Page 7: Sc/Apc Patchcords
EchoPoint Installation Manual NOTE: EchoPoint uses SC/APC connectors. The connectors must be clean before they are plugged into the controller. SC/APC Patch cords SC/APC patch cords are spliced to the two sensor fibers in the lead-in cable. Test Cable This is shipped by the factory along with the EP9000 SERIES controller. The purpose of the test cable is to test whether the EP9000 SERIES controller is fully functional, and to aid in troubleshooting. -
Page 8: Ru Splice Module
Black. Relay modules (optional): Sealevel relay boards are integrated with Fiber SenSys Inc. products through a USB interface. If a longer length is needed, then an ethernet cable can be used. Examples of some Sealevel relay boards are 410U (Shown below) and 410N. -
Page 9: Cable Deployment
EchoPoint Installation Manual CABLE DEPLOYMENT Before the fiber-optic cable can be mounted on the fence, it is unreeled along the inside of the fence line. The two primary approaches to deploying the fiber-optic cable are (a) unreeling the cable off a cable truck as it moves along the fence and (b) pulling the cable off a stationary reel and around the site. - Page 10 EchoPoint Installation Manual For proper sensor performance, the cable must be held against the fence fabric and fence posts without slack. A minimum bend radius of 6” must be maintained on all cable turns. Stainless steel cable ties are recommended for a durable cable attachment. UV-stabilized nylon cable ties may be used in geographic areas with low average UV levels.
- Page 11 EchoPoint Installation Manual Fiber Optic Sensor Figure 3 A standard cable installation in a straight line in the middle of the fence. Fiber Optic Sensor Figure 2 Recommended cable installation on a reinforced post Page 11 of 15 PM-ENG-096 EchoPoint Installation Manual – Limited Distribution...
-
Page 12: Cable Installation On Gates
EchoPoint Installation Manual CABLE INSTALLATION ON GATES Generally, there are two types of gates encountered on fence perimeters: swinging gates and sliding gates. Sliding gates must be bypassed, and protected by another type of sensor (e.g., a wireless gate sensor or a microwave sensor). Swinging gates can be protected by EchoPoint sensor cable. - Page 13 EchoPoint Installation Manual Fiber Optic Sensor Figure 4 Cable installation for a single swing gate. Fiber Optic Sensor Figure 5 Cable installation for a double swing gate. Page 13 of 15 PM-ENG-096 EchoPoint Installation Manual – Limited Distribution...
-
Page 14: Lead-In Cable Installation
EchoPoint Installation Manual LEAD-IN CABLE INSTALLATION The lead-in fiber-optic cable connects the sensor cable to the indoor EchoPoint controller (Figure 6). Any combination of standard or site-specific installation procedures for fiber-optic telecommunication cables may be used when installing the lead cable. Consult relevant regulations to determine whether a different cable type needs be installed indoors. -
Page 15: Otdr Fiber Loss Measurements
EchoPoint Installation Manual OTDR FIBER LOSS MEASUREMENTS Using OTDR, measure the average loss of the two fibers to be used at the EchoPoint controller location. Following specifications must be met: • The loss for a single event must be ≤ 0.1 dB. •...
