Page 1 Home Appliances QW-HY25F463W-EN QW-HY25F463I-EN Dishwasher User Manual EN-1...
Page 3: Table Of Contents
CONTENTS CHAPTER-1: EXPLANATION OF PRODUCT Technical specifications Conformity with the standards and Test data CHAPTER-2: SAFETY INFORMATION AND RECOMMENDATIONS Recycling Safety information Recommendations Items not suitable for dishwashing CHAPTER-3: INSTALLING THE MACHINE Positioning the machine Water connections Water inlet hose Water outlet hose Electrical connection Fitting the machine undercounter...
Page 4: Chapter -1: Explanation Of Product
CHAPTER -1: EXPLANATION OF PRODUCT 1. Worktop 7. Rating plate 2. Upper basket with racks 8. Control Panel 3. Upper spray arm 9. Detergent and rinse-aid dispenser 4. Lower basket 10. Cutlery basket 5. Lower spray arm 11. Salt dispenser 6.
Page 5: Technical Specifications
CHAPTER -1: TECHNICAL SPECIFICATIONS Technical specifications Capacity 13 place settings Height 850 mm Height (without worktop) 820 mm Width 598 mm Depth 598 mm Net Weight 46 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W...
Page 6: Chapter -2: Safety Information And Recommendations
CHAPTER -2: SAFETY INFORMATION AND RECOMMENDATIONS SAFETY INFORMATION AND RECOMMENDATIONS Recycling • The recyclable materials are used in certain components and packaging. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper which should be disposed of into waste paper collection containers for recycling.
Page 7 • Do not leave the door open, for avoid an accident. • Place knives and other sharp-ended objects in the cutlery basket in blade- down position. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or competents persons in order to avoid a hazard.
Page 8: Recommendations
CHAPTER -2: SAFETY INFORMATION AND RECOMMENDATIONS Recommendations • For energy and water saving, remove coarse residues on your dishes before placing the dishes into the machine. Start your machine after having fully loaded it. • Use the pre-wash programme only whenever necessary. •...
Page 9: Water Connections
CHAPTER -3: INSTALLING THE MACHINE If the door of machine does not close properly, check if the machine is stable on the floor it stands; if not, adjust the feet and ensure its stable position. Water connection İndoor plumbing must be suitable for installing a dishwasher. Also, we recom- mend that you fit a filter at the entrance of your place or apartment so as to avoid any damage to your machine because of any contamination (sand, clay, rust etc.) that might be occasionally carried in through the mains water supply or the...
Page 10: Electrical Connection
CHAPTER -3: INSTALLING THE MACHINE Warning: When a drain hose longer than 4 m is used, the dishes might remain dirty. In that case, our company will not accept responsibility. Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current.
Page 11: Fitting The Machine Undercounter
CHAPTER -3: INSTALLING THE MACHINE Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
Page 12 CHAPTER -3: INSTALLING THE MACHINE Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm...
Page 13: Prior To Using The Machine
CHAPTER -4: PREPARING THE MACHINE FOR USE Prior to using the machine for the first time • Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. • Remove all packaging materials inside the machine. •...
Page 14: Adjusting Salt Consumption
CHAPTER -4: PREPARING THE MACHINE FOR USE Adjusting salt consumption Water hardness German French British Water hardness indicator level hardness dH hardness dH hardness dH L1 is seen on display. 6-11 10-20 7-14 L2 is seen on display. 12-17 21-30 15-21 L3 is seen on display.
Page 15: Combined Detergent
CHAPTER -4: PREPARING THE MACHINE FOR USE Combined detergents Combined detergents may include various properties. Before using the detergent, read the instructions carefully. Generally combined detergents produce sufficent results under certain conditions only. Points to consider when using this type of products: •...
Page 16: Chapter-5: Loading Your Dishwasher
The upper basket is for thin and narrow items. You are recommended to use the cutlery grid in order to obtain the best result. To avoid any possible injuries, long-handle and sharp-pointed dishes with their sharp points facing down or horizontally on the baskets.
Page 17 CHAPTER-5: LOADING YOUR DISHWASHER The movable cutlery basket can be slid between the front and rear wires of the bottom basket. Thanks to this feature, the cutlery basket can be placed at the desired location. EN-17...
Page 18: Alternative Basket Loads
CHAPTER-5: LOADING YOUR DISHWASHER Alternative basket loads Lower Basket Top basket Incorrect Loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: “dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.
Page 19: Chapter -6: Programme Descriptions Programme Items
CHAPTER -6: PROGRAMME DESCRIPTIONS Programme items Programme No 4 Reference Programme Prewash Mini 14' (Jet Quick 30’ names Wash) Temperatures No Heat 40°C 50°C Type of food Prewash to Pre-wash coffee, milk, coffee, milk, tea, cold waste rinse and loosen to rinse and tea, cold meats, meats, vegetables,...
Page 20 CHAPTER -6: PROGRAMME DESCRIPTIONS Programme items Programme No Programme Super 50 min. Dual Wash Hygiene Auto Intensive Steamwash names 60°C - 70°C Temperatures 65°C 60°C 70°C 65°C 65°C Type of food soups, sauces, Soups, sau- Dishes with soups, sauces, soups, sauces, waste pasta, eggs, ces, pasta,...
Page 21: Chapter -7: Switching On The Machine And Selectinga Programme
CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Programme Selection and Operating the Machine By pressing On/Off button(4), energise the machine. On/Off lamp lights as long as the machine is on. Select the suitable programme by pressing Program button(5). Press Start/Pause button (6) to start the program.
Page 22: Changing A Programme
CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Changing a programme If you would like to change the program while washing is continuing. Press the Start/Pause button. When the End light turns on, the programme will have been cancelled. After the program stops, select your desired Switching the Machine Off program via the Program selection button.
Page 23: Chapter -8: Maintenance And Cleaning
CHAPTER -8: MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, run the machine at high temperature.
Page 24: Chapter-9: Failure Codes And What To Do İn Case Of Failure
CHAPTER -9: FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR ERROR CONTROL CODE DESCRIPTION • Make sure the water input tap is totally open and that there is no water cut. Inadequate water • Close the water input tap, separate the water input hose from the supply tap and clean the filter at the connection end of the hose.
Page 25: Chapter -10: Practical And Useful Information
CHAPTER -10: PRACTICAL AND USEFUL INFORMATION If the dishes won’t dry up • A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. If there are rust stains on the dishes •...
Page 26: Disposal Of Your Old Machine
DISPOSAL OF YOUR OLD MACHINE This symbol on the product or package implies that the product should not be treated as domestic waste. Instead, it should be delivered to applicable waste collection places recycling electrical and electronic equipment. You will contribute to avoid potential negative results regarding environment and human health.
Page 27 Service & Support Visit Our Website sharphomeappliances.com EN-27 52255025 R35...
