Ascent AT5000 OPSW Quick Reference Manual
Optical switch
Hide thumbs
Also See for AT5000 OPSW:
- Quick reference manual (29 pages) ,
- Quick reference manual (27 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Ascent AT5000 OPSW
Summary of Contents for Ascent AT5000 OPSW
- Page 1 AT5000 OPSW Optical Switch Quick Reference Guide Revision 2B...
- Page 2 Quick Reference Guide Revision 2B Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden. This document is produced to assist professional and properly trained personnel with installation and maintenance issues for the product.
-
Page 3: Table Of Contents
AT5000 OPSW Optical Switch Table of Content 1. Product Overview ........................4 2. Features ..........................5 3. Installation ..........................6 4. Operation ............................6 5. Web Management Interface (Web GUI) ................12 Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 3 of 21... -
Page 4: Product Overview
RF thresholds when optical power input is above 0 dBm. Packaged in a 1RU 19” subrack, the AT5000 OPSW offers an intuitive front-panel LCD for user-friendly operation. When combined with ACT 1RU AT5000 XMOD and EDFA amplifiers, the switch delivers robust fiber protection for long-distance video, medium video overlays, and FTTX networks. -
Page 5: Features
AT5000 OPSW Optical Switch 2 Features It has the function of power-off protection. When the device itself fails or its power supply off, it will automatically remain on the current line before the failure to maintain the working status of the network. -
Page 6: Installation
AT5000 OPSW Optical Switch 3 Installation 3.1 Preparation before Installation Please examine the machine to see if there is distinct. Please examine if the accessories is complete and the quality cards is here. If not, please contact sales or dealer. -
Page 7: Main Technical Parameters
AT5000 OPSW Optical Switch 4.2 Main Technical Parameters Category Items Unit Index Remarks Min. Typ. Max. Optical Index Operating Wavelength 1200 1620 Switching Fiber Input Range Switching Fiber Input Range Telecommunication level Insertion Loss Switching Time Optical Return Loss Fiber Connector... -
Page 8: Front Panel Instructions
AT5000 OPSW Optical Switch Setting Setting Main Line Standby Line RF Input Status Working Mode Input Input Main Line RF Standby Line RF > Threshold > Threshold Abnormal Abnormal Main Line Setting Setting > Threshold < Threshold No reference to whether the RF signal... -
Page 9: Front Panel Operation
AT5000 OPSW Optical Switch Identification Name Remarks Local programming RS232 RS232 Port Remote SNMP and WEB supported RJ45 RJ45 Port OPT OUT Optical signal outlet IN 1 OPT IN 1 Optical signal input port 1 IN 2 OPT IN 2 Optical signal input port 2 4.6 Front Panel Operation... - Page 10 AT5000 OPSW Optical Switch 4.7 Notes Static-sensitive laser is applied in the optical switch , please note that electrostatic protection should be applied in the storage of the optical switch and it should not be stored with corrosive material, and the storage temperature should be between - 40°C and + 85°C.
-
Page 11: Warranty Terms
AT5000 OPSW Optical Switch 4.8 Solution to Some Ordinary Problems Fault Phenomenon Faulty Reason Solution Remarks INPUT 1 Red Line1 input signal lower than Adjust the input optical signal the threshold above the threshold or adjust the threshold below the input... -
Page 12: Web Management Interface (Web Gui)
AT5000 OPSW Optical Switch 5 Web Management Interface (Web GUI) Web server is built in SNMP module. Users can directly view the basic operating parameters and network parameters of the device through the web browser. Popular web browsers include IE of Microsoft, Chrome of Google, Firefox of Mozilla, Opera of software ASA's, etc. - Page 13 AT5000 OPSW Optical Switch Set the IP address to make the IP address and the device in the same network segment, so that the computer can access the device. Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 13 of 21...
- Page 14 AT5000 OPSW Optical Switch Open the web browser and enter the IP address of the device in the address bar of the browser, such as 192.168.0.22 The browser will pop up a login box In the pop-up login user name box, enter User Name: "admin" (Note: all lowercase letters), password: "123456", and then enter.
- Page 15 AT5000 OPSW Optical Switch The browser displays the device status page by default The left side of the page is the menu navigation bar. Click to enter the corresponding menu page Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 15 of 21...
- Page 16 AT5000 OPSW Optical Switch Device Setting Page: Alarm Status Page: Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 16 of 21...
- Page 17 AT5000 OPSW Optical Switch Alarm Properties Setting Page: Network Settings Page: Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 17 of 21...
- Page 18 AT5000 OPSW Optical Switch Page to Change User Name and Password: Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 18 of 21...
- Page 19 AT5000 OPSW Optical Switch Restore Page: Update Firmware Page: Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 19 of 21...
- Page 20 AT5000 OPSW Optical Switch Device Logs Page: Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 20 of 21...
- Page 21 Phone: +84-24-37955917 WEB: www.ascentcomtec.com EMAIL: sales@ascentcomtec.com Specifications and product availability are subject to change without notice. Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_1RU_OPSW_QRG_V2b_Jul_2017 Solutions Provider for FTTx, RFoG and HFC www.ascentcomtec.com Page 21 of 21...
