TRIVIEW 4345USC13 User Manual page 29

Panel control keys
Shut down/ Res art/ Bluetooth
t
When you long press the power button these three options will appear.
1. Shut down : Turn off the TV.
2. Res art : Res art the TV.
t t
3. Bluetooth : Connect TV with bluetooth devices(bluetooth mouse,bluetooth keyboard,bluetooth
speaker, bluetooth Headphone).
Ventilation
1. Please keep this space at leas around the TV as shown in the figure.
t
2. Do not cover the air vents or insert any object into the enclosure.
3. Do not put the device in limited space,e.g.bookcase or embedded closet,unless the TV set is properly
ventilated.
Input and output
After connected, press "SOURCE" key, then menu of signal source will be displayed on the screen.
Press the " " key to select the input signal, and press OK key to confirm.
The connecting mode is shown in the figure.
A ntenna c onnec tion
Warning
firs t. Do not approac h the outdoor antenna to high voltage mains power line to avoid electric shock.The wired network
antenna connected to this TV set mus be isolated from the protective grounding,or else it will cause fire or other hazards.
t
Input and output
1. AV
2. Digital video Broadcas t ing-Terris t rial
3. Digital video Broadcas ing-Satellite
t
4. Audio out (Headphone)
5. Network (Ethernet in)
6. Digital Audio Input (COAX)
7. HDMI 1
8. HDMI 2
9. HDMI 3
10. USB
11. USB
12. Common Interface
