olympia electronics RT-72/HACCP Manual

DOUBLE SIDED ELECTRIC INSECT TRAPS WITH ADHESIVE SHEET
TECHNICAL CHARACTERISTICS
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
FLUORESCENT LAMP
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for your trust in our products. Olympia Electronics - European manufacturer.
The above product, produced and comply with 93/43 of the European council on the 14th of June
1993. (HACCP)
GENERAL
The electric insecticides are used to exterminate various annoying insects. The built-in lamps
(Black Light) produce a light that attracts insects from a distance. They can be used in every area
that many insects exist. They are attracted and pass though the interior metal net, they are
exterminated by the adhesive sheet.
Without using any chemical material it offers a complete protection against many like
insects mosquitos, flies, tiny gnats etc.
WARNING!!!
To clean the special holder (drawer) to which end the insects or to replace the adhesive surface,
we must follow the following procedure:
a. Remove the plug from the socket.
b. unlock the special drawer's hook.
c. Remove the special drawer and empty it. If necessary replace the adhesive sheet. Then place
the special drawer again and lock the hook. Place the plug into the socket again.
If we need to change lamps or starters follow the following procedure.
a. Remove the plug from the socket.
b. Remove the protection grid, by extracting it from its retention points.
c. Replace the lamp or starter that does not work.
d. Place the protection grid in its place by pressing it to secure it to its retention points.
e. Place the plug into the socket again.
ATTENTION!!! When the device is operating, the protection grid must be installed
and the adhesive sheet's cover must be removed.
Installation.
In order for the insecticide to operate simply insert the power plug into any suitable wall outlet that
is readily accessible. It is placed in a clear and visible place so as to attract insects easily
.
It includes two eyelets on the top side for ceiling
mounting installation by using a chain. Theese models are suitable for areas such as
grocery stores, butchers, greengrocers, patisseries, residential areas, etc.
Page 1 from 2
RT-72/HACCP RT-74/HACCP
220-240V AC/50-60Hz
100VA 210VA
2x15W BL 4x15W BL
IP 20
EN 60335-1, EN 60335-2-59
o
0 to 60 C
Up to 95%
Bayblend FR3010, electrostatic painted aluminum
490 x 118 x 420 mm (L x W x H)
3540gr. 4270gr.
2 years (1 year for the lamps)
925074001_09_002
WARNING!!!
- The device is suitable for indoor use.
- The device must be kept away from children.
- The device must be not installed in areas with
combustible gases or explosive dust.
- When the mains cable is damaged, this must be
replaced by our SERVICE department or by an
authorized technician.
72nd km. O.N.R.THESALONIKI-KATERINI
TEL: 23530/51-200, 51611-12
AREA CODE: 60061 Kolindros Katerini - GREECE
Athens branch:
Adromaxis 286, Kalithea
TEL: 210/9852193,9852194
Description
1. Installation point (for normal installation with chain).
2. Fuse holder.
3. Plug.
4. Protection grid.
5. Special drawer.
4
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
HEAD OFFICE
72 km. O.N.R. Thessaloniki-Katerini
nd
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.com
info@olympia-electronics.gr
Page 2 from 2
Head office:
Figure 1
1
2
3
5
925074001_09_002
