TRIVIEW 4345USC13 User Manual page 48

Technical Specifications
Technical Specifications
4345USC13
TV Model
TV Size
up to 3840 x 2160 4K
Output Resolution
up to 3840 x 2160 4K
Input Resolution
Frameless
Tv Design
Android OS Version : 13 , RAM:1.5GB, Internal Stroage : 16GB
Android Specifications
178 H : 178 V
Viewing Angle
Refresh Rate
10-bit, 1.07 Billion colors
Color Depth
Auto Analog&Digital, Tessrstrial Programs Scan (DVB-T/T2)
Channels
+ Digial Satellite Programs Scan (DVB-S2)
Audio Power
Max Power Consumption
Input Voltage
Without base:
With base:
Dimension & Weight
TV Carton:
Net weight: 7.1kg , Gross weight: 9kg
Inputs and outputs DVB-T/T2, DVB-S2, HDMI x3, AV, USB x2, Ethernet, Wi Fi, Headphone, COAX
Applications Cinema, Play store, Psiphon, Netflix, Screen Mirroring , AnyDesk , Eshare ,YouTube ,VLC
Included an HD receiver , Digital channels recording, Ability to control and connect the
TV with android and iphone mobile devices using Eshare and Screen mirroring APKs,
Features
Playstation connection, Bluetooth Function to connect wireless device to TV,
Voice assistant search through air mouse device
Accessories Remote control, User manual, Warranty card
Guaranty
43 inch
60 Hz
2 x 10 Watts
100 Watt
100-240 VAC /50-60 Hz
width:961, heigh:560, depth:80 mm
width:961, heigh:615, depth:208 mm
width:1040, heigh:643, depth:161 mm
Free one year warranty
Simple Troubleshooting
If the display fails or the performance changes dramatically,check the display in accordance with the following ins
Remember to check the periphe rals to pinpoint the source of the failure.
Symptom
-
Power cannot be turned on.
(Power indicator does not light)
-
No input signal message
appears.
-
The remote control does not
function properly.
-
Flashing spots or s t ripes
appear on the screen.
-
Image colour or quality
deteriorates.
-
Screen position and size
are inncorrect.
-
Image or colour is incorrect.
-
Display warning message.
46
Solution
Check that both ends of the power cable are plugged into the socket
appropriately and the wall socket is operational.
1-Check that the signal line is connected properly.
2-Check that the power of the relevant peripherals is turned on.
3-Check that the input option that has been selected matches with the
input signal.
1-Check the batteries are not drained(Use new batteries).
2-Check that the remote control is within the operating range.
3-Check that the remote control is pointed to the remote control window
on the display.
4-Check that there are no obs acles between the remote control and the
t
remote control window .
Check that there are no emission (Car,HV cable or Neon lamp)or other
possible interference source.
1-Check that all the video setting are adjus t ed appropriately,such as
brightness,contras ,colour etc.
t
2-For more information about video settings,refer to OSD functions in
chapter 2.
Check that the screen position and size is adjus ed appropriately.
t
1-Check that the signal line is connected properly.
2-When connecting to a PC, you can change the resolution of the PC
to acquire the correct image.
The discrepancy of the PC output signal may affect the display of the
image.
1-Check that the input signal line is properly ixed.
2-Select the correct input signal.
3-For more information,refer to supported signal modes in chapter 4.
t ructions.
45
